ADC GPRS Support Node GGSN & SGSN WAVE.GSN Manuel utilisateur

WAVE.GSN

GPRS Support Node GGSN & SGSN

www.adc.com • +1-952-938-8080 • 1-800-366-3891

Spec Sheet

ADC’s WAVE.GSN (GPRS Support Node) is a key component for supporting General Packet Radio

Service (GPRS) and is ideally suited for small size GSM/GPRS networks. WAVE.GSN is standard

compliant, fully manageable and a cost-effective platform engineered to facilitate easy deployment

in community and enterprise GPRS networks. The system is run-time configurable to function as a

Serving GPRS Support Node (SGSN), a Gateway GPRS Support Node (GGSN) or a combined GSN

(SGSN + GGSN).

ADC’s WAVE.GSN (GPRS Support Node) is a cost effective, fully manageable product that is easily

integrated with an existing GSM network to provide GPRS services in corporate and community

networks. It offers a complete set of standard GPRS interfaces related to a GSN node. WAVE.

GSN also supports its signaling and data interfaces over Frame Relay (FR) and SS7 or the Internet

Protocol (IPv4) to provide seamless integration with packet-based networks. Plus, ADC Wireless’

WAVE.GSN provides both local management capability with a GUI-based local manager and a

remote management with an SNMP agent. The WAVE.GSN Local Manager implements GUI based

statistics reporting, configuration management, alarms, status and user actions.

7/08 • 106422AE WAVE.GSN

WAVE.GSN

GPRS Support Node GGSN & SGSN

www.adc.com • +1-952-938-8080 • 1-800-366-3891

ADC Wireless’ WAVE.GSN is run-time configurable to function as a Serving GPRS Support Node (SGSN),

a Gateway GPRS Support Node (GGSN) or a combined GSN (SGSN + GGSN). Interface Specifications:

ETSI TS 101 299, GPRS BSS-SGSN Interface; Network Service (GSM 08.16 version 7.1.0 Release 1998)

ETSI TS 101 343, GPRS BSS-SGSN; BSS GPRS Protocol (BSSGP) (GSM 08.18 version 7.1.0 Release 1998)

Draft ETSI EN 300 940, Digital cellular telecommunications system (Phase 2+);

Mobile radio interface signaling layer 3 specification (GSM 04.08 version 7.4.0 Release 1998)

ETSI TS 101 345, Digital cellular telecommunications system (Phase 2+);

General Packet Radio Service (GPRS); Serving GPRS Support Node (SGSN) – Visitors Location Register

(VLR); Gs interface network service specification (GSM 09.16 version 7.0.1 Release 1998)

Draft ETSI EN 301 347, Digital cellular telecommunications system (Phase 2+);

General Packet Radio Service (GPRS); GPRS Tunneling Protocol (GTP) across the Gn and Gp Interface

(GSM 09.60 version 7.3.0 Release 1998)

ETSI TS 101 297, Digital cellular telecommunications system (Phase 2+); General Packet Radio Service

(GPRS); Mobile Station (MS) – Serving GPRS Support Node (SGSN); Subnetwork Dependent Convergence

Protocol (SNDCP) (GSM 04.65 version 7.1.1 Release 1998)

ETSI TS 101 351, Digital cellular telecommunications system (Phase 2+);

General Packet Radio Service (GPRS); Mobile Station – Serving GPRS Support Node (MS-SGSN) Logical

Link Control (LLC) layer specification (GSM 04.64 version 7.1.1 Release 1998)

ETSI TS 100 974 V7.1.0 (1999-08) Technical Specification Digital cellular telecommunications system

(Phase 2+); Mobile Application Part (MAP) specification

(GSM 09.02 version 7.1.0 Release 1998)

SS7 TCAP specification ITU-T Q.771 – Q774, ETSI ETS 300 134, ETS 300 287, ANSI T1.114

Higher capacity levels can be supported via multiple GSNs to form a distributed network.

7/08 • 106422AE WAVE.GSN

WAVE.GSN

GPRS Support Node GGSN & SGSN

www.adc.com • +1-952-938-8080 • 1-800-366-3891

Conﬁguration Options Combined GSN (WAVE.GSN)

SGSN (WAVE.SGSN)

GGSN (WAVE.GGSN)

SGSN Interconnections Base Station Subsystem/PCU (Gb)

HLR/EIR (Gr and Gf)

MSC/VLR (Gs)

Charging Gateway (Ga)

Other GSN (Gn and Gp)

SGSN Supported Features GPRS Mobility Management (GMM)

Session Management (SM)

Short Message Service (SMS)

Sub-Network Dependent Convergence Protocol (SNDCP);

compression, S-CDR

Standard GPRS Ciphering

Quality of Service (QOS)

Restart and Recovery Procedures

GGSN Interconnections Internet (Gi)

HLR (Gc)

Charging Gateway (Ga)

Other GSN (Gn and Gp)

GGSN Supported Features Dynamic Addressing using DHCP

Authentication using External RADIUS

RADIUS Accounting

Network Initiated PDP contecxt activation

Restart and Recovery Procedures

Managemernt GUI based Local Manager

Remote management with an SNMP agent

Statistics reporting

Conﬁguration Management

Alarms

Status

User Action

Major Interfaces Gb over ITU-T Frame Relay or IPv4

Gr, Gs, Gd over ITU SS7 or IETF SIGTRAN suit

Ga, Gn, Gp, Gc, Gi over IP (Ethernet)

Remote GSN admin via SNMP agent over IP

Physical I/F 4-8 E1 or T1 ports and 2 Ethernet ports

Website: www.adc.com

From North America, Call Toll Free: 1-800-366-3891 • Outside of North America: +1-952-938-8080

Fax: +1-952-917-3237 • For a listing of ADC’s global sales office locations, please refer to our website.

ADC Telecommunications, Inc., P.O. Box 1101, Minneapolis, Minnesota USA 55440-1101

Specifications published here are current as of the date of publication of this document. Because we are continuously

improving our products, ADC reserves the right to change specifications without prior notice. At any time, you may

verify product specifications by contacting our headquarters office in Minneapolis. ADC Telecommunications, Inc.

views its patent portfolio as an important corporate asset and vigorously enforces its patents. Products or features

contained herein may be covered by one or more U.S. or foreign patents. An Equal Opportunity Employer

Spec Sheet

Hardware Platform Industrial Grade PC Platform

2.0 GHz P4 Processor with 1GB RAM

20 GB hard drive

Network cards

DVD-RW drive

19” rack mount with 2U form factor

Monitor and keyboard for Local Manager

1-2 Adax HDC card (4 E1 or T1 ports per card) for FR or SS7

Red Hat Linux ES 4 (pre-loaded)

Capacity WAVE.GSN 300: 300 attached users and 500 PDP contexts

WAVE.GSN 1000: 1000 attached users and 1500 PDP contexts

WAVE.GSN 3000: 3000 attached users and 4500 PDP contexts

WAVE.GSN 5000: 5000 attached users and 7500 PDP contexts

WAVE.GGSN up to 15000 active users

WAVE.SGSN up to 50000 attached users
