OPERATING MANUAL
PRODIGIT MARKER
Inclinometer
adainstruments.com
APPLICATION:
Control and measurement of slope of any surface. It is used in wood process-
ing industry (especially in furniture manufacturing industry) for wood angle
accurate cutting; auto repair industry for tiring assembling angle accurate con-
trolling; in machining industry for machine tool working angle accurate posi-
tioning; in woodwork; when setting guides for gypsum board partitions.
PRODUCT FEATURES:
─Relative/absolute measurement interchange at any position
─Built-in magnets on measuring surface
─Slope measurement in % and °
─Power-off automatically in 3 minutes
─Portable size, convenient to co-work with other measuring tools
─HOLD data
─2 built-in laser aimers
TECHNICAL PARAMETERS
Measuring range.......................... 4х90°
Resolution...................................... 0.05°
Accuracy......................................... ±0.2°
Battery............................................ Li-On battery, 3,7V
Working temperature................. -10°С ~50°
Dimension...................................... 561х61х32 mm
Laser aimers ................................. 635нм
Laser class ..................................... 2, <1mVt
FUNCTIONS
LI-ONBATTERY
Inclinometer operates from built-in Li-On battery. Battery level is shown on
the display. Blinking indicator (4) without inner bars shows low battery level.
For charging, connect the charger via USB type-C wire to the socket on the
back cover of the inclinometer. If the battery is fully charged, the indicator (4)
doesn’t blink, all bars are lled.
NOTE! Do not use charger with output voltage more than 5V.
Higher voltage will damage the device.
OPERATION
1. Press «ON/OFF» button to switch ON the tool. The LCD displays absolute
hoprizontal angle. «Level» is displayed on the screen. Press «ON/OFF» button
againto switch o the tool.
2. If you lift the left side of the tool you will see an arrow “up” on the left side
of the display. On the right side of the display you will see an arrow “down”. It
means the left side is higher and right side is lower.
3. Measurement of relative angles. Place the tool on the surface from which it is
necessary to measure the relative angle, press “ZERO” button. 0 is desplayed.
«Level» is not desplayed. Then place the tool on another surface. Value of the
relative angle is desplayed.
4. Press shortly «Hold/Tilt%» button to x the value on the display. To continue
measurements repeat short pressing of «Hold/Tilt%» button.
5. Press «Hold/Tilt%» button for 2 sec to measure slope in %. To make angle
measurement in degrees, press and hold «Hold/Tilt%» button for 2 sec.
6. Use the laser lines to mark the level at a distance from inclinometer. Lines
can be used only for marking on vertical surfaces (such as walls) where the
level is attached to. Press ON/OFF button to swtich ON/OFF the tool and select
laser lines: right line, left line, both lines. Attach the tool to the vertical surface
and rotate it to the desired angle focusing on the data on the display. Mark the
inclination along laser lines on the vertical surface.
7. Magnets from all sides allow to attach the tool to the metal object.
8. “Err” is displayed on the screen, when the deviation is more than 45 degrees
from the vertical position. Return the instrument to the upright position.
CALIBRATION
1. Press and hold ZERO button to turn on the calibration mode. Then press
and hold ON/OFF button. Calibration mode is activated and “CAL 1” is dis-
played. Place the tool on a at and smooth surface as shown in the picture.
2. Press ZERO button once in 10 seconds. “CAL 2” wil be displayed. Rotate the
tool by 90 degrees in clockwise direction. Place it on the right edge towards
display.
3. Press ZERO button once in 10 seconds. “CAL 3” wil be displayed. Rotate the
tool by 90 degrees in clockwise direction. Place it on the upper edge towards
display.
4. Press ZERO button once in 10 seconds. “CAL 4” wil be displayed. Rotate the
tool by 90 degrees in clockwise direction. Place it on the left edge towards
display.
5. Press ZERO button once in 10 seconds. “CAL 5” wil be displayed. Rotate the
tool by 90 degrees in clockwise direction. Place it on the lower edge towards
display.
6. Press ZERO button once in 10 seconds. “PASS” wil be displayed. After a while
“0.00 degrees” will be also displayed. The calibration is over.
SAFETY OPERATION INSTRUCTIONS
IT IS FORBIDDEN:
• Use a charger with an output voltage of more than 5 V to charge the
battery of the device.
• Use of the device not according to the instructions and use that goes
beyond the permitted operations;
1. press ZERO in 10 min.
2. rotate the device
3. press ZERO in 10 min.
4. rotate the device
5. press ZERO in 10 min.
6. rotate the device
7. press ZERO in 10 min.
8. rotate the device
9. press ZERO in 10 min.
10. calibration is over
1. Laser line 1. Laser line
2. ON/OFF the tool/laser
lines 4. Relative angle
3. HOLD data
Measuring units
1. Measuring units
5. Direction of the inclina-
tion
4. Power indication
2. Mode of the level
3. HOLD data
WARRANTY CARD
Name and model of the product ______________________________________________
Serial number ___________________ Date of sale ______________________________
Name of commercial organization ____________________________________________
Stamp of commercial organization
Warranty period for the instrument explotation is 24 months after the date of
original retail purchase.
During this warranty period the owner of the product has the right for free
repair of his instrument in case of manufacturing defects. Warranty is valid
only with original warranty card, fully and clear lled (stamp or mark of thr
seller is obligatory).
Technical examination of instruments for fault identication which is under
the warranty, is made only in the authorized service center. In no event shall
manufacturer be liable before the client for direct or consequential damages,
loss of prot or any other damage which occur in the result of the instrument
outage. The product is received in the state of operability, without any visible
damages, in full completeness. It is tested in my presence. I have no complaints
to the product quality. I am familiar with the conditions of qarranty service and
i agree.
Purchaser signature _________________________________
Before operating you should read service instruction!
If you have any questions about the warranty service and technical support contact seller
of this product
• Use of the device in an explosive environment (gas station, gas equipment,
chemical production, etc.);
• Disabling the device and removing warning and indicative labels from the
device;
• Opening the device with tools (screwdrivers, etc.), changing the design of
the device or modifying it.
WARRANTY
This product is warranted by the manufacturer to the original purchaser to be
free from defects in material and workmanship under normal use for a period of
two (2) years from the date of purchase.
During the warranty period, and upon proof of purchase, the product will be
repaired or replaced (with the same or similar model at manufactures option),
without charge for either parts of labour. In case of a defect please contact the
dealer where you originally purchased this product.
The warranty will not apply to this product if it has been misused, abused or al-
tered. Without limiting the foregoing, leakage of the battery, bending or dropping
the unit are presumed to be defects resulting from misuse or abuse.
PRODUCT LIFE
The service life of the product is 3 years. Dispose of the device and its battery
separately from household waste.
EXCEPTIONS FROM RESPONSIBILITY
The user of this product is expected to follow the instructions given in operators’
manual. Although all instruments left our warehouse in perfect condition and
adjustment the user is expected to carry out periodic checks of the product’s
accuracy and general performance. The manufacturer, or its representatives,
assumes no responsibility of results of a faulty or intentional usage or misuse
including any direct, indirect, consequential damage, and loss of prots. The
manufacturer, or its representatives, assumes no responsibility for consequen-
tial damage, and loss of prots by any disaster (earthquake, storm, ood ...), re,
accident, or an act of a third party and/or a usage in other than usual conditions.
The manufacturer, or its representatives, assumes no responsibility for any dam-
age, and loss of prots due to a change of data, loss of data and interruption of
business etc., caused by using the product or an unusable product. The manufac-
turer, or its representatives, assumes no responsibility for any damage, and loss
of prots caused by usage other thsn explained in the users’ manual. The manu-
facturer, or its representatives, assumes no responsibility for damage caused by
wrong movement or action due to connecting with other products.
WARRANTY DOESN’T EXTEND TO FOLLOWING CASES:
1. If the standard or serial product number will be changed, erased, removed
or wil be unreadable.
2. Periodic maintenance, repair or changing parts as a result of their normal
runout.
3. All adaptations and modications with the purpose of improvement and
expansion of normal sphere of product application, mentioned in the service
instruction, without tentative written agreement of the expert provider.
4. Service by anyone other than an authorized service center.
5. Damage to products or parts caused by misuse, including, without limita-
tion, misapplication or nrgligence of the terms of service instruction.
6. Power supply units, chargers, accessories, wearing parts.
7. Products, damaged from mishandling, faulty adjustment, maintenance with
low-quality and non-standard materials, presence of any liquids and foreign
objects inside the product.
8. Acts of God and/or actions of third persons.
9. In case of unwarranted repair till the end of warranty period because of
damages during the operation of the product, it’s transportation and storing,
warranty doesn’t resume.
adainstruments.com
No.101 Xinming West Road, Jintan Development Zone,
Changzhou Jiangsu China
Made In China
