ActionTec T3280B Manuel utilisateur

User Manual

WiFi 6 Gateway Router

with Bonded VDSL

Model # T3280

0535-0137-000

Table of Contents

1 Introduction 4

Package Contents 5

Minimum System Requirements 5

Features 5

Getting to Know the Gateway 6

Connecting the Gateway 9

2 Accessing the Home Screen 11

Accessing the Home Screen 11

Icon Bar 12

Connection Status 13

3 Checking the Gateway’s Status 14

Accessing the Status Screens 14

Connection Status 15

Line 1/Line 2 Status 16

WAN Ethernet 17

Routing Table 17

Firewall Status 18

NAT Table 18

Wireless Status 19

Advanced Wireless Status 20

Wireless Monitor 20

Modem Utilization 21

LAN Status 21

ARP Table 22

Network Devices 22

Interface Statistics 23

Multicast Statistics 23

System Log 24

4 Configuring Wireless Settings 25

Accessing Wireless Settings 25

Basic Settings 26

Windstream T3280 Gateway

Advanced Settings 27

WPS 28

MAC Address Control 29

WDS 30

Band Steering 31

5 Configuring Firewall Settings 32

Accessing Firewall Settings 32

Firewall 33

IPv6 Firewall 34

Port Forwarding 35

Applications 36

DMZ Hosting 37

IPv6 DMZ Hosting 38

UPnP 39

5 Advanced Settings 40

Accessing the Advanced Setup Screens 40

Services Blocking 42

Website Blocking 42

Scheduling Access 43

Parental Controls 44

WAN IP Addressing 45

IPv6 WAN Settings 46

RFC1483 Transparent Bridge 47

LAN IP Settings 48

Static IP 49

IPv6 LAN Settings 50

DHCP Reservation 51

Dynamic DNS 52

DNS Host Mapping 53

IP QoS Upstream Settings 54

IP QoS Downstream Settings 55

IPv6 Q0S 56

Remote GUI 57

Remote Telnet 57

Dynamic Routing 58

Admin Password 59

Storage Device Info 59

iii

Windstream T3280 Gateway

Samba Configuration 60

Reboot 60

Restore Defaults 61

Upgrade Firmware 61

Check for New Firmware Link 62

Speed Test 62

Ping Test 63

Tcpdump Debug 64

Iperf Test 65

IPv6 Ping Test 66

Traceroute 67

IPv6 Traceroute 68

Time Zone 69

Language Settings 69

DNS Cache 70

IGMP Setting 71

Upgrade History 72

ALG 72

Tool Box 73

DLNA 73

xDSL Diagnostics 74

Print Server 75

A Specifications 76

General 76

Wireless Operating Range 77

LED Indicators 77

Power Adapter 77

Environmental 78

Notices 79

Warranty 79

Important Safety Instructions 79

FCC Class B Equipment 80

Important Note on Wi-Fi 81

Contact Info 82

Introduction

Congratulations on purchasing the T3280 Wireless 11axBonded VDSL2 Modem

Gateway. The Gateway is a single platform device that supports universal WAN

access, FTTN, FTTdp, FTTB, or FTTP. With support for advanced 802.11ax4x4

WiFi, the Gateway enables blazing fast HD video streaming, with multi-channel

HD video throughput. The Gateway also offers an unprecedented level of security,

helping protect your network resources. It has also been designed to deliver

unparalleled WiFi performance, using dual-band WiFi supporting speeds up to

3.55 Gbps.

Windstream T3280 Gateway

Package Contents

• Black Power adapter

• Yellow cable (Ethernet, 6 ft.)

• White cable (Ethernet, 10 ft.)

• Quick Start Guide

• Installation Guide

• Wall-mount template

• Vertical stand

Minimum System Requirements

• Active ADSL2+ service

• Computer with an 10 Mbps or 10/100/1000 Mbps Ethernet connection

• Microsoft Windows 10, 8, 7; Mac OS OS X+

• TCP/IP network protocol installed on each computer

Features

• ADSL2+, VDSL2, WAN Ethernet and Fiber in a single CPE

• Dual Band WiFi delivering up to 3.55 Gbps with 802.11ax4x4 5GHz

and 802.11ax 3x3 2.4GHz

• Optimized for IPTV and Video over WiFi

Introduction

Getting to Know the Gateway

This section contains a quick description of the Gateway’s lights, ports, and other

features. The Gateway has several indicator lights (LEDs) and a button on its front

panel, and a series of ports and switches on its rear panel.

Front Panel

The front panel of the Gateway features 12 LEDs, and a WPS (Wireless Protected

Setup) button.

Power

The Power LED brights green when the unit is powered up.

DSL 1

The DSL 1 LED brights green when the DSL 1 is synchronized.

DSL 2

The DSL 2 LED brights green when the DSL 2 is synchronized.

Internet

The Internet LED illuminates green when the Gateway is properly connected to

a WAN Internet connection.WAN/LANThis LED brights green when there is

an active Ethernet cable connected to the WAN port, and it blinks with traffic

activity.

Ethernet 1

This LED brights green when there is an active Ethernet cable connected to the

LAN port #1, and it blinks with traffic activity.

Ethernet 2

This LED brights green when there is an active Ethernet cable connected to the

LAN port #2, and it blinks with traffic activity.

Ethernet 3

This LED brights green when there is an active Ethernet cable connected to the

LAN port #3, and it blinks with traffic activity.

Ethernet 4

This LED brights green when there is an active Ethernet cable connected to the

LAN port #4, and it blinks with traffic activity.

Windstream T3280 Gateway

USB

This LED brights green when there is an active device connected to the USB

port.

Wi-Fi 2.4G

This LED brights green when the Gateway’s radio is operating in the 2.4GHz

band.

Wi-Fi 5G

This LED brights green when the Gateway’s radio is operating in the 5GHz

band.

WPS Button

The WPS button is used when connecting a wireless device to the Gateway’s

wireless network using WPS.

Rear Panel

The rear panel of the Gateway features 8 ports, and a Reset button.

Power Port

The Power port is used to connect the Power cord (Model No.

CDS036-W120U, made by Actiontec) to the Gateway.

Reset Button

Depressing the Reset button for 10 seconds will restore the Gateway’s

factory default settings. The reset process will start after releasing the

button.

Introduction

WARNING! Do not unplug the Power cord from the Gateway

during the reset process. Doing so may result in permanent damage

to the Gateway.

WAN Ethernet Port

The WAN Ethernet port is used to connect the Gateway to a WAN

connection via an Ethernet cable.

LAN Ethernet Ports (4)

The LAN Ethernet ports are used to connect computers to the Gateway

via Ethernet cable. The Ethernet ports are 10/100/1000 Mbps auto-

sensing ports, and either a straight-through or crossover Ethernet cable

can be used when connecting to the ports.

USB Port

The USB port is used to connect the Gateway to a USB device.

DSL Port

The DSL port is used to connect the Gateway to a DSL wall outlet via

DSL cable.

Windstream T3280 Gateway

Connecting the Gateway

There are many variables involved when connecting the Gateway, depending on the

type of Internet service available. The figure below shows the possible connections

available for the Gateway.

Connecting a Computer to the Gateway

To connect a computer to the Gateway to access the Gateway’s graphical user

interface (GUI):

1. Get the Gateway and black Power cord from the box.

2. Plug the black Power cord in the black port on the back of the Gateway and

then into a power outlet.

3. Plug the yellow Ethernet cable from the box into one of the four yellow

Ethernet ports on the back of the Gateway.

4. Make sure the computer is powered on, then plug the other end of the

yellow Ethernet cable into an Ethernet port on the computer.

5. Make sure that the LED on the LAN port into which the Ethernet cable is

plugged glows steadily green. This may take a few moments.

6. The computer should either be configured with a statically defined IP address

and DNS address, or instructed to automatically obtain an IP address using

the Network DHCP server. The Gateway is set up, by default, with an active
