Wireless

DSL Modem

Model #: GT724WGR

User Manual

Ver 1.0

Solutions for the Digital Life™

Table of Contents

1 Introduction 1

Minimum System Requirements 1

Features 2

Getting to Know the Modem 3

2 Performing a Quick Setup 7

Accessing Quick Setup Screens 7

Changing the Password 9

3 Viewing the Modem’s Status 11

Broadband Connection Status 11

Network Status 14

4 Configuring Wireless Settings 15

Accessing Wireless Setup 15

Basic Wireless Setup 17

Wireless Advanced Settings 17

Wireless Status 23

5 Configuring Advanced Setup Options 25

Accessing the Advanced Setup Options 25

DSL Settings 27

DHCP Settings 28

LAN IP Address 30

WAN IP Address 31

QoS Settings Upstream 33

QoS Settings Downstream 35

QoS Status 36

Remote Management 36

Telnet Timeout Setting 37

Dynamic Routing 38

Static Routing 38

UPnP (Universal Plug and Play) 39

Time Zone 39

Remote Syslog Capture 40

Actiontec Wireless DSL Modem User Manual

6 Configuring Security Settings 41

Accessing Wired Security Screens 41

Admin User Name and Password 42

Firewall 43

Port Forwarding 47

DMZ Hosting 49

NAT (Network Address Translation) 50

7 Configuring Internet Access Controls 51

Accessing Internet Access Control Screens 51

Services Blocking 52

Website Blocking 53

Schedule Rules 54

8 Configuring the Modem’s Utilities 57

Accessing the Utilities Screens 57

Restore Default Settings 59

Upgrade Firmware 59

Web Activity Log 60

System Log 61

OAM Ping Test 62

Ping Test 62

Reboot 63

9 Troubleshooting 65

Troubleshooting 65

Frequently Asked Questions 67

A Specifications 73

General 73

Wireless Operating Range 74

LED Indicators 74

Environmental 74

B Setting up Static IPon a Computer 75

Windows 2000 75

Windows XP 80

Windows Vista 83

C Service Acronyms 87

Service Acronym Definitions 87

D Glossary 91

Notices 95

Regulatory Compliance Notices 95

Modifications 95

Limited Warranty 97

Introduction

Thank you for purchasing the Actiontec Wireless DSL Modem. The Modem is the

simplest way to connect computers to a high-speed broadband connection. This

easy-to-use product is perfect for the home office or small business. If you want to

take your computing to the next level, the Wireless DSL Modem is sure to be one

of the keys to your success.

Minimum System Requirements

s Active DSL service

s Computer with a 10 Mbps or 10/100 Mbps Ethernet connection

s Microsoft Windows 2000, XP, Vista

Mac OS 7.1+, 8.0+, 9.0+, OS X+

s Internet Explorer 4.0 or higher (5.x+ recommended) or Netscape Navigator

4.0 or higher (4.7+ recommended)

s TCP/IP network protocol installed on each computer

Actiontec Wireless DSL Modem User Manual

Chapter 1 Introduction

Features

s ADSL WAN port (RJ-11)

s Full-rate ANSI T1.413 Issue 2, ITU G.992.1(G.dmt) and G.992.2(G.lite)

standard compliance

s Auto-handshake for different ADSL services

s Bridged Ethernet over ATM, PPP over ATM, PPP over Ethernet

s Precise ATM traffic shaping

s IP packet routing and transparent bridge

s RIP-1, RIP-2, and static routing protocol support

s Built-in NAT, DHCP server

s DNS relay support

s PAP/CHAP authentication, administrative passwords through Telnet

s 64-, 128-, and 256-bit WEP/WPA wireless LAN security

s IEEE 802.3 Ethernet standard compliance

s 10/100 Base-T Ethernet ports (4)

s Fast Ethernet flow control support

s Web-based configuration setup

s FTP firmware upgradeable

s Web download support

s 802.11b/g support

Actiontec Wireless DSL Modem User Manual

Chapter 1 Introduction

Getting to Know the Modem

This section contains a quick description of the Modem’s lights, ports, etc.

The Modem has several indicator lights (LEDs) on its front panel and a series of

ports on its rear panel.

Front Panel

The front panel of the Modem features eight lights: Power, DSL, Internet,

Ethernet (4), and Wireless.

Power Light

The Power light displays the Modem’s current status. If the Power light glows

steadily green, the Modem is receiving power and fully operational. When the

Power light is rapidly flashing, the Modem is initializing. If the Power light glows

red when the Power cord is plugged in, the Modem has suffered a critical error

and technical support should be contacted.

DSL Light

The DSL light illuminates when the Modem is connected to a DSL line and the

unit is able to synchronize to the DSL signal from the ISP. When it flashes, the

Modem’s built-in DSL modem is training for the DSL service.

Actiontec Wireless DSL Modem User Manual

Chapter 1 Introduction

Internet Light

When the Internet light glows steadily, the Modem is connected to the

DSL provider.

Ethernet Lights

The Ethernet lights illuminate when the Modem is connected to one or more

computers via its yellow Ethernet ports.

Wireless Light

The Wireless light illuminates when the Modem’s wireless radio is turned on.

Rear Panel

The rear panel of the Modem contains six ports (Ethernet [4], Line, and Power), as

well as Reset and Power switches.

12VDC 0 6A

Reset

ON OFF

Ethernet Ports

The Ethernet ports are used to connect computers to the Modem via Ethernet

cable. The Ethernet ports are 10/100 Mbps auto-sensing ports, and either a

straight-through or crossover Ethernet cable can be used when connecting to

the ports.

Line Port

The Line port is used to connect the Modem to a DSL (Digital Subcriber

Line) connection.

Actiontec Wireless DSL Modem User Manual

Chapter 1 Introduction

Reset Switch

Depressing the Reset switch restores the Modem’s factory default settings. To

reset the Modem, depress and hold the Reset switch for five to seven seconds.

The reset process will start after releasing the switch, during which the Power

light will turn from green to orange.

Power Port

The Power port is used to connect the Power cord to the Modem.

N Warning: Do not unplug the Power cord from the Modem dur-

ing the reset process. Doing so may result in permanent damage

to the Modem.

Power Switch

The Power switch is used to power the Modem on and off.

Actiontec Wireless DSL Modem User Manual

This page left intentionally blank.

Performing a

Quick Setup

This chapter is a guide through a quick set up of the Modem, including how to

connect the Modem to the ISP.

To complete the quick setup, have the Welcome Letter or ISP Worksheet handy. If

the document is not available, contact the ISP immediately.

Accessing Quick Setup Screens

To access the Quick Setup screens:

1. Open a Web browser. In the “Address” text box, type:

http://192.168.0.1

then press Enter on the keyboard.
