ActionTec MegaPlug HPE100T Manuel utilisateur

85 Mbps

MegaPlug

Ethernet Adapter

Model #: HPE100T

User Manual

Ver 1.0

Solutions for the Digital Life™

Table of Contents

1 Introduction 1

Package Contents 1

Features 2

System Requirements 2

Getting to Know the Ethernet Adapter 3

Technical Support 4

2 Connecting the MegaPlug Adapter 5

Connecting the Adapters 5

Installing the Configuration Utility 6

3 Using the Configuration Utility 9

Quick Setup 9

Advanced 10

About 12

4 Troubleshooting 13

Troubleshooting 13

Frequently Asked Questions 14

5 Setting Up Static IP Address 17

Windows 98 SE 17

Windows Me 20

Windows 2000 23

Windows XP 27

6 Setting Up File and Printer Sharing 31

File Sharing 31

Printer Sharing 39

A Specifications 41

General 41

LED Indicators 42

Environmental 42

B Glossary 43

Notices 47

Regulatory Compliance Notices 47

Modifications 47

Miscellaneous Legal Notices 48

Limited Warranty 49

Actiontec HomePlug Ethernet Adapter User Manual

This page left intentionally blank.

Introduction

Thank you for purchasing the Actiontec MegaPlug Ethernet Adapter. The

MegaPlug Ethernet Adapter is one of the easiest ways to enjoy home or small busi-

ness networking. It operates on the MegaPlug Powerline Specification Turbo stan-

dard, providing data transfer speeds up to 85 Mbps over home AC wiring. Since

home power lines are the most pervasive medium in households, with multiple

outlets in every room, the MegaPlug Ethernet Adapter allows multiple desktop and

laptop computers to be networked easily, enabling them to share an Internet con-

nection, printers, files, and games, without any additional wiring. If you want to

take your computer networking to the next level, the Actiontec MegaPlug Ethernet

Adapter is sure to be one of the keys to your success.

Package Contents

Make sure the following items came in this package:

s One Actiontec 85 Mbps MegaPlug Ethernet Adapter

s One Ethernet Cable

s Installation CD (includes this manual)

s Quick Start Guide

Actiontec MegaPlug Ethernet Adapter User Manual

Chapter 1 Introduction

Features

s HomePlug Turbo compliant

s 85 Mbps data rate (maximum)

s 56-bit DES encryption

s Two-pronged US power plug (fits ungrounded power outlets)

s Power and Link indicators

System Requirements

s At least 1 available power outlet

s Standard home power wiring

s Computer with the following:

· CD-ROM drive

· IBM compatible running at 200 MHz or better

· Windows 98SE, Me, 2000, or XP installed

· 64 MB of RAM

· Ethernet network adapter

· TCP/IP installed

Actiontec MegaPlug Ethernet Adapter User Manual

Chapter 1 Introduction

Getting to Know the Ethernet Adapter

This section contains a quick description of the Adapter’s external features.

Front Panel

The Adapter’s front panel features 2 lights (LEDs):

Power Light

The Power light glows green when sychronized with another device. If the Power

light is off, it can still be powered up.

Link Light

The Link light glows green when an Ethernet connection is detected, and flickers

when data is being transferred across the Adapter.

Bottom Panel

The Adapter’s bottom panel contains one Ethernet port:

Ethernet Port

The Ethernet port is used to connect the Adapter to a computer or gateway/

router via Ethernet cable.

Information Sticker

The information sticker (located beneath the electrical prongs) displays the MAC

(Media Access Control) address, device ID, serial number, and other information

about the Adapter.

Actiontec MegaPlug Ethernet Adapter User Manual

Technical Support

Actiontec Electronics prides itself on making durable, high-quality, high-perfor-

mance products. If you need assistance, the Actiontec Technical Support Department

is available all day every day to provide professional support.

Actiontec Electronics, Inc.

760 N. Mary Avenue

Sunnyvale, CA 94085

Technical Support

Phone: (USA) 1-888-436-0657

E-mail: http://support.actiontec.com/email_support/support_form.php

Internet: www.actiontec.com/support

Connecting the

MegaPlug Adapter

To connect the Adapter, it must be connected to a computer, plugged into a stan-

dard wall outlet, and the Configuration Utility loaded on the computer.

Connecting the Adapters

To use the Adapters properly, two Adapters should be plugged into electrical out-

lets, and devices (computers, printers, etc.) connected to them.

Connecting an Adapter to a Computer

1. Get an Adapter and one Ethernet cable.

2. Insert one end of the Ethernet cable into the Ethernet port of the Adapter.

3. Plug the Adapter into a wall outlet.

☞

Note: Do not plug the Adapter into a UPS or power strip with

surge protection. The Adapter’s network signal may not pass

through these devices.

4. Insert the other end of the Ethernet cable into an Ethernet port on the back of

a computer.

Connecting an Adapter to a Router/Gateway

1. Get an Adapter and one Ethernet cable.

2. Insert one end of the Ethernet cable into the Ethernet port of the Adapter.

3. Plug the Adapter into a wall outlet.

☞

Note: Do not plug the Adapter into a UPS or power strip with

surge protection. The Adapter’s network signal may not pass

through these devices.

4. Insert the other end of the Ethernet cable into an Ethernet port on a router/

gateway connected to a computer.

Actiontec MegaPlug Ethernet Adapter User Manual

Chapter 2 Connecting the MegaPlug Adapters

5. Insert the other end of the Ethernet cable into an Ethernet port on a router/

gateway connected to a computer.

Follow the instructions in the next section, “Installing the Configuration Utility.”

Installing the Configuration Utility

After connecting the Adapters, install the Configuration Utility:

1. Insert the Installation CD in the CD-ROM drive of the computer connected

to an Adapter.

2. When the “Welcome” screen appears, click Next.

3. When the “Choose Destination Screen” appears, click Next.

Actiontec MegaPlug Ethernet Adapter User Manual

Chapter 2 Connecting the MegaPlug Adapters

4. When this window appears, click Finish.

5. Repeat for other computers connected to an Adapter.

The MegaPlug Adapters are now connected and ready to use, and the

Configuration Utility is loaded on the computers. Go to chapter 3, “Using the

Configuration Utility” for information about changing the default configuration

settings of the Adapter.
