ActiGraph CentrePoint Data Hub Manuel utilisateur
User Manual
CentrePoint Data Hub
CentrePoint Data Hub | Revision: 0 | Released: 07/11/2017
2actigraphcorp.com
User Manual
CentrePoint Data Hub
CentrePoint Data Hub | Revision: 0 | Released: 07/11/2017
Contents
Overview…………………………………………………………………………………………………………………………………………………………………
Getting Started……………………………………………………………………………………………………………………………………………………………
Assigning the CentrePoint Data Hub to a Subject………………………………………………………………………………………………………………………
Operating the CentrePoint Data Hub……………………………………………………………………………………………………………………………………
Managing the CentrePoint Data Hub in CentrePoint……………………………………………………………………………………………………………………
Technical Details…………………………………………………………………………………………………………………………………………………………..
Troubleshooting…………………………………………………………………………………………………………………………….……………………………
2
3
4
6
8
10
12
Overview
CentrePoint Data Hub
The CentrePoint (CP) Data Hub from ActiGraph is a home-based communication gateway capable of transmitting both one-minute
epoch level and raw data captured by ActiGraph GT9X Link activity monitors to the CentrePoint cloud software platform via 3G cellular
network. The CP Data Hub also functions as a charging hub for ActiGraph Link activity monitors. This User Manual contains instructions
on how to set up, operate, and manage your CentrePoint Data Hub.
3actigraphcorp.com
Getting Started
Your CP Data Hub package contains the items listed below. A CentrePoint user account and ActiGraph Link activity monitor are required
to use the CentrePoint Data Hub and must be purchased separately.
You will also need:
CentrePoint Data Hub Power Cable
USB Cable
ActiGraph Link and Accessories (Not Included)
Link Dock
CentrePoint Account (Not Included)
4actigraphcorp.com
Pair the CP Data Hub with the ActiGraph Link
Follow the instructions in the CentrePoint User Manual or your custom Site Manual to assign the ActiGraph
Link activity monitor to a new subject in CentrePoint. After the assignment is complete, remove the Link from
the dock (connected to your PC).
Connect the adapter end of the power cable into the back of the CP Data Hub and plug the other end into a
wall outlet, using the international adapter if necessary.
The blue LED status light on the back of the CP Data Hub will flash during startup. It may take up to 20
seconds for the LED to begin to flash. Once the CP Data Hub connects to the cellular network, the blue LED
will stay on solid.
Connect the Link dock to the USB port on the CP Data Hub using the USB cable.
Insert the Link into the dock connected to the CP Data Hub. Once connected, a progress wheel will appear
on the Link screen indicating that data upload has begun. A checkmark will appear on the Link screen when
this is complete.
Assigning the CentrePoint Data Hub to a Subject
11
2
3
4
5
Power Status LightUSB Port
5actigraphcorp.com
Assigning the CentrePoint Data Hub to a Subject (Continued)
2Verify connection and upload status in CentrePoint
On the CentrePoint website, go to the “Subject Details” page and select “Subject Timeline.”
Verify that an upload has occurred via Data Hub USB.The ActiGraph Link and the CP Data Hub are now paired.
Remove the ActiGraph Link from the dock. Give the activity monitor, CP Data Hub, dock, and cables to the
subject and provide specific instructions for wearing, charging, and uploading data.
1
2
3
6actigraphcorp.com
Operating the CentrePoint Data Hub
Setting up the CP Data Hub in the home (instructions for subjects)
The CP Data Hub should be placed in a location where the subject spends a lot of time.
Connect the adapter end of the power cable into the back of the CP Data Hub and plug the other end into a
standard wall outlet, using the international adapter if necessary.
The blue LED status light on the back of the CP Data Hub will flash during startup. It may take up to 20 seconds
for the LED to begin to flash. Once the CP Data Hub connects to the cellular network, the blue LED will stay
on solid.
If the CP Data Hub cannot connect to the cellular network (or if it loses connection), the blue LED will continue
to flash. If this continues for more than two minutes or occurs throughout the day, move the CP Data Hub
to a new location.
Once the CP Data Hub is successfully connected, plug the Link dock into the USB port on the side of the CP
Data Hub.
1
2Wireless uploads (Bluetooth®)
If the CP Data Hub has been configured for wireless Bluetooth® uploads, it will periodically attempt to connect to
the ActiGraph Link wirelessly when the activity monitor is within range, which is approximately 30 meters. Once
connected, the CP Data Hub will download one-minute epoch summary data from the ActiGraph Link.
If a full day’s worth of data is downloaded, it will be immediately transferred to the CentrePoint system via 3G
cellular network.
If only a partial day is downloaded via Bluetooth®, the CP Data Hub will store that data until a full day is queued.
The data will then be uploaded to CentrePoint.
Note: CentrePoint Data Hub default settings require a full day of data before an upload is initiated, however this can be
congured for each study.
1
2
3
4
5
1
2
The CP Data Hub performs wireless uploads of summary data using Bluetooth®, and raw data is uploaded via USB
connection. Please reference this Helpdesk article for more information about the difference between raw and
summary data.
https://actigraph.desk.com/customer/portal/articles/2830405-raw-and-summary-data-explained
7actigraphcorp.com
3
Operating the CentrePoint Data Hub (Continued)
Raw data uploads (USB)
The CP Data Hub can be used to upload raw actigraphy data using the Link dock.
Insert the ActiGraph Link into the connected dock with the logo facing up. A progress wheel will appear on
the ActiGraph Link screen once the upload begins.
When the upload is complete, a checkmark will appear on the screen. This can take several minutes to several
hours, depending on how much data is on the device.The ActiGraph Link can now be removed from the dock.
Summary one-minute epoch data and the raw data file (if applicable) are immediately available in CentrePoint.
See "Viewing uploaded data" section below.
4Charging the activity monitor
The CP Data Hub charges the ActiGraph Link battery anytime it is placed in the connected dock.
During charging, an animated battery icon will appear on the ActiGraph Link screen and the charging dock
will display a yellow LED.
Charging is complete when the LED turns green.
If the dock displays a red LED, this indicates a charging problem. Remove and reinsert the activity monitor in
the dock.
It takes approximately 2-3 hours to charge a fully depleted battery.
1
2
3
1
2
3
4
Uploading Upload Completed
Charging Fully Charged
8actigraphcorp.com
Managing the CentrePoint Data Hub in CentrePoint
1Viewing upload details
All CP Data Hub data uploads (wireless and raw data) are instantly logged in the“Activity Feed”on the “Study
Home Dashboard” page.
To view detailed upload information for a subject, go to the “Subject Details” page and select “Subject
Timeline.” Each timestamped data upload is logged and the amount of new data, activity monitor battery
level, and upload source (CP Data Hub Bluetooth® or USB) are provided.
1
2
9actigraphcorp.com
Managing the CentrePoint Data Hub in CentrePoint (Continued)
2Viewing uploaded data
After the CP Data Hub performs a successful data upload (Bluetooth® or USB), the epoch summary data is
immediately available to view.
From the “Subject Details” page, select “Subject Data Report” from the dropdown list to view daily wear
compliance, calories, and steps. Select the date link to view minute by minute daily details.
1
2
10 actigraphcorp.com
Managing the CentrePoint Data Hub in CentrePoint (Continued)
If raw data has been uploaded via the CP Data Hub (USB), the file can be downloaded by going to the
“Subject Details” page and selecting the “Raw Data Downloads” tab. Select the desired file(s) and click
download. The raw data is stored in a .gt3x file, which can only be opened using the ActiLife desktop
analysis software.
3
Note: CentrePoint is a role-based system and certain user types can be congured to view wear compliance data only.
