ACTi B81 Manuel utilisateur

2014/01/13

Outdoor Dome

Mounting on the Wall with

Gang Box (Face Forward)

Installation Guide

For Models:

B81, B84, B85, B87

www.acti.com

Installation Guide

Table of Contents

Installation Procedures .....................................................3

Step 1: Prepare for Waterproof Installation............................................. 4

Step 2: Prepare the Camera for Installation ............................................ 5

Step 3: Install the Gang Box..................................................................... 7

Step 4: Install the Gang Box Converter ................................................... 8

Step 5: Connect the Cable(s).................................................................... 9

Waterproof Solution with Naked Cable ................................................... 9

Waterproof Solution with Conduit.......................................................... 12

Step 6: Install the Camera....................................................................... 16

Step 7: Connect to Network.................................................................... 17

Step 8: Access the Camera Live View.................................................... 17

Step 9: Adjust the Viewing Angle........................................................... 18

Step 10: Close the Dome Cover.............................................................. 19

Appendices.......................................................................20

How to Access the Camera Live View.................................................... 20

How to Connect a Power Adapter (Optional) ........................................ 27

How to Connect DI/DO Devices (Optional)............................................ 29

How to Connect Audio Devices (Optional)............................................ 32

Safety Information............................................................33

www.acti.com

Installation Guide

Installation Procedures

This guide describes the procedures in installing the camera on a Two-Gang Box which is

mounted on the wall.

With this type of installation, the following accessories and tools are required:

Gang Box (Two-Gang)

Gang Box Converter (PMAX-0804) with Bundled Screw Pack

Phillips Screwdriver

Network Cable

Flexible Conduit (if necessary)

www.acti.com

Installation Guide

Step 1: Prepare for Waterproof Installation

The camera comes with two (2) glands used for waterproof installation:

Cable Gland: For use with an Exterior-grade Ethernet cable. Exterior-grade Ethernet

cables are already waterproof. Note that throughout this documentation, this solution is

referred to as the Waterproof Solution with Naked Cable.

Conduit Gland: For use with a flexible conduit. This solution is recommended when an

exterior-grade Ethernet cable is not available or other cables, such as power adapter,

DI/DO devices, etc., will be connected to the camera. Note that throughout this

documentation, this solution is referred to as the Waterproof Solution with Conduit.

1. Determine the type of waterproof solution that is applicable to your installation requirements

and prepare the necessary accessories or purchase extra materials.

Cable Gland

Conduit Gland

For use with an Exterior-grade Ethernet

cable (not included in the package).

For use with 1/2” flexible conduit (not

included in the package)

www.acti.com

Installation Guide

2. From this point:

When doing the Waterproof Solution with Naked Cable, skip this step.

When doing the Waterproof Solution with Conduit, pull the network cable through

the flex conduit. If connecting other input/output devices or an external power

adapter, pull the cables through the flex conduit without connectors. The terminal

blocks will be attached once the cables pass through the camera hole later.

Step 2: Prepare the Camera for Installation

NOTE: To avoid scratches or leaving fingerprints on the dome cover, it is recommended to retain

the plastic covering the dome cover until the camera is completely installed. However, the plastic

has been removed on some of the pictures in this documentation to show clarity of the

procedures being described.

1. Remove the metal cap covering the bottom hole of the camera, and attach the cap to the side

hole to close it. The cable will be routed to pass this hole from the gang box later.

www.acti.com

Installation Guide

2. With the bundled hex screwdriver, loosen the three (3) screws securing the dome cover.

3. Carefully lift to open the dome cover and place it on the side of the camera.

NOTE: Do not abruptly lift the dome cover; it is attached to the camera with a spring wire.

4. If necessary, insert a memory card, with the metallic contacts facing down, into the card slot

of the camera. Push the card until it clicks into place.

www.acti.com

Installation Guide

Step 3: Install the Gang Box

Before installation, note that the gang box must be installed with the orientation as shown below:

Depending on your installation environment, the gang box can be installed on the wall or inside

the wall. If the gang box will be installed in the wall, route enough length of network cable or

flex conduit inside the wall to pass through the gang box slot.

NOTE: The succeeding procedures and images show how to do the camera installation with a

gang box installed inside the wall; same procedures apply if the gang box is on the wall.

1. Remove a knockout on the gang box where you want to route the network cable. If the gang

box will be installed in the wall, insert the network cable through this knockout at this point.

Using the Naked Cable Solution Using the Flex Conduit Solution

2. Install the gang box on or inside the wall with the orientation as shown above. If the gang

box is installed on the wall, insert the network cable through the knockout after installing

the gang box on the wall.

www.acti.com

Installation Guide

Step 4: Install the Gang Box Converter

The Gang Box Converter can be attached to the gang box by either of the following orientation:

The gang box will be on the upper side of the

converter. This orientation is recommended if

the camera is installed indoors or the gang

box is installed inside the wall.

The gang box will be on the lower side of the

converter. This orientation is recommended if

the gang box is installed on the wall and the

cable be routed along the wall. This way, the

cable will be routed with a downward position

which will be an added protection against

possible water leak.

Determine the most appropriate orientation for your installation environment.

NOTE: The succeeding procedures and images show how to do the camera installation with a

gang box installed inside the wall; same procedures apply if the gang box is on the wall.

1. Route the network cable to pass through the cable hole of the gang box converter.

NOTE: The image below shows the flex conduit through the gang box converter, same

procedure applies when using the naked cable.

www.acti.com

Installation Guide

2. Install the gang box converter onto the gang box using the screws included in the gang box

package. Note the screw holes to use to secure the converter to the gang box.

Step 5: Connect the Cable(s)

Follow the procedures to connect the cable(s) based on your selected waterproof solution:

Waterproof Solution with Naked Cable, see Waterproof Solution with Naked Cable

below.

Waterproof Solution with Conduit, see Waterproof Solution with Conduit on page

Waterproof Solution with Naked Cable

This section describes the procedures in using the bundled cable gland and an exterior-grade

Ethernet cable.

1. Disassemble the cable gland as shown below:

Body

(with Washer)

Sealing Insert

with Claw

Clamping

Nut

www.acti.com

Installation Guide

2. Insert the clamping nut into the Ethernet cable.

3. Insert the sealing insert with claw.

4. Attach the cable gland body to the hole of the camera.

5. Pull the network cable through the bottom hole of the camera.
