Actel ProASIC PLUS Manuel utilisateur

ProASICPLUS Evaluation Board

User’s Guide

QS_Tutorial_eval.book Page i Monday, January 13, 2003 1:08 PM

Actel Corporation, Sunnyvale, CA 94086

Printed in the United States of America

Part Number: 51700003-0

Release: December 2002

No part of this document may be copied or reproduced in any form or by any means

without prior written consent of Actel.

Actel makes no warranties with respect to this documentation and disclaims any im-

plied warranties of merchantability or fitness for a particular purpose. Information

in this document is subject to change without notice. Actel assumes no responsibil-

ity for any errors that may appear in this document.

This document contains confidential proprietary information that is not to be dis-

closed to any unauthorized person without prior written consent of Actel Corpora-

tion.

Trademarks

Actel and the Actel logotype are registered trademarks of Actel Corporation.

Adobe and Acrobat Reader are registered trademarks of Adobe Systems, Inc.

Liberty is a licensed trademark of Synopsys Inc. This product uses SDC, a Propri-

etary format of Synopsys Inc.

Libero is a trademark of Actel Corporation.

Mentor Graphics, Viewlogic, ViewDraw, MOTIVE, and ModelSim are registered

trademarks of Mentor Graphics, Inc.

Synplify and Synplicity are registered trademarks of Synplicity, Inc.

Verilog is a registered trademark of Open Verilog International.

WaveFormer Lite and SynaptiCAD are trademarks of SynaptiCAD, Inc.

Windows is a registered trademark and Windows NT is a trademark of Microsoft

Corporation in the U.S. and other countries.

All other products or brand names mentioned are trademarks or registered trade-

marks of their respective holders.

QS_Tutorial_eval.book Page ii Monday, January 13, 2003 1:08 PM

iii

Table of Contents

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Document Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Document Assumptions . . . . . . . . . . . . . . . . . . . . . . . . . . 5

1Contents and System Requirements . . . . . . . . . . . . . . . .7

Evaluation Kit Contents . . . . . . . . . . . . . . . . . . . . . . . . . .7

System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

2Setup and Self Test . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Software Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Testing the Evaluation Board. . . . . . . . . . . . . . . . . . . . . . . .9

Programming the Test file . . . . . . . . . . . . . . . . . . . . . . . . 10

3Hardware Description . . . . . . . . . . . . . . . . . . . . . . . . 11

Power Supplies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Programming Headers . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Clock Circuits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

LED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

ABoard Connections . . . . . . . . . . . . . . . . . . . . . . . . . 17

BBoard Schematics . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

CProduct Support . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Actel U.S. Toll-Free Line . . . . . . . . . . . . . . . . . . . . . . . . . 35

Customer Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Customer Applications Center . . . . . . . . . . . . . . . . . . . . . . 36

Guru Automated Technical Support . . . . . . . . . . . . . . . . . . . 36

Web Site. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

FTP Site . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Contacting the Customer Applications Center . . . . . . . . . . . . . . 36

Worldwide Sales Offices . . . . . . . . . . . . . . . . . . . . . . . . . 38

QS_Tutorial_eval.book Page iii Monday, January 13, 2003 1:08 PM

QS_Tutorial_eval.book Page iv Monday, January 13, 2003 1:08 PM

Introduction

Thank you for purchasing Actel’s ProASICPLUS Evaluation Board.

The purpose of this user’s guide is to provide you with information so you can

easily evaluate the ProASICPLUS devices.

This is the first release of the user’s guide. The most up-to-date version of this

guide is available at:

http://www.actel.com/products/tools/hw.html

Document Contents

Chapter 1 - Contents and System Requirements describes the

contents of the ProASICPLUS Evaluation Kit.

Chapter 2 - Setup and Self Test describes how to setup the ProASICPLUS

Evaluation Board and how to perform a self test.

Chapter 3 - Hardware Description describes the components of the

ProASICPLUS Evaluation Board.

Appendix A - Board Connections lists a board connection table.

Appendix B - Board Schematics show illustrations of the ProASICPLUS

Evaluation Board.

Appendix C - Product Support describes our support services.

Document Assumptions

This user’s guide assumes the following:

• You intend to use Actel’s Libero software.

• You have installed and are familiar with Actel’s Libero software.

• You are familiar with the VHDL or Verilog hardware description language.

• You are familiar with UNIX workstations and operating systems or PCs and

Windows operating systems.

QS_Tutorial_eval.book Page 5 Monday, January 13, 2003 1:08 PM

QS_Tutorial_eval.book Page 6 Monday, January 13, 2003 1:08 PM

Contents and System Requirements

This chapter describes the differences between the three versions of the

ProASICPLUS evaluation board. This chapter also details the contents of the

ProASICPLUS evaluation kit and provides power supply and software system

requirements.

Evaluation Kit Contents

The ProASICPLUS evaluation kit has three board versions.

Note: There is no socket on these boards.

APA-EVAL-BRD1

This board contains all the surrounding circuitry, but no APA device. For this

board, it is assumed that you will acquire a device and solder it to the board

yourself. This allows you to use the board with any device in the APA family.

APA-EVAL-BRD300

Same as BRD1 but with an APA300 device mounted.

APA-EVAL-BRD075

Same as BRD1 but with an APA075 device mounted.

When you purchase any of the above board versions, you also receive the

following:

• Evaluation board - one of the three listed above

• The ProASICPLUS Evaluation Board User’s Guide

•CustomerLetter

• CD with design examples

For the CD contents, review the ReadMe.doc file at the top level of the

CD. As more design examples become available, the CD contents will

change. For the latest design examples, refer to the Hardware Tools

section of the Actel website:

http://www.actel.com/products/tools/hw.html

QS_Tutorial_eval.book Page 7 Monday, January 13, 2003 1:08 PM

Chapter 1: Contents and System Requirements

Power Supply and Software Requirements

This section describes power supply and software requirements for the

ProASICPLUS evaluation kit.

Power Supply The ProASICPLUS evaluation board requires the following:

• Wall mount power supply

• 9V, 500mA supply with 2.1mm female connector P5 type

• Digikey part number T413-P5P-ND for US

• Digikey part number T408-P5P-ND for Europe

Software Each ProASICPLUS evaluation board requires a different version of the

software.

APA-EVAL-BRD075

This board can use the free evaluation Libero Silver version, which

does not include simulation. To include simulation, use the Libero Gold

version.

APA-EVAL-BRD300

This board requires a full Libero Platinum license.

APA-EVAL-BRD1

With the blank board, you can select any device from the ProASICPLUS family

in a 208 PQFP footprint and solder it to the board yourself.

Use the appropriate software for the device you choose. For software support

details, refer to the Actel Website:

http://www.actel.com/products/tools/support.html

QS_Tutorial_eval.book Page 8 Monday, January 13, 2003 1:08 PM

Setup and Self Test

Software Installation

Since this package does not include software, this guide does not provide

software installation instructions. For software installation instructions, refer to

the Actel Installation and Licensing Guide at:

http://www.actel.com/products/tools/libero/docs.html

Testing the Evaluation Board

If the evaluation board is shipped directly from Actel, it contains a test program

that determines if the board works properly.

To test the evaluation board:

1. Supply power to the board.

2. Turn on the ON/OFF switch.

3. Perform the actions described in Table 2-1.

Table 2-1. Evaluation Board Test

Action Result Pass/Fail

Press PB1 multiple times, but not

too fast A sequence of LEDs light up Pass

Press and hold SW1 All LEDs are unlit Pass

Press and hold SW2 All LEDs light up except DS1 Pass

Press and hold SW3

A random sequence of LEDs

light up while you hold the

switch

Pass

Press and hold SW4 The LED is lit/unlit in a

01101010 pattern Pass

Any two switches are pressed

together Creates a 00100110 pattern. Pass

QS_Tutorial_eval.book Page 9 Monday, January 13, 2003 1:08 PM

Chapter 2: Setup and Self Test

Programming the Test file

If you want to retest the evaluation board, you can reprogram the board using

the test program at any time. Use the STAPL file test.stp or the bitstream file

test.bit. These files are included on the Evaluation Kit CD. Table 2-2 describes

the actions you should perform when retesting your evaluation board.

This design is currently implemented for the APA300 device. If you have a

device of a different size, you can recompile the design into other device sizes.

The design files are available under actelprj/eval in the Evaluation Kit CD.

For instructions on programming the device using Flash Pro, refer to the Flash

Pro User’s Guide at:

http://www.actel.com/techdocs/manuals/docs/flashproUG.pdf

Table 2-2. Retesting the Evaluation Board

Action Result Pass/Fail

Press PB1 multiple

times, but not too fast

Count sequence should be visible on

the LED Pass

Press and hold SW1 All LEDs are unlit Pass

Press and hold SW2 All LEDs are lit Pass

Press and hold SW3 Count sequence runs while you hold

the switch Pass

Press and hold SW4 LED is lit/unlit alternately in a

10101010 pattern Pass

Any two switches are

pressed together Creates a 00110011 pattern Pass

QS_Tutorial_eval.book Page 10 Monday, January 13, 2003 1:08 PM
