ACT 10 Digital Keypad
Product Overview
The ACT 10 digital keypad is a sturdy and
durable unit made from vandal resistant die
cast zinc with backlit stainless steel keys.
This multi-purpose keypad caters for access
control, door monitoring and interlock
applications.
Main Features
10 User codes
2 Output relays
2 doors, 2 user groups
Interlock, fire alarm input, door monitoring
Surface or Flush mount options
Indoor or outdoor (IP54)
Zinc diecast housing, stainless steel keys
Front and back tamper
Backlit keypad
Installation / Specification Guidelines
The ACT 10 requires an operating voltage
of 12 to 24 volts AC or DC. For full functionality
use 12 volts DC supply.
2 x 5 amp relay outputs
The ACT 10 can be installed either
indoors or outdoors (IP54)
Operating Temperature: -10 to +50 C
There are flush mounting and weather shield
accessories available for this product
●
●
●
●
●
●
●
●
●
●
●
●
●
●
ACT 10 System Schematic
ACT 10
PSU
EXIT
220/240 Volts AC
Tamper 3 Inputs (100mA)
3 Outputs (100mA)
12/24 Volts AC/DC
ACT 10 Digital Keypad
Product Specification
Operating Voltage: 12/24 Volts AC/DC
Current Consumption: 40/120 mA
Weight: 700 grams
Operating Temperature: -10 to +50 C
Dimensions (HxWxD): 138 x 87 x 37 mm
Mounting: Surface or Flush
Installation: Indoor or Outdoor
Access Control Technology Unit C1, South City Business Park, Tallaght, Dublin 24, Ireland.
ACT 10 Digital Keypad
ACT 10
Weather Shield
ACT 10
Flush Kit
ACT Standalone products comparison chart
Feature
Doors
Users
User Groups
Master Slave Operation
Proximity
Pin
Pin & Prox
Pin or Prox
Keypad Backlighting
Interlock
Door Monitoring
Fire Alarm Override
Master Slave Operation
Toggle Mode
Door Relay Output
Programmable Inputs
Programmable Outputs
Programmable Inputs/
Outputs
Push to release button
input
Tamper Output
12-24volt DC or
AC Input*
IP Rating
* ACTsmart2 units require a DC supply when programmable input / outputs or master slave operation are used.
ACT 5
1
10
Yes
Yes
Yes
5 amp
Yes
Yes
IP67
ACT 5 Prox
1
50
Yes
Yes
Yes
Yes
Yes
Yes
5 amp
Yes
Yes
IP67
ACT 10
2
10
2
Yes
Yes
Yes
Yes
Yes
Yes
5 amp
2
2
Yes
Yes
Yes
IP54
ACTsmart2
1070
1
1000
1
Yes
Yes
Yes
Yes
Yes
Yes
Yes
5 amp
1
2
Yes
Yes
Yes
IP67
ACTsmart2
1080
1
1000
1
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
5 amp
1
2
Yes
Yes
Yes
IP67
ACTsmart2
1090
1
1000
1
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
5 amp
1
2
Yes
Yes
Yes
IP67
ACT 10 Flush Kit
Product Specification
Front Plate
Dimensions (HxWxD): 185 x 130 x 3 mm
Back Box
Dimensions (HxWxD): 150 x 90 x 40 mm
Weight: 750 grams
ACT 10 Weather Shield
Product Specification
Dimensions (HxWxD): 140 x 92 x 74 mm
Weight: 475 grams
