ACT'L eWON4002 Manuel utilisateur
eWON4002™
Ethernet Gateway
Remote Access Server (RAS)
Programmable Industrial Router (PIR)
Datalogger
Integrated Input/Output
3 serial Ports
INSTALLATION GUIDE
Rev. 2.04 -
3/18/05
Cool
Internet
Telecontrol
Solutions
eWON4002™ Installation Guide
Table Of Contents
1 Product description ............................................................... 1
1.1 Introduction...............................................................................1
1.2 General specification of the hardware platform .........................1
1.3 Ethernet Gateway ......................................................................1
1.4 RAS Modem & PIR ......................................................................2
1.4.1 Remote Access Server functions..................................................... 2
1.4.2 Programmable Industrial Router functions .................................... 2
1.5 Datalogger .................................................................................2
1.6 Typical applications....................................................................2
1.7 Part Numbers and internal options.............................................2
1.8 External accessories ..................................................................3
2 Structure of the eWON® technical documentation................. 4
3 Housing and markings ........................................................... 5
3.1 Housing......................................................................................5
3.2 Markings ....................................................................................6
3.3 Applicable directives, standards and compliance .......................6
3.4 Equipment information and versions..........................................7
3.5 Mechanical outline .....................................................................7
3.6 Mounting and environmental conditions ....................................8
3.7 Preparing the installation...........................................................9
3.8 Specifications for external power supply selection.....................9
3.8.1 Auto fuse........................................................................................ 9
4 Front panel control LEDs...................................................... 10
5 Communication interfaces and I/Os .................................... 11
5.1 Ethernet Port ...........................................................................11
5.2 Embedded PSTN Modem...........................................................11
5.3 Embedded GSM/GPRS Modem..................................................11
5.3.1 Recommendations for the GSM/GPRS antenna............................. 12
5.4 Serial ports ..............................................................................13
5.4.1 Serial port #1 .............................................................................. 13
5.4.2 Serial port #2 .............................................................................. 14
5.4.3 Serial port #3 .............................................................................. 15
5.5 Digital Inputs ...........................................................................16
5.6 Digital Outputs.........................................................................17
5.6.1 Open collector Digital Output ....................................................... 17
5.6.2 Relays .......................................................................................... 18
5.7 Analog Inputs ..........................................................................18
5.7.1 Configurable standard Analog Inputs (AI1 - AI4)......................... 18
5.7.2 Resistive Temperature Detector Inputs ........................................ 19
6 Communicating with the eWON® ........................................ 20
6.1 By Ethernet ..............................................................................20
eWON4002™ Installation Guide
Table Of Contents
6.2 By phone line or GSM ...............................................................20
6.2.1 Under Windows 98, NT and 2000.................................................. 20
6.2.2 Under Windows XP ....................................................................... 21
7 IP parameters configuration................................................ 22
8 Technical support ................................................................ 23
8.1 Resets ......................................................................................23
8.1.1 User Reset .................................................................................... 23
8.1.2 Factory Reset ............................................................................... 23
9 Appendix: Pinouts and connections ..................................... 24
9.1 Power Supply ...........................................................................24
9.2 Ethernet ...................................................................................25
9.2.1 Direct connection ......................................................................... 25
9.2.2 Connection over hub/router ......................................................... 26
9.3 RJ45 connector ........................................................................27
9.4 Input/Outputs .........................................................................28
9.4.1 DI / DO connector ........................................................................ 28
9.4.2 Analog Input ................................................................................ 29
9.4.3 Relays output ............................................................................... 30
9.4.4 Digital input ................................................................................. 31
9.5 Serial Ports ..............................................................................32
9.5.1 Pinout serial ports 1 and 3 (according to mode): ......................... 33
9.5.2 Pinout serial port 2....................................................................... 33
9.6 Unitelway/Modbus serial cable ................................................34
9.7 PSTN phone line connector ......................................................35
eWON4002™
Installation Guide
page 1 of 35
ver 2.04
1 Product description
1.1 Introduction
The eWON4002™ is a compact version from a complete range of Ethernet/Internet gateways also known as
“Programmable Industrial Routers” (PIR). See our web site http://www.ewon.biz to get further information about the
eWON® range. The eWON® is a terminal that enables access to technical data, whatever their format is. The
eWON® is configurable by means of web pages. It is secure because it meets the toughest industrial standards, and
it provides restricted access features (required in open networks). The hardware platform of the eWON4002™ is a
standard eWON® that embeds a modem (PSTN or GSM/GPRS).
The eWON® range supports the TCP/IP and PPP protocols. This brings you all the benefits of an universally
recognized standard network. It also allows you to use popular software tools like Internet Explorer, FTP client,
SNMP Manager, Mail Recipient (TCP)… and thus to reduce significantly your costs (implementation and
ownership).
1.2 General specification of the hardware platform
• Processor ARM clocked @ 75Mhz, 8Mb SDRAM, 8 Mb Flash
• Battery backed up Real Time Clock (RTC) with 10 years autonomy
• External power supply 12-24 VDC +/- 20%
• 1 Ethernet port 10/100Mb BaseTx
• 1 isolated configurable serial port (RS232/RS422/RS485)
• 1 non-isolated configurable serial port (RS232/RS422/RS485)
• 1 RS232 serial port with all control lines connected
• 8+1 digital inputs (DI)
• 2+1 digital outputs (DO)
• 4 analog inputs (AI) configurable in 0-10V or 0-20mA
• 2 Resistive Temperature Detector inputs (RTD) to fit PT100 2 wires probes
• 1 Internal Temperature probe
• DIN rail mounting compliant with EN50022 (latch)
• Environmental conditions (operating):
• Ambient T°: from 0°C to +50°C
• Humidity: from 0 to 80% non condensing
1.3 Ethernet Gateway
• Compatibility with MODBUS, UNITELWAY, NETMPI and DF1 protocols
• Data acquisition
• Web server – fully customizable web pages
• Programmable by BASIC scripts
• Alarm management
• Report generation
eWON4002™
Installation Guide
page 2 of 35
ver 2.04
1.4 RAS Modem & PIR
1.4.1 Remote Access Server functions
• Remote Access Server (RAS) and TCP/IP Server
• PAP/CHAP Authentication
• Login/password
• Remote network access
• User access control
• Security: Integrated firewall (NAT, IP filtering, …)
• Conventional and internet callback
1.4.2 Programmable Industrial Router functions
• Automatic routing of protocols
• Pre-configured routing tables
• Programmable routing from I/O and Tag names (BASIC)
1.5 Datalogger
• Internal cyclic database - up to 139264 points
• Export of data in binary or text format, by FTP or as an Email attachment
1.6 Typical applications
• Alarm management
• Sending alarms by network, phone, Email and/or SMS
• Remote measurements, loop back, control and monitoring
• Local or remote Human Machine Interface (SCADA)
• Predictive and operational maintenance
• Diagnosis and machinery status control
• Stock and vessel level monitoring
• Process and machinery activity logs
• Commissioning support
• Remote programming
• Interface for Application Service Providers (ASP)
• Datalogging
1.7 Part Numbers and internal options
Part Number structure of the eWON® product range:
EWaabcc/xy
Where (examples):
• aa = Type of hardware platform:
• 05 = eWON500™
• 21 = eWON2001™
• 41 = eWON4001™
• 42 = eWON4002™
• 12 = eWON1002™
• b = Power supply:
• 1 = Universal 110-230VAC
• 2 = Low voltage DC power supply
eWON4002™
Installation Guide
page 3 of 35
ver 2.04
• cc= Communication:
• 01 = NO modem (Ethernet only)
• 02 = PSTN modem
• 05 = GSM/GPRS modem
• /xy = Options:
The only option of the eWON4002™ is the modem type.
Available Part Numbers for the eWON4002™ platform:
Table 1: List of available Part Numbers
1.8 External accessories
External accessories available for the eWON4002™ platform:
Table 2: Available external accessories
Type/Description Part Number
eWON4002™/Ethernet EW42201
eWON4002™/PSTN33 (PSTN modem) EW42202
eWON4002™/GSM/GPRS (GSM/GPRS modem) EW42205
Description Part Number
Starter Kit (Eth cables: 1 straight, 1 crossed + CDROM) EW40901
Antenna GSM/GPRS (dual band fixing by screw) EW40902
Antenna adapter SMA-M/FME-M EW40908
Serial cable 2m for Schneider SUBD9-MiniDIN EW40906
eWON4002™
Installation Guide
page 4 of 35
ver 2.04
2 Structure of the eWON® technical documentation
The eWON® technical documentation is structured in 4 different levels as shown in the table below:
Table 3: eWON®technical documentation different levels
All those manuals are available for download in pdf format on the eWON® website: http://www.ewon.biz.
Level Title Contents
1
Hardware Installation
Guide (the present
document)
(~40pp)
Detailed description of the hardware platform, of its interfaces, available
options and accessories. Hardware specifications, conformity to
standards. Installation recommendations and connectors pinout. Step-by-
step tutorial to establish first communications and make the IP
configuration.
Exists for the following platforms:
• eWON500™
• eWON2001™
• eWON4001™
• eWON4002™
• eWON1002™
2
Software Getting
Started
(~30pp)
Manual to start using the basic functions of the eWON®software. Covers
most usual applications.
3Software User Manuals
(~250pp)
Exhaustive manual to use all advanced functions of the eWON®. Contains
BASIC and HTML syntax.
(Exists for all platforms)
4Application Notes
Technical Notes
• Unitelway topology Gateway XIP
• Unitelway for Schneider PLC
• Gateway MPI for Siemens PLC and Gateway for IP devices
• Etc, etc.
eWON4002™
Installation Guide
page 5 of 35
ver 2.04
3 Housing and markings
3.1 Housing
Figure 1: Housing, front view
Figure 2: Housing, bottom view
Status leds
Ethernet port
10/100 BaseTx
Phone line
Reset button
Configurable
serial port 1
Serial port 2
Din-rail latch
Configurable
serial port 3
Power supply
12-24 VDC
Digital I/O
connector
Analog input
connector
Relay
connector
Serial port 3 dip
switch
Front
Back
eWON4002™
Installation Guide
page 6 of 35
ver 2.04
3.2 Markings
The identification label of the eWON® stands on the left hand side of the housing. The label is composed of the
following fields:
Figure 3: eWON® Label
The eWON® Serial Number (SN) is an important traceability tool for both the user and the manufacturer. Therefore,
next to the product label, each eWON® has its serial number stored in the flash memory. This SN is also used in
order to scan the network for eWONs® and to assign its IP address, subnet mask and gateway. For more details,
See “Equipment information and versions” on page 7.
3.3 Applicable directives, standards and compliance
• 93/68/EEC European directive for CE-mark
• 73/23/EEC European directive for the safety of low voltage equipment (LVD) – Applicable standard is EN60950
A1+A4+A11
• 89/336/EEC amended by 92/31/EEC European directives for the electromagnetic compatibility (EMC) – Applicable
standards EN55022:94 A1, A2 (emissions) and EN55024:98 (immunity)
• UL/CSA certification in progess (UL60950)
Serial number
0504 = year+week
0001 = sequential number
89 = suffix eWON4002™
COM type
../33.6 = PSTN modem at
33.6 kb
../GPRS = GSM modem
(GPRS compatible)
Required power supply
The power supply must be
limited to max 300mA and
be SELV-compliant (safety
voltage)
eWON4002™
Installation Guide
page 7 of 35
ver 2.04
3.4 Equipment information and versions
The eWON® hardware and software revisions can be checked via a web browser on the eWON® server (see
Communicating with the eWON® on page 20). Once logged onto the eWON®, clicking on the eWON® logo shows
these revisions:
Figure 4: eWON® info page details
3.5 Mechanical outline
Figure 5: Mechanical outline
IP Address
Software
version
Serial
Number
System Info
(I/O, Modem,
free memory)
106 mm
51mm
120mm
Table des matières
Autres manuels ACT'L Porte
Manuels Porte populaires d'autres marques
LST
LST M500RFE-AS Manuel utilisateur
Kinnex
Kinnex Media Gateway Manuel utilisateur
2N Telekomunikace
2N Telekomunikace 2N StarGate Manuel utilisateur
Mitsubishi Heavy Industries
Mitsubishi Heavy Industries Superlink SC-WBGW256 Manuel utilisateur
ZyXEL Communications
ZyXEL Communications ZYWALL2 ET 2WE Manuel utilisateur
Telsey
Telsey CPVA 500 - SIP Manuel utilisateur
