SERIES IP440 INDUSTRIAL I/O PACK 32-CHANNEL ISOLATED DIGITAL INPUT MODULE
___________________________________________________________________________________________
- 2 -
The information contained in this manual is subject to change
without notice. Acromag, Inc. makes no warranty of any kind with
regard to this material, including, but not limited to, the implied
warranties of merchantability and fitness for a particular purpose.
Further, Acromag, Inc. assumes no responsibility for any errors
that may appear in this manual and makes no commitment to
update, or keep current, the information contained in this manual.
No part of this manual may be copied or reproduced in any form,
without the prior written consent of Acromag, Inc.
Table of Contents Page
1.0 GENERAL INFORMATION........................................... 2
KEY IP440 FEATURES................................................. 2
INDUSTRIAL I/O PACK INTERFACE FEATURES........ 3
SIGNAL INTERFACE PRODUCTS............................... 3
INDUSTRIAL I/O PACK SOFTWARE LIBRARY........... 3
2.0 PREPARATION FOR USE............................................ 3
UNPACKING AND INSPECTION..................................
CARD CAGE CONSIDERATIONS................................
BOARD CONFIGURATION...........................................
CONNECTORS.............................................................
IP Field I/O Connector (P2)...........................................
Noise and Grounding Considerations............................
IP Logic Interface Connector (P1)..................................
3.0 PROGRAMMING INFORMATION................................. 5
ADDRESS MAPS.......................................................... 5
Standard (Default) Mode Memory Map.......................... 6
Enhanced Mode Memory Map....................................... 6
REGISTER DEFINITIONS............................................. 7
THE EFFECT OF RESET.............................................. 11
IP440 PROGRAMMING................................................ 11
Basic Input Operation.................................................... 11
Enhanced Operating Mode............................................ 11
Event Sensing............................................................... 11
Change-Of-State Detection............................................ 12
Debounce Control.......................................................... 12
Interrupt Generation....................................................... 12
Programming Example.................................................. 12
4.0 THEORY OF OPERATION............................................ 13
IP440 OPERATION………………………....................... 13
LOGIC/POWER INTERFACE……………...................... 14
5.0 SERVICE AND REPAIR................................................ 14
SERVICE AND REPAIR ASSISTANCE........................ 14
PRELIMINARY SERVICE PROCEDURE...................... 14
6.0 SPECIFICATIONS......................................................... 14
GENERAL SPECIFICATIONS....................................... 14
INPUTS......................................................................... 15
INDUSTRIAL I/O PACK COMPLIANCE........................ 15
APPENDIX.................................................................... 15
CABLE: MODEL 5025-550. & 5025-551........................ 15
CABLE: MODEL 5029-900............................................ 15
TERMINATION PANEL: MODEL 5025-552................... 16
TERMINATION PANEL: MODEL 5029-910................... 16
TRANSITION MODULE: MODEL TRANS-GP............... 16
DRAWINGS Page
4501-434 IP MECHANICAL ASSEMBLY...................... 17
4501-593 IP440 FIELD CONNECTIONS...................... 17
4501-603 IP440/445 LOOPBACK CONNECTIONS...... 18
4501-594 IP440 BLOCK DIAGRAM.............................. 18
4501-462 CABLE 5025-550 (NON-SHIELDED)............ 19
4501-463 CABLE 5025-551 (SHIELDED)..................... 19
4501-464 TERMINATION PANEL 5025-552................. 20
4501-465 TRANSITION MODULE TRANS-GP............. 20
IMPORTANT SAFETY CONSIDERATIONS
It is very important for the user to consider the possible adverse
effects of power, wiring, component, sensor, or software failures
in designing any type of control or monitoring system. This is
especially important where economic property loss or human life
is involved. It is important that the user employ satisfactory
overall system design. It is agreed between the Buyer and
Acromag, that this is the Buyer's responsibility.
1.0 GENERAL INFORMATION
The Industrial I/O Pack (IP) Series IP440 module provides 32
channels of isolated digital inputs for interfacing to the VMEbus or
ISAbus, according to your carrier board. Four units may be
mounted on a single carrier board to provide up to 128 inputs per
system slot. Inputs of this module are bipolar and can be used to
sense positive or negative voltages in 3 ranges according to the
model:
MODEL INPUT RANGE THRESHOLD
IP440-1 ±4V to ±18V DC or AC peak ±4V Max
IP440-2 ±16 to ±40V DC or AC peak ±16V Max
IP440-3 ±38 to ±60V DC or AC peak ±38V Max
MODEL OPERATING TEMPERATURE RANGE
IP440-X 0 to +70°C
IP440-XE -40 to +85°C
The inputs normally function as independent input level
detectors without interrupts. However, each input line includes
built-in event sense circuitry with programmable polarity,
debounce, and interrupt support. Inputs also include hysteresis
for increased noise immunity. The IP440 utilizes state of the art
Surface-Mounted Technology (SMT) to achieve its wide
functionality and is an ideal choice for a wide range of industrial
I/O applications that require a high-density, highly reliable, high-
performance interface at a low cost.
KEY IP440 FEATURES
•High Channel Count - Provides programmable monitor and
control of 32 optically-isolated input points. Four units
mounted on a carrier board provide 128 isolated input points
in a single VMEbus or ISAbus (PC/AT) system slot.
•High-Speed/0 Wait States - No wait states are required for
all read/write cycles (all cycles complete in 250ns) and hold
states are supported.
•Wide Range Bipolar Input Voltage - Three model ranges
provide interface capability for bipolar voltages from ±4 to
±60V DC or AC peak (see Specifications section).
•Optically Isolated - Individual bipolar opto-couplers provide
isolation. There are four groups (ports) of 8 channels each
which include separate port commons to ensure port-to-port
isolation. Individual ports are isolated from each other and
from the logic.
•Programmable Polarity Event Interrupts - Interrupts are
software programmable for positive (low-to-high) or negative
(high-to-low) input level transitions on all 32 channels.
Using two channels per input, change-of-state transitions
may also be configured.
•Input Hysteresis - Isolated inputs include hysteresis for
increased noise immunity.
