ACME PLB-114S Manuel utilisateur
Model: PLB-114S
Universal
Wall Bracket
www.acme.eu
www.acme.eu
3
GB 4 Installation Instruction 88 Warranty card
LT 11 Montavimo instrukcija 89 Garantinis lapas
LV 19 Uzstādīšanas instrukcija 90 Garantijas lapa
EE 26 Paigaldusjuhend 91 Garantiileht
PL 32 Instrukcja instalacji 92 Karta gwarancyjna
DE 39 Installationsanleitung 93 Garantieblatt
FI 46 Asennusohjeet 94 Takuulomake
SE 53 Installation Instruktion 95 Garantisedel
RO 60 Instrucţiuni de montare 96 Fişa de garanţie
BG 67 Инструкции за монтаж 97 Гаранционен лист
RU 74 Инструкция по установке 98 Гарантийный талон
UA 81 Інструкція по установці 99 Гарантійний лист
4
GB
Unpacking instructions
• Carefully open the carton, remove contents and lay out on cardboard
or other protective surface to avoid damage.
• Check package contents against the Supplied Parts List in the next
page to assure that all components were received undamaged. Do
not use damaged or defective parts.
• Carefully read all instructions before attempting installation.
Important safety information
Install and operate this device with care. Please read this instruction
before beginning the installation, and carefully follow all instructions
contained herein. Use proper safety equipment during installation.
Please call a qualied installation contractor for help if you:
• If you don’t understand these directions or have any doubts about the
safety of the installation.
• If you are uncertain about the nature of your wall, consult a qualied
installation contractor.
Do not use this product for any purpose or in any conguration not
explicitly specied in this instruction. We hereby disclaim any and all
liability for injury or damage arising from incorrect assembly, incorrect
mounting, or incorrect use of this product.
5
GB
ThisTV mount must be securely attached to the vertical wall.
If the mount is not properly installed it may fall, resulting in
possible injury and/or damage.
Tools Required •5/32"(4mm) Drill Bit
•Screwdriver
•3/8”(10mm)
Masonry Bit
•Stud Finder
•Wrench or Socket Set
• Carpenter’s Level
Note: The mounting components and hardware supplied in this package
are not designed for installations to walls with steel studs or to cinder block
walls. If the hardware you need for your installation is not included, please
consult your local hardware store for proper mounting hardware for the
application.
WARNING
6
GB
Supplied parts list
7
GB
Mounting the monitor
brackets to a TV with flat back
First of all, make sure the diameter of the Bolt (d,e,f,g) your TV requires.
Once you have determined the correct diameter, please see the relative
diagram as below. You will thread the Bolt into the TV using the correct
Lock Washer (l,m,n,o) and Washer (r,s). Please make sure the Monitor
Brackets (b,c) are vertically centered and level with each other.
M4 Diameter Bolt M6 Diameter Bolt
M5 Diameter Bolt M8 Diameter Bolt
Diagram 1A
8
GB
Mounting the monitor
brackets to a TV with curved
back
First of all, make sure the diameter of the Bolt (h,i,j,k) your TV requires.
Once you have determined the correct diameter, please see the relative
diagram as below. You will thread the Bolt into the TV using the correct
Lock Washer (l,m,n,o), Washer(r,s) and spacer(p,q). For the M4 or M5
diameter bolt, you will need another M4/M5 Washer between the
Monitor Bracket and the Spacer. Please make sure the Monitor Brackets
are vertically centered and level with each other.
M4 Diameter Bolt M6 Diameter Bolt
M5 Diameter Bolt M8 Diameter Bolt
Diagram 1B
9
GB
Mounting the wall plate
to the wall
Brick, Solid Concrete and Concrete Block mounting:
Use the Wall Plate(a) as a template to mark 3 hole locations on the wall.
Make sure these holes are level. Pre-Drill these holes with a 3/8”(10mm)
masonry bit to at least 2.4”(60mm) in depth. Insert a Concrete Anchor(v)
into each of these holes.
Make sure the anchor is seated completely ush with the concrete
surface even if there is a layer of drywall or other material in front. Attach
the Wall Plate to the wall using 3pcs Lag Bolts(t) and 3pcs Lag Bolt
Washers(u), shown in Diagram 2A.
Wood Stud mounting:
The Wall Plate(a) must be mounted to two wood studs at least
16”(406mm) apart. Use a stud nder to locate two adjacent studs. It is a
good idea to verify where the studs are located with an awl or thin nail
shown in Diagram 2B. Pre-drill a 2.4”(60mm) deep hole at the desired
height in each stud using a 5/32”(4mm) drill bit. Make sure these holes
are in the center area of the studs and level with each other. Attach
the Wall Plate to the wall using the 2pcs Lag Bolts(t) and 2pcs Lag Bolt
Washers(u).
Diagram 2A Diagram 2B
Stud Finder
16 inch
16 inch
16 inch
10
GB
Attaching monitor
to wall plate
Warning: Some TVs may require two people to lift! We are not responsible
for personal injury or product damage.
First hook the Monitor Brackets(b,c) over the top of the wall Plate(a), then
let the bottom of the Monitor Brackets rotate to the wall as shown in the
Diagram 3A. The nishing looking as shown in the Diagram 3B.
Thanks for choosing our products, enjoy the using.
Diagram 3BDiagram 3A
wall wall
