ACME LED?7TC Manuel utilisateur

LED‐7TC

UserGuide

Pleasereadtheinstructioncarefullybeforeuse

Contents

1.SafetyInstructions....................................................................................................2

2.TechnicalSpecifications ............................................................................................3

3.Installation................................................................................................................4

4.HowtoSettheFixture..............................................................................................4

4.1ControlPanel ......................................................................................................4

4.2MainFunction .....................................................................................................5

5.HowtoControltheUnit .........................................................................................10

A.UniversalDMXcontroller ...................................................................................10

B.Master/Slaveoperation......................................................................................11

C.EasyController(byCA‐8)....................................................................................11

6.DMX512Configuration ..........................................................................................12

7.DMX512Connection..............................................................................................13

8.Troubleshooting......................................................................................................14

9.CleaningAndMaintenance ....................................................................................15



1.SafetyInstructions

WARNING

yPleasekeepthisUserManualforfutureconsultation.Ifyousellthefixturetoanotheruser,be

surethattheyalsoreceivethisinstructionbooklet.

yUnpackandcheckcarefullythereisnotransportationdamagebeforeusingthefixture.

yBeforeoperating,ensurethatthevoltageandfrequencyofpowersupplymatchthepower

requirementsofthefixture.

yIt’simportanttogroundtheyellow/greenconductortoearthinordertoavoidelectricshock.

yDisconnectmainpowerbeforeservicingandmaintenance.

yUsesafetychainwhenfixesthisfixture.Don’thandlethefixturebytakingitsheadonly,but

alwaysbytakingitsbase.

yMaximumambienttemperatureisTa:40℃.Don’toperateitwherethetemperatureishigher

thanthis.

yIntheeventofseriousoperatingproblem,stopusingthefixtureimmediately.Nevertryto

repairthefixturebyyourself.Repairscarriedoutbyunskilledpeoplecanleadtodamageor

malfunction.Pleasecontactthenearestauthorizedtechnicalassistancecenter.Alwaysusethe

sametypespareparts.

yDonotconnectthedevicetoanydimmerpack.

yDonottouchanywireduringoperationandtheremightbeahazardofelectricshock.

yTopreventorreducetheriskofelectricalshockorfire,donotexposethefixturetorainor

moisture.

yThehousingmustbereplacediftheyarevisiblydamaged.

yDonotlookdirectlyattheLEDlightbeamwhilethefixtureison.

Warning:



Pleasereadtheinstructionscarefullywhichincludesimportant

informationabouttheinstallation,operationandmaintenance.

Ifusinga230Vac50Hzpowersupply,donotconnectinseriesmorethan20units,use

anothermainssupplyforthenext20units.

Ifusinga120Vac60Hzpowersupply,donotconnectinseriesmorethan10units,use

anothermainssupplyfornext10units.

yTopreventorreducetheriskofelectricalshockorfire,donotexposetheunittorainor

moisture.

yDonotopentheunitwithinfiveminutesafterswitchingoff.

yThehousing,thelenses,ortheultravioletfiltermustbereplacediftheyarevisiblydamaged.

Caution:

Therearenouserserviceablepartsinsidethefixture.Donotopenthehousingorattemptany

repairsyourself.Intheunlikelysituation,yourunitmayrequireservice,pleasecontactyour

nearestdealer.



2.TechnicalSpecifications

•DMXchannel:4channelmodes

•LED:7x3WRGB(Tri‐color)LED

•Powersupply

InputVoltage:AC100V‐240V~50/60Hz

•Powerconsumption:28.5W

•Fuse:T6.3A

•Dimension:212x80x212mm

•Weight:2.5kgs

3.Installation

Theunitshouldbemountedviaitsscrewholesonthebracket.Alwaysensurethattheunitis

firmlyfixedtoavoidvibrationandslippingwhileoperating.Alwaysensurethatthestructureto

whichyouareattachingtheunitissecureandisabletosupportaweightof10timesoftheunit’s

weight.Alsoalwaysuseasafetycablethatcanhold12timesoftheweightoftheunitwhen

installingthefixture.

Theequipmentmustbefixedbyprofessionals.Anditmustbefixedataplacewhereisoutofthe

touchofpeopleandhasnoonepassbyorunderit.

4.HowtoSettheFixture

4.1ControlPanel

○

1Display:Toshowthevariousmenusandtheselectedfunctions

LED:

○

2DMXOnDMXinputpresent

○

3MASTEROnMasterMode

○

4SLAVEOnSlaveMode

○

5SOUNDFlashingSoundactivation

Button:

○

6MENUToselecttheprogrammingfunctions

○

7DOWNTogobackwardintheselectedfunctions

○

8UPTogoforwardintheselectedfunctions

○

9ENTERToconfirmtheselectedfunctions

○

10 Microphone:Receivemusicforthesoundactive.

○

11 Onlyforremotecontrol:ByconnecttotheCA‐8tocontroltheunitforStandby,Function

andModefunction.

○

12 DMXoutput:ForDMX512link,use3/5 ‐pinXLRplugcabletolinkthenextunit.

○

13 DMXinput:ForDMX512link,use3/5 ‐pinXLRplugcabletoinputDMXsignal.

○

14 Mainsinput:Connecttosupplymainspower.

○

15 Mainsoutput:Connecttosupplymainspowerforthenextunit.

4.2MainFunction

Toselectanyofthegivenfunctions,presstheMENUbuttontoshowtherequiredoptiononthe

display.SelectthefunctionwiththeENTERbuttonandthedisplaywillblink.UsetheDOWNand

UPbuttonstochangethemode.Oncetherequiredmodehasbeenselected,PresstheENTER

buttontostore.TogobacktothemainmenuwithoutanychangespresstheMENUbutton.Hold

andpresstheMENUbuttonaboutonesecondorwaitforoneminutetoexitthemenumode.The

mainfunctionsareshownbelow:



DMX512AddressSetting

PresstheMENUbuttonuptowhenthe  isshownonthedisplay.PressENTERbuttonand

thedisplaywillblink.UseDOWNandUPbuttontochangetheDMX512Address(1‐512)orselect

(autosettingDMX512address).Onceselected,presstheENTERbuttontostoreor

automaticallyreturntothemainfunctionswithoutanychangesafter8seconds.Togobacktothe

functionswithoutanychangepresstheMENUbuttonagain.



Channelmode

PresstheMENUbuttonuptowhenthe  isshownonthedisplay.PressingtheENTER

buttonandthedisplaywillblink.UsetheDOWNandUPbuttontoselectthe  (channel1)

or  (channel2)or(channel3)or  (channel4)mode.Oncethemodehasbeen

selected,presstheENTERbuttontosetuporautomaticallyreturntothemainfunctionswithout

anychangeafter8seconds.TogobacktothefunctionswithoutanychangepresstheMENU

buttonagain.



ShowMode

PresstheMENUbuttonuptowhenthe  isshownonthedisplay.PressingENTERbutton

andthedisplaywillblink.UseDOWNandUPbuttontoselectthe  (autoshow)or 

(show1)or  (show2)or…(show12).Oncetheshowhasbeenselected,pressthe

ENTERbuttontoconfirm,ifyouselect(show1)or  (show2)or…(show

12),youcanpressDOWNandUPbuttontoselect(slowest)or…  (fastest),press

ENTERbuttontostoreorautomaticallyreturntothemainfunctionswithoutanychangeafter8

seconds.TogobacktothefunctionswithoutanychangepresstheMENUbuttonagain.



ChaseMode

PresstheMENUbuttonuptowhenthe  isshownonthedisplay.PressingENTERbutton

andthedisplaywillblink.UseDOWNandUPbuttontoselectthe  (chase1)or…or

(chase16)or  (fade).Oncethechasehasbeenselected,presstheENTERbuttontoconfirm,

thenpressDOWNandUPbuttontoselect  (slowest)or…  (fastest),pressENTER

buttontostoreorautomaticallyreturntothemainfunctionswithoutanychangeafter8seconds.

TogobacktothefunctionswithoutanychangepresstheMENUbuttonagain.



SlaveMode

PresstheMENUbuttonuptowhenthe  isshownonthedisplay.PressingENTERbutton

andthedisplaywillblink.UseDOWNandUPbuttontoselectthe(Mater)or 

(normal)or…or  (16lightshow)mode.Oncethemodehasbeenselected,presstheENTER

buttontosetuporautomaticallyreturntothemainfunctionswithoutanychangeafter8seconds.

TogobacktothefunctionswithoutanychangepresstheMENUbuttonagain.



Soundcontrol

PresstheMENUbuttonuptowhenthe  isshownonthedisplay.PressingENTERbutton

andthedisplaywillblink.UseDOWNandUPbuttontoselectthe  (soundcontrolon)or

(soundcontroloff).Oncethemodehasbeenselected,presstheENTERbuttontosetupor

automaticallyreturntothemainfunctionswithoutanychangeafter8seconds.Togobacktothe

functionswithoutanychangepresstheMENUbuttonagain.



BlackoutMode

PresstheMENUbuttonuptowhenthe  isshownonthedisplay.PressingENTERbutton

andthedisplaywillblink.UseDOWNandUPbuttontoselectthe (noblackout)or 

(yesblackout)mode.Oncethemodehasbeenselected,presstheENTERbuttontosetupor

automaticallyreturntothemainfunctionswithoutanychangeafter8seconds.Togobacktothe

functionswithoutanychangepresstheMENUbuttonagain.



ColorMode

PresstheMENUbuttonuptowhenthe  isshownonthedisplay.PressingENTERbutton

andthedisplaywillblink.UseDOWNandUPbuttontoselectthe  (color1)or…or 

(show16)or  (manualsetting).Onceselect,presstheENTERbuttontoconfirm,ifyou

select  (manualsetting),youcanpressDOWNandUPbuttontoselect  (red)or

(green)or  (blue),pressENTERbuttontoconfirm,thenuseDOWNandUPbutton

toadjustthevalue(0‐255)andpressENTERbuttontostore,automaticallyreturntothemain

functionswithoutanychangeafter8seconds.Togobacktothefunctionswithoutanychange

presstheMENUbuttonagain.



LEDDisplay

PresstheMENUbuttonuptowhenthe  isshownonthedisplay.PressingENTERbutton

andthedisplaywillblink.UseDOWNandUPbuttontoselectthe  (LEDon)or  (LED

off)mode.Oncethemodehasbeenselected,presstheENTERbuttontosetuporautomatically

returntothemainfunctionswithoutanychangeafter8seconds.Togobacktothefunctions

withoutanychangepresstheMENUbuttonagain.



DisplayInversion

Itisgoodforyoutoinstalltheunitonthefloororunderceiling.PresstheMENUbuttonupto

whenthe  isshownonthedisplay.PressingENTERbuttonandthedisplaywillblink.Use

DOWNandUPbuttontoselectthe  (displayinversion)or  (displaynormal).Once

select,presstheENTERbuttontosetuporautomaticallyreturntothemainfunctionswithoutany

changeafter8seconds.TogobacktothefunctionswithoutanychangepresstheMENUbutton

again.



FixtureTemperature

PresstheMENUbuttonuptowhenthe  isblinkingonthedisplay.PressingENTERbutton

andthedisplaywillshowthetemperatureoftheunit.TogobacktothefunctionspresstheMENU

buttonagain.


