Acer K130 Series Manuel utilisateur
Acer Projector
Multi-media
User's Guide
Introduction 1
Multimedia Features 1
Getting Started 2
Connecting multi-media device to the projector 2
Control Panel and Remote Control 3
Onscreen Display (OSD) Menus 5
Media Gallery 6
Setup 9
Photo Setting 10
Music Setting 11
Video Setting 12
Using MPtG Converter Tool 13
Wireless Projection via acer USB WiFi Adapter 14
Projection with MobiShow 17
Using MobiShow 17
Photo reviewer 18
Wireless PtG 19
Using the PtG2 converter 20
Acer EquiView - Screen Projection from Acer Tablet21
Display over USB 22
Appendices 23
Troubleshooting 23
Problems and Solution 23
Multi-media format supported 24
1. Photo Format 25
2. Music Format 25
3. Video Format 26
Contents
1
English
Introduction
The Acer multimedia support offers easier projection without PC and player
connected. Through Micro SD card reader and USB type A slot, you can easily
access various photo, video and music media formats (See format supported
table). The stylish user interface gives you best experience while playing media
files.
Multimedia Features
•Fancy and stylish user interface for better experience.
Supports Micro SD/ SDHC card, USB memory stick and mass storage (FAT32,
FAT16, NTFS) device.
•Supports high resolution JPEG and BMP picture formats, slideshow and
kinds of slideshow effects for the best viewing experience.
•Supports MP3, PCM and WMA...audio formats, music spectrum and
random play function for your please control.
•Supports MJPEG, MPEG4, H.264, WMV, MKV and RMVB...video formats.
Smooth video playback with 1080p@30Hz.
•Support office documents playback (Word, Excel, Powerpoint, PDF).
•Easy control for all media functions by remote controller.
Copyright ©2011. Acer Incorporated.
All Rights Reserved.
Changes may be made periodically to the information in this publication
without obligation to notify any person of such revisions or changes.
Such changes will be incorporated in new editions of this manual or
supplementary documents and publications.
This company makes no representations or warranties, either expressed or
implied, with respect to the contents hereof and specifically disclaims the
implied warranties of merchantability or fitness for a particular purpose.
2
English
Getting Started
Connecting multi-media device to the
projector
Note: The media contents in external HDD drive via USB cable is
not supported.
#Icon Component Description
1 MicroSD Card
Slot
Connects to MicroSD Card.
2 USB connector Connects to USB disk/stick/cable.
USB
HDMI
UNIVERSAL I/O
AV IN DC IN
micro
12
micro
USB
3
English
Control Panel and Remote Control
#Icon Component Description
1 Back/Stop Stop playing media file or go back to upper
data folder.
2 Menu Press to be back or stop function in multimedia
controls.
3 Media Toggle between USB A, Micro SD and RAM
sources.
4 Empowering
key
Unique Acer functions: eView, eTimer, e3D and
ePower Management.
Toolbar During Office Reader viewing, press to
bring up the toolbar.
Thumbnail Press to display folders or photos as
thumbnails at Photo category.
5 Enter/Play/
Pause
Confirm your selection of items or play/pause
media file.
Rotate During Office Reader viewing, press to
rotate the image from the toolbar.
2
6
4
3
5
1
4
English
6 Pre./Next Press / to select previous or next item
when the media is playing.
Rewind/Fast
forward Long press / to rewind or fast forward
when the media is playing.
Volume Press / to decreases or increases the
volume when the media is playing.
Select
Enter When the Media Gallery is displayed, press /
to make a selection and then press to
enter submenu for feature setting .
Enter/Play
Back Press to enter or play function or press
to be back function in most multimedia
controls.
Zoom During Office Reader viewing, select / to
zoom out or zoom in from the toolbar.
5
English
Onscreen Display (OSD) Menus
Setting
Main menu
Sub menu
6
English
Media Gallery
Note:
Change source to USB A to play your media contents in USB
drive.
Note:
Change source to Micro SD to play your media contents in
Micro SD card.
Photo: For access of photo files. Music: For access of music files.
Video: For access of video files. Office Reader: For access of WORD,
EXCEL, PPT, PDF files.
MPtG: For access of MPtG files. Please
refer to section "Using MPtG Converter
Tool"
Setup: For access of kinds of settings.
7
English
Note:
Change source to RAM to play your media contents in
internal memory.
Note:
Change source to USB B, make sure to plug USB cable well
and you can see disk and edit 1GB free space of internal memory.
Note:
Only support USB 2.0 handy drive. USB hubs are not
supported. External USB Hard disk is not supported.
Note:
Support USB handy drive/ Micro SD card upto 32GB.
8
English
Note: Office Reader:
1. All IPR, including but not limited to copyright, in the Picsel
Products is owned by Picsel suppliers.
2. The End User may not:
• Make copies of the Picsel Products or make them available
for use by third parties.
• Reverse engineer, disassemble, reverse translate, or in any
way decode the Picsel Products or any copy or part of it in
order to derive any source code, save only as is permitted
by any applicable law.
3. Picsel make no representations or warranties whether express
or implied (by statute or otherwise) relating to the
performance, quality, merchantability or fitness for a
particular purpose of the Picsel Products or otherwise and all
such representations or warranties are specifically disclaimed
and excluded.
4. Picsel agrees and acknowledges that Picsel and the Picsel
Products will not be specifically mentioned in the end user
license agreement.
Note: No support for advanced settings, such as Microsoft Word
drawing plug-in or table background settings.
Note: Contents outside the defined borders in Microsoft Word
will not be displayed.
Note: Microsoft PowerPoint slide effects not supported.
Note: Worksheets are displayed individually and sequentially
when the workbook has multiple worksheets.
Note: Page layout and numbering may be changed during
decoding.
Note: Objects embedded in files cannot be activated or viewed.
Note: Decoding may take a while for large files with complex
contents.
