Acer Aspire 5335 Series Manuel utilisateur

Aspire 5735/5735Z/5335

Series

Quick Guide

Changes may be made periodically to the information in this publication without obligation

to notify any person of such revisions or changes. Such changes will be incorporated in new

editions of this manual or supplementary documents and publications. This company makes

no representations or warranties, either expressed or implied, with respect to the contents

hereof and specifically disclaims the implied warranties of merchantability or fitness for a

particular purpose.

Record the model number, serial number, purchase date and place of purchase information in

the space provided below. The serial number and model number are recorded on the label

affixed to your computer. All correspondence concerning your unit should include the serial

number, model number and purchase information.

No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in

any form or by any means, electronically, mechanically, by photocopy, recording or otherwise,

without the prior written permission of Acer Incorporated.

Model number: __________________________________

Serial number: ___________________________________

Date of purchase: ________________________________

Place of purchase: ________________________________

Aspire 5735/5735Z/5335 Series Quick Guide

Original Issue: 08/2008

Aspire 5735/5735Z/5335 Series Notebook PC

Acer and the Acer logo are registered trademarks of Acer Incorporated. Other companies'

product names or trademarks are used herein for identification purposes only and belong to

their respective companies.

First things first

We would like to thank you for making an Acer notebook your choice for

meeting your mobile computing needs.

Your guides

To help you use your Acer notebook, we have designed a set of guides:

First off, the Just for Starters... poster helps you get started with setting up your

computer.

The Aspire Series Generic User Guide contains useful information applying to all

models in the Aspire product series. It covers basic topics such as Acer's

Empowering Technology, using the keyboard, audio, etc. Please understand

that due to its nature, the Generic User Guide as well as the AcerSystem User

Guide mentioned below will occasionally refer to functions or features which

are only contained in certain models of the series, but not necessarily in the

model you purchased. Such instances are marked in the text with language such

as "only for certain models".

The Quick Guide introduces you to the basic features and functions of your new

computer. For more on how your computer can help you to be more productive,

please refer to the AcerSystem User Guide. This guide contains detailed

information on such subjects as system utilities, data recovery, expansion

options and troubleshooting. In addition it contains warranty information and

the general regulations and safety notices for your notebook. It is available in

Portable Document Format (PDF) and comes preloaded on your notebook.

Follow these steps to access it:

1 Click on Start, All Programs, AcerSystem.

2 Click on AcerSystem User Guide.

Note: Viewing the file requires Adobe Reader. If Adobe Reader is not

installed on your computer, clicking on AcerSystem User Guide will run the

Adobe Reader setup program first. Follow the instructions on the screen to

complete the installation. For instructions on how to use Adobe Reader,

access the Help and Support menu.

English

Your Acer notebook tour

After setting up your computer as illustrated in the Just for Starters... poster,

let us show you around your new Acer notebook.

Top view

#Icon Item Description

1 Acer Crystal Eye

webcam

Web camera for video communication

(only for certain models).

English

2 Display screen Also called Liquid-Crystal Display (LCD),

displays computer output.

3 Power button Turns the computer on and off.

4 Empowering key Launch Acer Empowering Technology.

5 Keyboard For entering data into your computer.

6 Touchpad Touch-sensitive pointing device which

functions like a computer mouse.

7/14 Status indicators Light-Emitting Diodes (LEDs) that light up

to show the status of the computer's

functions and components. Please refer to

the Generic User Guide for more details.

8 Click buttons

(left and right)

The left and right buttons function like the

left and right mouse buttons.

9 Palmrest Comfortable support area for your hands

when you use the computer.

10 Speakers Left and right speakers deliver stereo

audio output.

11 Microphone Internal microphone for sound recording.

12 Easy-launch

buttons

Buttons for launching frequently used

programs. Please refer to the Generic User

Guide for more details.

13 VOL+/

VOL-

Volume up/

Volume down

Increases the sound volume/Decreases the

sound volume.

#Icon Item Description

English

Closed front view

Rear view

#Item Description

1 Latch Locks and releases the lid.

#Item Description

1 Ventilation slots Enable the computer to stay cool, even after

prolonged use.

English

Left view

#Icon Item Description

1 External display

(VGA) port

Connects to a display device (e.g.,

external monitor, LCD projector).

2 Ethernet (RJ-45)

port

Connects to an Ethernet 10/100/1000-

based network.

3 USB 2.0 port Connects to USB 2.0 devices (e.g., USB

mouse, USB camera).

4Microphone jack Accepts inputs from external

microphones.

5 Headphones/

speaker/line-out

jack

Connects to audio line-out devices

(e.g., speakers, headphones).

6 5-in-1 card reader Accepts Secure Digital (SD),

MultiMediaCard (MMC), Memory Stick

(MS), Memory Stick Pro (MS PRO), and

xD-Picture Card.

Note: Push to remove/install the card.

Only one card can operate at any given

time.

7 ExpressCard/54

slot

Accepts one ExpressCard/54 module.

Note: Push to remove/install the card.

English

Right view

#Icon Item Description

1 Optical drive Internal optical drive; accepts CDs or

DVDs.

2 Optical disk access

indicator

Lights up when the optical drive is

active.

3 Optical drive eject

button

Ejects the optical disk from the drive.

4 Emergency eject

hole

Ejects the optical drive tray when the

computer is turned off.

Note: Insert a paper clip to the

emergency eject hole to eject the

optical drive tray when the computer

is off.

5Modem

(RJ-11) port

Connects to a phone line.

6 DC-in jack Connects to an AC adapter.

7 Kensington lock slot Connects to a Kensington-compatible

computer security lock.

English

Base view

#Icon Item Description

1 Battery bay Houses the computer's battery pack.

2 Battery release latch Releases the battery for removal.

3 Battery lock Locks the battery in position.

4 Memory compartment Houses the computer's main memory.

5 Hard disk bay Houses the computer's hard disk (secured

with screws).

6 Ventilation slots and

cooling fan

Enable the computer to stay cool, even

after prolonged use.

Note: Do not cover or obstruct the

opening of the fan.

English

Specifications

Operating

system

•Genuine Windows Vista®

Platform •Intel®Core™2 Duo processor*

•Intel®Pentium®dual-core processor*

•Intel® Celeron®processor*

•Mobile Intel®GL40/GM45 Express Chipset*

•Intel®Wireless WiFi Link 5100/5300*

•Acer InviLink™Nplify™802.11b/g/Draft-N*

•Acer InviLink™802.11b/g*

System memory •Dual-channel support

•Up to 2 GB of DDR2 667 MHz memory, upgradeable

to 4 GB using two soDIMM modules

Display •15.6" HD 1366 x 768

Graphics •Mobile Intel®GL40/GM45 Express Chipset*

Storage

subsystem

•2.5" hard disk drive

•Optical drive option:

• DVD-Super Multi double-layer drive

•5-in-1 card reader

Audio •Two built-in stereo speakers

•High-definition audio support

• MS-Sound compatible

•Built-in microphone

Communication •Integrated Acer Crystal Eye webcam*

•WLAN:

•Intel

®Wireless WiFi Link 5100/5300*

• Acer InviLink™Nplify™802.11b/g/Draft-N*

• Acer InviLink™802.11b/g*

•WPAN: Bluetooth®2.0+Enhanced Data Rate (EDR)*

•LAN: Gigabit Ethernet; Wake-on-LAN ready

•Modem: 56K ITU V.92; Wake-on-Ring ready

Dimensions •383 (W) x 250 (D) x 15/37 (H) mm

15.08 (W) x 9.84 (D) x 0.59/1.46 (H) inch

Privacy control •BIOS user, supervisor, HDD passwords

•Kensington lock slot

Power

subsystem

•ACPI 3.0

•48.8 W 4400 mAh

•3-pin 65 W AC adapter

•ENERGY STAR®4.0*
