Acer SF314-512 Manuel utilisateur

English

Swift 3

Covers: SF314-512 / SF314-512T

This revision: December 2021

This manual contains proprietary information that is protected by copyright laws. The

information contained in this manual is subject to change without notice. Some features

described in this manual may not be supported depending on the Operating System

version. Images provided herein are for reference only and may contain information or

features that do not apply to your computer. Acer Group shall not be liable for technical

or editorial errors or omissions contained in this manual.

Model number: ________________________________________

Serial number: _________________________________________

Date of purchase: ______________________________________

Place of purchase: _____________________________________

ENVIRONMENT

Temperature:

- Operating: 5 °C to 35 °C

- Storage: -20 °C to 60 °C

Humidity (non-condensing):

- Operating: 20% to 80%

- Storage: 20% to 60%

English

First things first

We would like to thank you for making this Acer notebook your choice for meeting

your mobile computing needs.

Your guides

To help you use your Acer notebook, we have designed a set of guides:

First off, the Setup Guide helps you get started with setting up your computer.

For more on how your computer can help you to be more productive, please refer to

the Swift 3 User’s Manual. The Swift 3 User’s Manual contains useful information

applying to your new computer. It covers basic topics such as using the keyboard and

audio, etc.

This guide contains detailed information on such subjects as system utilities, data

recovery, expansion options and troubleshooting. In addition it contains warranty

information and the general regulations and safety notices for your notebook.

The User’s Manual can be downloaded from the Acer support website by going to:

http://go.acer.com/support

Software installation

The first time you turn on your computer, it will automatically install software and set

up for use. This may take some time, please do not turn off your computer; wait until

the installation has finished.

Recovery

You should create recovery backups as soon as you can. The Acer Recovery

Management program allows you to create recovery backups and then to restore or

reinstall applications and drivers provided by Acer.

Having trouble?

Acer provides several options to support your purchase.

Acer support

Make sure you write down your computer serial number, date and place of purchase

and model name on the area provided in this guide; save your proof of purchase.

Before you call us, please write down any error message that accompanies the

problem, and have the computer in front of you and switched on if possible. Having

these items to hand when contacting us will ensure better and quicker service.

English

Acer website

Remember to visit www.acer.com and refer to the support section for up-to-date

information, help, drivers and downloads.

Warranty and contact information

You can find information about the warranty for your computer and how to contact

technical support in your computer’s Warranty.

Your Acer notebook tour

English

Your Acer notebook tour

After setting up your computer as illustrated in the Setup Guide, let us show you

around your new Acer computer.

Screen view

#Icon Item Description

1 Microphones Internal digital microphone for sound recording.

2Camera

Camera for video communication or taking photos.

A light next to the camera indicates that the

camera is active.

3Screen Displays computer output, supports touch or non-

touch option.

English

Keyboard view

#Icon Item Description

1Keyboard For entering data into your computer.

See "Using the keyboard" on page 8.

2Touchpad

Touch-sensitive pointing device.

The touchpad and selection buttons form a single

surface.

Press down firmly on the touchpad surface to

perform a left click.

Press down firmly on the lower right corner to

perform a right click.

3Power button with

fingerprint reader

Turns the computer on and off.

Touch lightly to use fingerprint reader for Windows

Hello and security.

Your Acer notebook tour

English

Left view

#Icon Item Description

1USB Type-C port with

DC-in

Connects to the provided USB Type-C power

adapter and to USB devices with a USB Type-C

connector.

Supports Thunderbolt™ 4 and displays.

2HDMI port Supports high-definition digital video connections.

3USB port with power-

off charging Connects to USB devices.

USB Type-A information

• USB 3.2 Gen 1 compatible ports are blue.

• Compatible with USB 3.2 Gen 1 and earlier devices.

• For optimal performance, use USB 3.2 Gen 1-certified devices.

• Defined by the USB 3.2 Gen 1 specification (SuperSpeed USB).

USB Type-C information

• Supports DisplayPort™ audio/video output.

• Compatible with Thunderbolt™ 4.

• Delivers up to 3 A at 5 V DC for USB charging.

• DC-in: requires power adapter or power source providing 65 W at 20 V.

For optimal performance, please use a certified Acer power adapter or USB Power

Delivery device.

English

Right view

31 4

#Icon Item Description

1Headset/speaker jack Connects to audio devices (e.g., speakers,

headphones) or a headset with microphone.

2USB port Connects to USB devices.

Battery indicator

Indicates the computer’s battery status.

Charging: The light shows amber when the

battery is charging.

Fully charged: The light shows blue when in AC

mode.

Power indicator Indicates the computer’s power status.

4Kensington lock slot Connects to a Kensington-compatible security

lock.

Using the keyboard

English

Base view

#Icon Item Description

1Ventilation and cooling

fan

Allows the computer to stay cool.

Do not cover or obstruct the openings.

2Battery reset pinhole

Simulates removing and reinstalling the battery.

Insert a paperclip into the hole and press for four

seconds.

3Speakers Deliver stereo audio output.

Using the keyboard

The keyboard has full-sized keys, a numeric keypad, separate cursor, lock, Windows,

special keys and hotkeys.

Special keys

Your computer’s keyboard includes keys that activate special functions. The function

of each key is clearly marked with an icon.

Icon Function Description

Speaker toggle Turns the speakers on and off.

Volume down Decreases the sound volume.

English

Volume up Increases the sound volume.

Microphone toggle Turns the microphones on and off.

Brightness down Decreases the screen brightness.

Brightness up Increases the screen brightness.

Display toggle Switches display output between the display screen,

external monitor (if connected) and both.

Lock your computer Locks your computer to secure your information. You can

enter password to continue your work.

Flight mode Turns on / off the computer's network devices.

Touchpad toggle Turns the built-in touchpad on and off.

Keyboard backlight

control Adjusts keyboard backlight brightness

Snipping tool Snips a rectangle, freeform, window or full screen to your

clipboard.

Icon Function Description

Using the keyboard

English

Hotkeys

To activate hotkeys, press and hold the Fn key before pressing the other key in the

hotkey combination.

Hotkey Icon Description

Fn + F1-F12 Activates the F1 to F12 keys.

Fn + F

Switches fan mode between Silent, Normal and

Performance.

For more information on how to achieve optimal cooling

efficiency in different scenarios, please launch Acer

Quick Access application.

Fn + Delete Insert Turns Insert on or off.

Fn + Home Scrolls to the beginning of a document.

Fn + End Scrolls to the end of a document.

Fn + Pg up Scrolls up a page in a document.

Fn + Pg dn Scrolls down a page in a document.
