Acconeer XM112 Manuel d'installation
HP module EVK hardware user guide
- XM112, XB112, LH112
HP module EVK hardware user guide – XM112, XB112, LH112
Page 2 of 41
© 2018 by Acconeer – All rights reserved 2022-08-25
HP module EVK hardware user guide
- XM112, XB112, LH112
Author: Acconeer
Version 1.2: 2022-08.25
Acconeer AB
HP module EVK hardware user guide – XM112, XB112, LH112
Page 3 of 41
2022-08-25 © 2018 by Acconeer – All rights reserved
Table of Contents
1 Overview of the HP module EVK. ....................................................................................................... 5
1.1 Introduction .............................................................................................................................. 5
2 Software for the Module EVK ............................................................................................................. 6
2.1 Software download .................................................................................................................. 6
2.2 Module software for XM112 ................................................................................................... 6
2.3 SDK for ATMEL SAME70 ..................................................................................................... 6
3 The HP Module EVK Hardware .......................................................................................................... 7
3.1 XB112 Breakout Board ............................................................................................................ 8
3.1.1 Overview ......................................................................................................................... 8
3.1.2 Power ............................................................................................................................. 10
3.1.3 Electrical Schematics..................................................................................................... 11
3.1.4 Bill of Material .............................................................................................................. 15
3.1.5 Component Placement Drawing .................................................................................... 17
3.1.6 Pinning/Connectors ....................................................................................................... 19
3.1.7 Buttons ........................................................................................................................... 22
3.2 HP Module ............................................................................................................................. 23
3.2.1 Overview ....................................................................................................................... 23
3.2.2 Electrical Schematics..................................................................................................... 25
3.2.3 Bill of Material .............................................................................................................. 29
3.2.4 Component Placement Drawing .................................................................................... 30
3.2.5 Pinning ........................................................................................................................... 32
3.3 Lens Evaluation Kit LH112 ................................................................................................... 33
3.3.1 Overview ....................................................................................................................... 33
3.3.2 Contents and assembly .................................................................................................. 33
3.3.3 Lens Performance .......................................................................................................... 35
4 Flashing of XM112 via USB-UART Interface .................................................................................. 36
4.1 Updating the Software ........................................................................................................... 36
4.1.1 Install Tools ................................................................................................................... 36
4.1.2 Upgrade Procedure ........................................................................................................ 36
5 Safety 38
5.1 Electrostatic precautions ........................................................................................................ 38
6 Regulatory Information ...................................................................................................................... 39
7 Revision History ................................................................................................................................. 40
8 Disclaimer .......................................................................................................................................... 41
HP module EVK hardware user guide – XM112, XB112, LH112
Page 4 of 41
© 2018 by Acconeer – All rights reserved 2022-08-25
HP module EVK hardware user guide – XM112, XB112, LH112
Page 5 of 41
2022-08-25 © 2018 by Acconeer – All rights reserved
1 Overview of the HP module EVK.
1.1 Introduction
The HP Module Evaluation Kit (The EVK) is a platform for evaluating the HP Module. The module is
based on the Acconeer A111 sensor, which is an optimized low-power, high-precision 60 GHz radar
in one package solution with integrated Baseband, RF front-end and Antenna. In the HP Module The
A111 sensor is integrated together with an M7 processor (Atmel SAME70) which facilitates signal
processing for advanced use cases. For an introduction to Acconeer’s technology and product offer
refer to “Introduction to Acconeer’s sensor technology”, available at the Acconeer website.
The EVK consists of
One HP Module featuring A111 and an Atmel SAME70 MCU. The module is not pre-flashed and
an XB112 is needed to easily flash it.
One XB112 breakout board which enables connection to external devices.
LH112
HP module EVK hardware user guide – XM112, XB112, LH112
Page 6 of 41
© 2018 by Acconeer – All rights reserved 2022-08-25
2 Software for the Module EVK
2.1 Software download
All software is available for download at https://www.acconeer.com/products, more details about the
software offer and structure can be found in the document “Introduction to Acconeer’s sensor
technology”, available at the Acconeer website.
For the HP Module Acconeer provides two deliveries, a software development kit (SDK) for ATMEL
SAME70 and a module software image for XM112. Details about the software offer can be found in
the document “Introduction to Acconeer’s sensor technology”, available at the Acconeer website.
2.2 Module software for XM112
The HP Module software enable register-based access to radar functionality from external devices
connected to the HP Module. The module software is delivered as an image.
Typical usages of the HP Module software are:
1. Integration of radar functionality in your product to decrease development cost and time to
market.
2. Module evaluation and algorithm development in Python together with the “Acconeer Python
Exploration Tool” that is available for download on GitHub. https://github.com/acconeer/
The HP Module software provides a rich register-based API that can be accessed over UART, SPI and
I2C1.
The Module software will initially support the following services and detectors:
- Power Bin Service
- Envelope Service
- IQ Data Service
- Distance peak detector with fixed threshold
Support for more detectors is planned for future module software releases.
2.3 SDK for ATMEL SAME70
For users that wish to use the module MCU to implement their own applications and other SW
components we also provide an SDK.
The Acconeer SDK comes with an API (Application Programming Interface). Acconeer provides
several service oriented example applications, as well as customer guidelines for application
development when utilizing the API. All APIs provided by Acconeer are documented in the SDK.
1 The I2C support is planned but is not available at the time of writing.
HP module EVK hardware user guide – XM112, XB112, LH112
Page 7 of 41
2022-08-25 © 2018 by Acconeer – All rights reserved
3 The HP Module EVK Hardware
Figure 1 shows the block diagram for the HP Module Evaluation Kit
A111
24MHz XTAL
XM112
ATSAME70
ENABLE
INTERRUPT
1.8V
SPI external
I2C
UART[0,2,4]
SWD
MCU_INT
MCU_GPIO
ERASE
NRST
XB112 Board to board connector
SPI internal
12MHz XTAL
5V
1.8V
1.8V
FTDI
FT230XS
Misc GPIO
pin header
MCU_INT
MCU_GPIO
XM112 Board to board connector
JTAG/SWD
pin header
40-pin
connector
(NM)
FTDI
FT4222H
USB Connector 2 USB Connector 1
UART2
UART4
MCU_INT
MCU_GPIO
ERASE
NRST
SWD
I2C
NRST
Button
ERASE
Button
UART0
Switched
Power
Regulator
Dual
LDO
1.8V
1.8V
XB112
Figure 1 The EVK block diagram.
HP module EVK hardware user guide – XM112, XB112, LH112
Page 8 of 41
© 2018 by Acconeer – All rights reserved 2022-08-25
3.1 XB112 Breakout Board
The XB112 is Acconeer’s breakout board and part of the Module EVK.
3.1.1 Overview
The XB112 is a breakout-board designed for the XM112 Radar Module. It makes the interfaces from
the XM112 radar module accessible for evaluation and debug. It also enables flashing of the XM112
via USB-UART or SWD. The XM112 is connected to the XB112 via a board-to-board connector on
the top side of the PCB. Below you will find pictures of both front and back side of the breakout
board.
Picture 1 shows the XB112 connector board, front side.
HP module EVK hardware user guide – XM112, XB112, LH112
Page 9 of 41
2022-08-25 © 2018 by Acconeer – All rights reserved
Picture 2 shows the breakout board, XB112, back side.
HP module EVK hardware user guide – XM112, XB112, LH112
Page 10 of 41
© 2018 by Acconeer – All rights reserved 2022-08-25
3.1.2 Power
The EVK is powered via the USB connectors on XB112. USB1 powers the USB-UART chip (U4) and
the XM112. USB2 powers the USB-SPI chip (U5). If no SPI data is needed, the USB2 can be left
unconnected. USB1 must however always be connected. If the USB-UART interface is not used, a
dedicated USB charger can be inserted to USB1.
When the power LED on the XB112 is lit, the breakout board and the XM112 radar module (if
connected to the board-to-board connector on the top side of XB112) are powered on and ready for
use. For details regarding the power management on XB112, refer to the XB112 product brief.
