Abocom GP1520 Manuel utilisateur

Wireless GPRS Modem PC Card

The GP1520 is a type II PC Card for GSM 900/1800/1900 enabling

laptop users to have mobile access to the Internet or your company

network, assuring a wireless access “always on”, with speed

comparable to those of the current analogical modems.

Direct powered by your laptop, the GP1520 requires no external

power; plus, with the tri-band functionality, the GP1520 offers access on

all five continents with the same card, making it the perfect solution for

mobile worriers to always stay connected.

The GP1520 supports GSM data services, including GPRS, HSCSD, CSD, SMS and Fax. The included BVRP

application is intuitive and easy to use, which provides you easy and fast access to emails, SMS, and fax as well as

access to the Internet.

FEATURES

 Provides data connectivity at speeds of up to 85.6kpbs.

 GPRS/GSM over-air security with built-in authentication and encryption making it one of the most secure public

wireless system in the world.

 Uses GPRS/GSM wireless system to connect your notebook computer to your network or the Internet.

 Supports PC Card hot swap and true Plug & Play.

 Freedom to roam while staying connected

 Complies with Window 98/2000/ME/XP/PocketPC 2002

 Easy to install and configure

 Provide audio function

SPECIFICATION

Host Interface PC Card TypeII slot

Antenna Internal Tri-band Antenna

LED Indicators 



Link: POWER ON

Act: LINK BASE STATION

Frequency Band



EGSM Rx: 880 ~ 915MHz

EGSM Rx: 925 ~ 960MHz

DCS Tx: 1710 ~ 1785MHz

DCS Rx: 1805 ~ 1880MHz

PCS Tx: 1850 ~ 1910MHz

PCS Rx: 1930 ~ 1990MHz

Operation mode

GPRS multi-slot class 10 mode

(up to 4 download channels and 2 upload channels)

Coding Scheme Supports all coding schemes (1,2,3 and 4)

Device Class GPRS mobile station class B

SIM Interface SIM card Holder: Type 3V

Transmission Power 



Class 4 (2W) for GSM900

Class 1 (1W) for GSM1800 and GSM1900

Receiver Sensitivity

@ARP

BER <2.4%

-102dBm

Data Rate



GPRS data downlink transfer: 85.6 kbps (Max.)

GPRS data uplink transfer: 21.4 kbps (Max.)

SMS: Over CSD or GPRS connections

Power Consumption



Operating Voltage: 4.75V~5.25V

Active mode: 600mA (Max.)

Idle mode: 40mA (Typical)

Physical Specifications 



Weight: 50 g

Dimension: 125.81 (L) x 54.05 (W) x 11.46 (H) mm

Environment

Specifications (TBD)



Storage Temperature: -20~70℃ambient temperature

Storage humidity: 90% maximum (non-condensing)

Supported OS  Windows 98/ME/2000/XP/Pocket PC 2002
