Abocom WUE1500 Manuel utilisateur

M73-APO01-510

802.11b

Wireless & Fast

Ethernet

USB Adapter

Quick Installation Guide

REGULATORY STATEMENTS

FCC Certification

The United States Federal Communication

Commission (FCC) and the Canadian Department of

Communications have established certain rules

governing the use of electronic equipment.

Part15, Class B

This device complies with Part 15 of FCC rules.

Operation is subject to the following two conditions:

1) This device may not cause harmful interface, and

2) This device must accept any interface received,

including interface that may cause undesired

operation. This equipment has been tested and found

to comply with the limits for a Class B digital

device, pursuant to Part 15 of the FCC Rules. These

limits are designed to provide reasonable protection

against harmful interference in a residential

installation. This equipment generates, uses and can

radiate radio frequency energy, and if not installed

and used in accordance with the instructions, may

cause harmful interference to radio communications.

However, there is no guarantee that interference will

not occur in a particular installation. If this

equipment does cause harmful interference to radio

or television reception, which can be determined

by turning off and on, the user is encouraged to try

to correct the interference by one or more of the

following measures:

ZReorient or relocate the receiving antenna.

ZIncrease the distance between the equipment and

receiver.

ZConnect the equipment into an outlet on a circuit

different from that to which the receiver is

connected.

CAUTION:

1) To comply with FCC RF exposure compliance

requirements, a separation distance of at least 20

cm must be maintained between the antenna of

this device and all persons.

2) This transmitter must not be co-located or

operating in conjunction with any other antenna or

transmitter.

Software Installation

Precaution for Windows 98SE, 2000,

and ME users: You may install the

Adapter's software before installing the

hardware for saving your time.

Precaution for Windows XP users: It’s

not necessary to install the utility, since the

device will use the built-in utility in

Windows XP.

Installation the Utility under

Windows 98SE/ME/2000

1. Insert the Setup Utility CD-ROM into the

CD-ROM drive and double click on

Setup.exe to install the Configuration &

Monitor Utility.

2. When the Welcome screen appears, click

Next to continue.

3. The Choose Destination Location screen

will show you the default destination

chosen by the utility. Click Next to

continue.

4. Follow the instruction to select the

program folder. Click Next to continue.

5. In Start Copying Files, click Next to

continue.

6. In Setup Status, the InstallShield Wizard

will begin copying the files.

7. After the Configuration Utility has been

successfully installed, select Yes, I want

to restart my computer now, and then

click Finish to restart.

- 1 -

Hardware Installation

Installation of the USB Adapter

for Windows 98SE/ME/2000

Automatically

Precaution for Windows 98SE, 2000,

and ME users: If the Application setup in

Installation the Utility under

Windows98SE/ME/2000 has been

completed, follow below steps to install the

hardware.

For Windows 98SE users: As you

perform the installation, have your system

operating CD-ROM at hand. You may be

asked to insert the OS CD-ROM for the

system to download a specific driver.

1. Plug the square end (Type B) of USB

cable into the adapter's USB port.

2. Plug the rectangle end (Type A) of USB

cable into the PC's USB port.

3. Insert one end of your network cable into

the RJ-45 network port. Connect the other

end of the cable into a Hub.

After the device has been connected to your

computer, Windows will detect the new

hardware and then automatically copy all of

the files needed for networking.

Precaution for Windows 2000 users:

When Digital Signature Not Found

screen appears, click Yes to continue.

- 2 -

- 3 -

Manually

If you want to install the Hardware

before installing the utility, please follow

the below section.

Under Windows 98SE

1. In Add New Hardware Wizard, click

Next.

2. Click Search for the best driver for your

device (Recommended).

3. Insert the device driver CD-ROM into the

CD-ROM drive. Select Specify a location:

and click Browse to provide the

appropriate path (e.g. D:\Win9xMe).

Click Next.

4. Click Next, Windows will copy all the

necessary files to your system.

5. Insert Windows 98SE CD-ROM.

6. Click Finish to continue.

7. When Windows prompts you to restart

your computer, click No.

8. Repeat step 1-6.

9. When Windows prompt you to restart

your computer, click Yes.

Then go to Installation the Utility under

Windows98SE/ME/2000 section for installing

the utility.

Under Windows ME

1. Select Specify the location of the driver

(Advanced),click Next.

2. Insert the device driver CD-ROM into the

CD-ROM drive. Select Search for the

- 4 -

best driver for your device

(Recommended) and click Browse to

provide the appropriate path (e.g.

D:\Win9xMe). Click Next.

3. Click Next, Windows will copy all the

necessary files to your system.

4. Click Finish to continue.

5. When Windows prompts you to restart

your computer, click No.

6. Repeat step 1-4.

7. When Windows prompt you to restart

your computer, click Yes.

Then go to Installation the Utility under

Windows98SE/ME/2000 section for installing

the utility.

Under Windows 2000

1. In Found New Hardware Wizard, click

Next.

2. In Install Hardware Device drivers,

click Search for a suitable driver for my

device (Recommended).

3. Insert the device driver CD-ROM into the

CD-ROM drive. Select CD-ROM drivers

and Specify a location.

4. Click Browse to provide the appropriate

path (e.g. D:\Win2kXP). Click OK.

5. Click Next, Windows will copy all the

necessary files to your system.

6. Click Yes to continue the installation.

7. Click Finish to continue.

8. Repeat step 1-6.

9. Click Finish.

10. Restart your computer.

- 5 -

Then go to Installation the Utility under

Windows98SE/ME/2000 section for installing

the utility.

Precaution for Windows XP users: You

must install the Adapter's hardware first,

and then go to Installation of the USB

Adapter for Windows XP.

Installation of the USB Adapter

for Windows XP

1. Once the device is well connected to your

computer, Windows XP will automatically

detect the new device. Click Install from

a list of specific location and click Next.

2. Insert the Setup Utility CD-ROM into the

CD-ROM drive. Select Include this

location in the search: and click

Browse to provide the appropriate path

(e.g. D:\Win2kXP). Click Next.

3. Click Continue Anyway to proceed.

4. Click Finish to continue the Utility

installation.

5. Wait for seconds. Windows XP will

automatically detect the new hardware.

Click Install from a list or specific

location (Advanced) and click Next.

6. Select Include this location in the search:

and click Browse to provide the

appropriate path (e.g. D:\Win2kXP).

Click Next.

7. Click Continue Anyway to proceed.

8. Click Finish to complete the Utility

installation.

Configuration Procedure

Configuration and Monitor Utility

for Windows 98SE/ME/2000

After installing the device successfully, go to

Start ÆPrograms Æ802.11 Wireless +

USB 10&100 LAN ÆConfiguration and

Monitor Utility.

The Wireless LAN Monitor Utility icon will

appear in the taskbar every time the device is

running. You can open it by double-clicking on

this icon.

Icon Status

Mode Icon Link Status

Red. The station is not

associated to an Access

Point.

Access Point

mode

Blue. The station

associates itself to an

Access Point.

Red. The color is red

only when the card is

during resetting or

initializing procedure.

Peer-to-Peer

mode

Blue. Peer-to-Peer mode

is activated.

Note:Except for the following

configuration utility, using Windows to

configure the wireless network settings in

the Windows XP is recommended. (Please

skip to the Configuration for Windows

XP section)

- 6 -

- 7 -

All settings are categorized into 6 tabs:

Monitor

Statistics

Site Survey

Encryption

Advanced

Version

The Status tab will display the current status of

the Wireless USB Adapter.

Monitor

Item Description

Operating

Mode

It displays the current operating

mode. (Access Point or Peer-to

-Peer).

Channel It shows the selected channel that is

currently used. (There are 14

channels available, depends on the

country.)

SSID The SSID is the unique name shared

amon

all

oints in

our wireless

Item Description

network. The name must be identical

for all devices and points attempting

to connect to the same network.

It shows the current SSID setting of

the Wireless USB Adapter.

Tx Rate It shows the current transfer rate. (1,

2, 5.5, or 11Mbps or Auto)

Int. Roaming It displays the current roaming

status. (Disabled or Enabled)

Radio It displays the current status of the

Wireless USB Adapter. (On or Off)

Status It displays the information about the

status of the communication (the

BSSID of the Access Point to which

the card is associated).

Signal

Strength

It displays the signal strength of the

connection between the Wireless

USB Adapter and the Access Point it

connects.

Link Quality It displays the link quality of the

connection between the Wireless

USB Adapter and the Access Point it

connects.

Change Click Change to change the

configuration parameters such as

Operating Mode, SSID, Tx Rate,

and Int. Roaming. (In Peer-to-Peer

mode, Channel button is enabled).

Submit Click Submit to save the changes.

Cancel Click Cancel to ignore the previous

setting.

Hide Click Hide to exit the application.

- 8 -

Table des matières

Autres manuels Abocom Adaptateur

Abocom

Abocom WU5206 Manuel utilisateur

Abocom

Abocom PLE0085I Manuel utilisateur

Abocom

Abocom FE2000 Manuel utilisateur

Abocom

Abocom Wireless USB Adapter WUB1500 Manuel utilisateur

Abocom

Abocom WBD512 Manuel utilisateur

Abocom

Abocom RE450 Manuel utilisateur

Abocom

Abocom FE1500 Manuel utilisateur

Abocom

Abocom WUE1500MNL Manuel utilisateur

Abocom

Abocom USB Home PhoneLine 1Mbps Network Adapter Manuel utilisateur

Abocom

Abocom 1M HomePNA Ethernet Adapter HB2000 Manuel utilisateur

Abocom

Abocom RE450MX Manuel utilisateur

Abocom

Abocom WUG2200 Manuel utilisateur

Abocom

Abocom Bluetooth Wireless USB Adapter UBT1000 Manuel utilisateur

Abocom

Abocom UBT1K Manuel utilisateur

Abocom

Abocom HP2000 Manuel utilisateur

Abocom

Abocom UFE2000 Manuel utilisateur

Abocom

Abocom WU5202 Manuel utilisateur

Abocom

Abocom WU5200 Manuel utilisateur

Abocom

Abocom WU5214 Manuel utilisateur

Abocom

Abocom PCMCIA Instructions de montage

Abocom

Abocom 802.11 b/g/n Mini Wireless LAN USB 2.0 Adapter... Manuel utilisateur

Abocom

Abocom PA1040 Manuel utilisateur

Abocom

Abocom UBT1000H Manuel utilisateur

Abocom

Abocom UFT128 Manuel utilisateur

Manuels Adaptateur populaires d'autres marques

PCB Piezotronics

PCB Piezotronics 090B274 Manuel utilisateur

Auvidea

Auvidea J20 Manuel du produit

Gossen MetraWatt

Gossen MetraWatt AT3-III E Manuel utilisateur

Akribis

Akribis ITF-21-BISS-MIT Manuel utilisateur

Tenda

Tenda W54U Manuel utilisateur

ROHO

ROHO AGILITY Manuel utilisateur

PROLiNK

PROLiNK WN2001 Manuel utilisateur

Hawking

Hawking HUF2 Manuel utilisateur

Airlink101

Airlink101 AWLC4030 Manuel utilisateur

NETGEAR

NETGEAR XAV101v1 - Powerline AV Ethernet Adapter Manuel utilisateur

Philips

Philips SWA4554S/10 Manuel utilisateur

JVC

JVC TS-C9D2B Manuel d'instructions

NETGEAR

NETGEAR A6100 Manuel utilisateur

D-Link

D-Link DWA-121 Manuel utilisateur

Philips

Philips SWA2037 Manuel utilisateur

Basalte

Basalte 0610-20 Manuel utilisateur

Yealink

Yealink EHS40 Manuel utilisateur

Balluff

Balluff BIC 1B0-IT1A7-Q40KFU-SM4A4A Manuel utilisateur
