SE6 Motherboard User’s Manual

Index

TABLE OF CONTENTS

CHAPTER 1. INTRODUCTION OF SE6 FEATURES

1-1. FEATURES OF THIS MOTHERBOARD 1-1

1-2. SPECIFICATIONS 1-2

1-3. LAYO UT DIAGRAM 1-4

1-4. THE SYSTEM BLOCK DIAGRAM 1-5

CHAPTER 2. INSTALLING THE MOTHERBOARD

2-1. INSTALLING THE MOTHERBOARD TO THE CHASSIS 2-2

2-2. INSTALLATION OF THE PENTIUM





III CPU 2-3

2-3. INSTALLING SYSTEM MEMORY 2-4

2-4. CONNECTORS, HEADERS AND SWITCHES 2-6

CHAPTER 3. INTRODUCING THE BIOS

3-1. CPU SETUP [SOFT MENU™II] 3-4

3-2. STANDARD CMOS FEATURES SETUP MENU 3-11

3-3. ADVANCED BIOS FEATURES SETUP MENU 3-16

3-4. ADVANCED CHIPSET FEATURES SETUP MENU 3-21

3-5. INTEGRATED PERIPHERALS 3-25

3-6. POWER MANAGEMENT SETUP MENU 3-31

3-7. PNP/PCI CONFIGURATIONS 3-40

3-8. PC HEALTH STATUS 3-43

3-9. LOAD FAIL-SAFE DEFAULTS 3-45

3-10. LOAD OPTIMIZED DEFAULTS 3-45

3-11. SET PASSWORD 3-46

3-12. SAV E & EXIT SETUP 3-48

3-13. EXIT WITHOUT SAV I N G 3-49

APPENDIX A INF INSTALLATION UTILITY FOR WINDOWS®98 SE

APPENDIX B: INSTALLING THE VGA DRIVER FOR WINDOWS®98

APPENDIX C INSTALLING THE AUDIO DRIVER FOR WINDOWS®

98 SE

APPENDIX D ATA INSTALLATION UTILITY FOR WINDOWS®98

APPENDIX E INSTALLING THE VGA DRIVERS FOR THE

WINDOWS®NT 4.0 SERVER / WORKSTATION

APPENDIX F INSTALLING THE AUDIO DRIVERS FOR THE

WINDOWS®NT 4.0 SERVER / WORKSTATION

APPENDIX G ATA INSTALLATION UTILITY FOR THE WINDOWS®

NT 4.0 SERVER / WORKSTATION

APPENDIX H INF INSTALLATION UTILITY FOR THE WINDOWS®

2000 SERVER / WORKSTATION

APPENDIX I: INSTALLING THE VGA DRIVERS FOR THE

WINDOWS®2000 SERVER / WORKSTATION

APPENDIX J: INSTALLING THE AUDIO DRIVERS FOR THE

WINDOWS®2000 SERVER / WORKSTATION

APPENDIX K: ATA INSTALLATION UTILITY FOR THE WINDOWS®

2000 SERVER / WORKSTATION

APPENDIX L BIOS FLASHING USER INSTRUCTIONS

APPENDIX M HARDWARE MONITORING FUNCTION

(INSTALLING THE WINBOND HARDWARE DOCTOR

UTILITY)

APPENDIX N INSTALLATION GUIDE FOR SUSPEND TO RAM

APPENDIX O TROUBLESHOOTING (NEED ASSISTANCE?)

APPENDIX P HOW TO GET TECHNICAL SUPPORT

Introduction of SE6 Features 1-1

User’s Manual

Chapter 1. Introduction of SE6 Features

1-1. Features of This Motherboard

The SE6 Motherboard is designed for use with Intel’s new generation of Pentium Processors,

which utilize the FC-PGA (Plastic Pin Grid Array), 370-pin design. Up to 512MB of

memory can be supported.

The SE6 uses the new Intel 815E chipset. Its’ 133 MHz capable memory interface supports

the wide range of PC 133 memory devices now on the market. Its 133MHz capable front-

side bus delivers a clear upgrade path to the future generation of 133MHz processors. The

SE6 offers Ultra ATA/100. This provides speedier HDD throughput that boosts overall

system performance. Up to four IDE devices can be supported by your system. These can be

either Ultra ATA/33 IDE devices, Ultra ATA/66 IDE devices or Ultra ATA/100 IDE devices.

A Digital Video Out Interface supporting digital display and TV Out are options. The SE6

also has an integrated AC’97 2.1 CODEC onboard. This CODEC is complete with a H/W

Sound Blaster ProAC’97 digital audio controller that gives you the best sound quality and

compatibility. The chipset includes integrated 2X 3D Graphics Acceleration. For those

wanting even greater graphics performance, an AGP slot is included on the board. The AGP

Slot will support a 4MB display cache AGP In-line Memory Module (AIMM). AIMM is a

lower cost alternative to a video card.

With 2 USB ports as well as capability of expanding to 4 USB slots, the SE6 meets future

USB demands. A Communication / Network Riser Slot (CNR Slot) is found on the SE6. The

CNR Slot provides audio, modem and network connectivity. The specification’s main

objective is to reduce the cost of audio and modem functionality.

The SE6 has built-in hardware monitoring functions (refer to Appendix M for detailed

information). This will monitor and protect your computer, ensuring a safe computing

environment.

This motherboard provides high performance for servers while also meeting the

requirements for desktop systems; both now and into the future.

1-2 Chapter1

SE6

1-2. Specifications

1.CPU

!Supports Intel®Pentium®III 500 ~ 1GHz processors (Based on FC-PGA package)

!Supports Intel®Celeron®300A ~ 733MHz processors (Based on 66MHz PPGA &

FC-PGA package)

!Supports 66, 100, and 133MHz CPU external clock speeds.

!Reserves support for future Intel Pentium®III processors.

2. Chipset

!Intel 815E chipset

!Supports 66/100/133MHz (Front Side Bus)

!Supports AGP 1X/2X/4X (Sideband) 1.5V/3.3V device

!Supports Advanced Configuration and Power Management Interface (ACPI)

!Supports UDMA 33/66/100 and feature specification devices

3. Graphics

!Chipset integrated 2X 3D graphics acceleration

!Support 4MB display Cache AIMM ( AGP In-line Memory Module )

4. Memory

!Three 168-pin DIMM sockets support SDRAM module

!Supports up to 512MB MAX. (32, 64, 128, 256MB SDRAM)

!Support 100MHz , 133MHz SDRAM interface (No 66Mhz support)

5. Audio

!AC’97 Digital Audio controller integrated

!AC’97 Audio CODEC on board

!Audio driver included

6. System BIOS

!SOFT MENU™ II eliminates the need for jumpers or DIP switches to set CPU

parameters

!Award Plug and Play BIOS supports APM and ACPI

!Write-Protect Anti-Virus function by AWARD BIOS

Introduction of SE6 Features 1-3

User’s Manual

7. Multi I/O Functions

!2 Channels of Bus Master IDE Ports supporting Ultra DMA 33/66/100 and future

specification devices

!PS/2 Keyboard and PS/2 Mouse Connectors

!1x Floppy Port (up to 2.88MB)

!1x Parallel Port (EPP/ECP)

!2x Serial Ports

!2x USB Connectors

!2x USB Headers (Optional connecting cable available)

!Audio connector (Line-in, Line-out, Mic-in, and Game Port)

8. Miscellaneous

!Support STR(Suspend to DRAM)

!ATX form factor

!1 Universal AGP slot, 6 PCI slots and 1CNR slot

!Hardware Monitoring – Including Fan speed, Voltages, CPU and System temperature

and one thermal header for other devices temperature monitoring

!Keyboard and Mouse Power On

!Built-in Wake on LAN/Open Chassis header

!Built-in IrDA TX/RX header

!Digital Video out interface adds support digital display or TV out (Option)

"Supports Wake On LAN, Modem, but your ATX power supply 5V standby power

must be able to provide at least a 720mA current capacity. Otherwise, the functions

may not work normally.

#Specifications and information contained in this manual are subject to change

without notice.

Note

All brand names and trademarks are the property of their respective owners.

1-4 Chapter1

SE6

1-3. Layout Diagram

Figure 1-1. SE6 Motherboard component location

Introduction of SE6 Features 1-5

User’s Manual

1-4. The System Block Diagram

Figure 1-2. System diagram of the INTEL 815E Chipset

1-6 Chapter1

SE6
