ABB TruONE ATS Guide de l'utilisateur

—

Automatic transfer switches

34OX_30-1600 rev. B / 1SCC303011M0201

INSTALLATION AND OPERATING INSTRUCTION

Automatic transfer switches

TruONE® ATS, OX_ 30. . .1600_

—

Receiving, handling and storage

Receiving and handling

Upon receipt, carefully inspect the switch

for damage that may have occurred

during transit. If damage is evident, or

there is visible indication of rough han-

dling, immediately file a damage claim

with the transportation company, and no-

tify your local ABB sales office.

Do not remove the shipping package until

ready to install the switch.

Storage

If the unit will not be placed into service

immediately, store the switch on its origi-

nal package in a clean, dry location. To

prevent condensation, maintain a uniform

temperature. Store the unit in a tempera-

ture controlled building, allowing ade-

quate air circulation and protection from

dirt and moisture. Storing the unit out-

doors could cause harmful condensation

inside the switch enclosure.

HAZARD OF EQUIPMENT

OVERTURNING

When moving with a fork lift, do not re-

move the shipping package until the de-

vice is in its final location.

Failure to follow this instruction will

result in personal injury or equipment

damage.

Warning

4TruONE® ATS, INSTALLATION AND OPERATING INSTRUCTION

—

Read these safety instructions

carefully before using this product!

HAZARD OF ELECTRIC SHOCK,

EXPLOSION, OR ARC FLASH

• Wear appropriate personal protective

equipment and follow safe electrical

work practices.

• This equipment must only be installed

and serviced by qualified electrical per-

sonnel.

• Disconnect all sources of electrical sup-

ply before performing visual inspec-

tions, tests, service or maintenance on

the equipment. Assume that all circuits

are live unless they are completely

de-energized, tested, grounded, and

tagged. Pay particular attention to the

design of the power system. Consider

all sources of power, including the pos-

sibility of backfeeding.

• Turn off switch before removing or mak-

ing load side connections.

• Always use a properly rated voltage

sensing device at all line and load to

confirm switch is off.

Failure to follow these instructions could

result in death or serious injury.

HI-POT OR DIELECTRIC TEST

• Performing a hi-pot or dielectric test on

the power section, REMOVE the mecha-

nism from the switch.

• See details in Service Instruction

manual.

Danger

General warning

34OX_30-1600 rev. B / 1SCC303011M0201

—

Installation and

operating instruction

Automatic transfer

switches, TruONE® ATS

INSTALLATION INSTRUCTIONS,

TRUONE® ATS, OX_30…1600

CHAPTERS 8–10

OPERATING INSTRUCTIONS,

TRUONE® ATS, OX_30…1600

CHAPTERS 1–7

6TruONE® ATS, INSTALLATION AND OPERATING INSTRUCTION

34OX_30-1600 rev. B / 1SCC303011M0201

—

Operating instruction

Automatic transfer

switches, TruONE® ATS

1. Introduction 11

1.1 Use of symbols in manual

1.2 Explanations of abbreviations and terms

2. Product overview 13

2.1 General overview 14

2.1.1 Differences of level types /

operation types and suitability

of Ekip-modules 15

2.2 HMI 17

2.3 TruONE® ATS feature comparison 18

2.4 Typical applications 21

2.5 Description of basic functionality 23

2.5.1 Switching sequence / Automatic 23

2.5.2 Automatic configuration 29

2.5.3 In-phase monitor 29

2.5.4 Powering supply scenarios 29

8TruONE® ATS, INSTALLATION AND OPERATING INSTRUCTION

3. Operating 30

3.1 Position indication 30

3.2 Operating and locking 31

3.3 Manual mode, operating by the handle 32

3.4 Automatic mode, operating by HMI 34

3.5 LED functionality in HMI 35

3.6 Using Level 2 (DIP) control interface HMI 37

3.6.1 Keypad 37

3.6.2 Configuration by DIP-switches 38

3.7 Using Level 3 (LCD) control interface HMI 40

3.7.1 Keypad 40

3.7.2 Navigating in menu 40

3.8 Using Level 4 (touch) control interface HMI 41

3.8.1 Keypad 41

3.8.2 Navigating in menu 41

4. Navigating menu 42

4.1 Level 3 (LCD) control interface, menu tree 42

4.1.1 Start screens 44

4.1.2 Enter key, main menu 45

4.1.3 Esc key 55

4.2 Level 4 (touch) control interface, menu tree 56

4.2.1 Start Menu 58

34OX_30-1600 rev. B / 1SCC303011M0201

5. Electronic accessories 73

5.1 Using Ekip Connect -software 74

5.2 Using Ekip Bluetooth-module 75

5.2.1 Signallings 75

5.3 Using Ekip Programming -module 76

5.3.1 Signallings 76

5.4 Auxiliary power supply module 77

5.4.1 Electrical characteristics 77

5.4.2 Signallings 77

5.5 Using Ekip Signalling 2K-_ -module 78

5.5.1 Electrical characteristics of 78

Ekip Signalling 2K-_ -module

5.5.2 Access from the display / 78

Ekip Signalling 2K-_ -module

5.5.3 Signals and inputs/outputs 81

of Ekip Signalling 2K-_ -module

5.6 Using Ekip Com _ -modules 82

5.6.1 Ekip Com Modbus RTU -module 82

5.6.2 Ekip Com Profibus DP -module 85

5.6.3 Ekip Com DeviceNet -module 89

5.6.4 Ekip Com Modbus TCP -module 93

5.6.5 Ekip Com Profinet -module 97

5.6.6 Ekip Com EtherNet/IP -module 100

5.6.7 Ekip Com IEC 61850 -module 104

5.6.8 Ekip Com Hub -module 108

10 TruONE® ATS, INSTALLATION AND OPERATING INSTRUCTION

6. Troubleshooting 112

6.1 Alarms 112

6.2 Warnings 114

6.3 Information 115

7. Technical data 116

7.1 Circuit diagrams 119

Table des matières
