ABB ACF-NT Manuel utilisateur

ACF-NT, ACF-NT V0309

Multicomponent Analyzer Systems for Emission and Process Monitoring

Operator’s Manual 42/23572 EN Rev. 5

42/23-572 EN Rev. 5 Operator’s Manual ACF-NT, ACF-NT V0309 3

Contents

Page

Foreword 4

Important Safety Information 5

Safety Tips for Handling Electronic Measurement Devices 6

Safety Tips for Handling the FTIR Spectrometer 7

Safety Tips for Handling the VOC Analyzer 8

Safety Tips for Handling Harmful Gases 8

Special Information about the System Design for Measurement of HF 9

Chapter 1 Startup

Restart 10

Chapter 2 Operation

Display/Control Unit 11

“Measured Values” Screen 12

“Control Panel” Screen 13

“Diagnosis” Screen 15

“Ranges” Screen 16

“ASP Module” Screen 17

“Multi-FID” Screen 18

“Flow” Screen 19

Changing the Password 20

Chapter 3 Maintenance

Safety Notes 21

Cleaning Hints 21

Visual Inspection 22

Seal Integrity Check 23

Wear Part Replacement 24

Replacing the Filter Element in the Probe 25

Cleaning/Replacing the Sample Gas Filter in the SC Block 28

Replacing the Air Purifier Inlet Filter 30

Replacing the Air Conditioner Filter Mesh 30

Calibration 31

FTIR Spectrometer Zero Calibration 33

FTIR Spectrometer Span Check 35

Oxygen Analyzer Calibration 36

VOC Analyzer Calibration 37

Status Messages 38

Taking the Analyzer System Out of Service 39

Appendix

Operating Specifications 40

Index 41

4 Operator’s Manual ACF-NT, ACF-NT V0309 42/23-572 EN Rev. 5

Foreword

The Content of this

Manual

This manual contains all the information you will need to safely and efficiently

operate and maintain the analyzer system.

This manual contains information on all the functional units in the analyzer system.

Your analyzer system as delivered may differ from the version described in this

manual.

System

Documentation

The system documentation consists of a set of drawings individually prepared for

each analyzer system as delivered. It includes the following plans:

Layout Plan

Piping Plan

Wiring Plan

Terminal Plan

Connection Plan

The system documentation is supplied as part of the analyzer system.

Title Publication No.

Specification Sheet 10/23-8.11 EN

Supplementary

Documentation

Installation Instructions 42/23-571 EN

These publications can be ordered from your authorized ABB representative or

from

ABB Automation GmbH,

Analytical, Marketing Communication,

Telefax: +49-(0)69-7930-4566, E-mail: [email protected]

Additional Information

on the Internet

Additional information on ABB Analytical products and services is available on the

Internet at “http://www.abb.com/analytical”.

indicates safety information to be heeded during analyzer system

operation in order to avoid risks to the user.

identifies specific information on operation of the analyzer system as

well as on the use of this manual.

1, 2, 3, … identifies reference numbers in figures.

Display identifies a display on the screen.

Symbols and Type

Format in this Manual

Input identifies input from the user.

This manual is protected by copyright. The right is reserved to pursue civil or criminal penalties if this

publication is translated, reproduced (by electronic or mechanical means, photocopying, recording, etc.),

stored in information retrieval systems or networks or transmitted in any form without the permission of

the copyright holder.

42/23-572 EN Rev. 5 Operator’s Manual ACF-NT, ACF-NT V0309 5

Important Safety Information

Proper Operation The analyzer system is designed for continuous measurement of concentrations

of specific components in gases or vapor.

Explosion Protection The analyzer system must not be used to measure combustible gas/air or gas/

oxygen mixtures. The analyzer system must not be installed in hazardous locations.

Requirements for

Safe Operation

In order to operate in a safe and efficient manner, the analyzer system should be

properly handled and stored, correctly installed and set-up, properly operated and

carefully maintained.

Personnel

Qualifications

Only persons familiar with the installation, set-up, operation and maintenance of

comparable analyzer systems and certified as being capable of such work should

work on the system.

Special Information

and Precautions

These include

The content of this manual.

The safety labels affixed to the analyzer system.

The applicable safety precautions for installing and operating electrical devices

Safety precautions for working with gases, acids, condensates, etc.

Observe the safety labels affixed to the analyzer system:Safety Labels

Affixed to the

Analyzer System

Consult

Documentation!

Hot Surface!

(Temperature

> 60 °C)

Risk of

Electric Shock!

National Regulations The regulations, standards and guidelines cited in this operator’s manual are

applicable in the Federal Republic of Germany. The applicable national regulations

should be followed when the analyzer system is used in other countries.

Analyzer System

Safety and Safe

Operation

The analyzer system is designed and tested in accordance with EN 61010 Part 1/

IEC 1010-1, “Safety Provisions for Electrical Measuring, Control, Regulation and

Laboratory Instruments” and has been shipped ready for safe operation.

To maintain this condition and to assure safe operation, read and follow the safety

information identified with the symbol in this manual. Failure to do so can put

persons at risk and can damage the analyzer system as well as other systems and

instruments.

Additional

Information

If the information in this manual does not cover a particular situation, ABB Service

is prepared to supply additional information as needed.

Please contact your local service representative. For emergencies, please contact

ABB Service

Telephone: +49-(0)180-5-222580, Telefax: +49-(0)621-38193129031,

E-mail: [email protected]

6 Operator’s Manual ACF-NT, ACF-NT V0309 42/23-572 EN Rev. 5

Safety Tips for Handling Electronic Measurement Devices

Protective Lead

Connection

The protective lead should be attached to the protective lead connector before

any other connection is made.

Risks of a

Disconnected

Protective Lead

The analyzer system can be hazardous if the protective lead is interrupted inside

or outside the system or if the protective lead is disconnected.

Correct Operating

Voltage

Be sure the analyzer system voltage setting matches the line voltage before

connecting the power supply.

Risks Involved in

Opening the Covers

Current-bearing components can be exposed when covers or parts are removed,

even if this can be done without tools. Current can be present at some connection

points.

Risks Involved in

Working with an

Open Analyzer

System

The analyzer system must be disconnected from all power sources before being

opened for any work. All work on an analyzer system that is open and connected

to power should only be performed by trained personnel who are familiar with the

risks involved.

Charged Capacitors The capacitors in the analyzer system can retain their charge even when it is

disconnected from all power sources.

Use of Proper Fuses Only fuses of the specified type and rated current should be used as replace-

ments. Never use patched fuses. Do not short-circuit the fuse holder contacts.

When safe operation

can no longer be

assured …

If it is apparent that safe operation is no longer possible, the analyzer system

should be taken out of operation and secured against unauthorized use.

The possibility of safe operation is excluded:

If the analyzer system is visibly damaged

If the analyzer system no longer operates

after prolonged storage under adverse conditions

after severe transport stresses

42/23-572 EN Rev. 5 Operator’s Manual ACF-NT, ACF-NT V0309 7

Safety Tips for Handling the FTIR Spectrometer

Electrical Safety The FTIR Spectrometer consists of an exposed metal chassis that is connected

directly to earth via a power supply cord and is therefore classified as “Safety

Class I” equipment.

WARNING!

When used to analyze flammable gases, the equipment is subject to

acceptance by the local inspection authorities having jurisdiction.

For continued fire protection use specified line fuse only. Disconnect power

cord before replacing fuse.

To avoid electrical shock, the power cord protective conductor must be

connected to earth.

To avoid electrical shock, do not operate this equipment if it bears any sign

of damage to any portion of its exterior surface.

Do not expose this equipment to any source of excessive moisture.

Do not use this equipment in an explosive atmosphere.

Laser and

High Voltage

Under normal operating conditions, the FTIR spectrometer can be operated in

complete safety (Class 1 Laser Product – see rating plate).

Do not open the spectrometer enclosure during normal operation – no user-

serviceable parts inside.

However, since the instrument contains a laser and uses high voltages (accessible

only when the spectrometer enclosure is open), observe the following warnings.

WARNING!

The enclosure of the spectrometer is to be opened only by authorized ABB

Service Personnel.

Opening the enclosure may result in exposure to laser radiation and high

voltages.

Laser type: He-Ne Laser Class 3B as per IEC-60825-1

Class 111a as per 21 C F R 1040.10

Output power: max. 3.2 mW

Wavelength: 632.8 nm

Avoid eye exposure to direct to direct or mirrored laser radiation. It is

recommended to wear laser safety goggles when working on the open

spectrometer.

High voltage is present at the red wire connected to the laser tube inside the

enclosure.

The voltage is approximately 7 kV at startup, and between 1200 V and 1400 V

under normal operating conditions.

Because of the capacitors in the laser power supply, the high voltage may be

present even when the power is off.

8 Operator’s Manual ACF-NT, ACF-NT V0309 42/23-572 EN Rev. 5

Safety Tips for Handling the VOC Analyzer

DANGER!

Do not open any threaded connections in the VOC analyzer gas paths. Doing

so will damage gas path seal integrity.

Combustion gas flowing out of the leak points thus formed in the internal gas

paths can cause fire and explosions (even outside the VOC analyzer itself).

If device-internal gas path threaded connections are opened, a seal integrity

check must be performed with a leak detector (thermal conductivity) when

the device is reassembled.

CAUTION!

The combustion gas path inside the VOC analyzer is checked for leaks at the

factory. No seal integrity testing is required during normal operation.

Safety Tips for Handling Harmful Gases

WARNING!

Some of the gases measured with the analyzer system are harmful to health.

Therefore, the sample gas must not escape from the gas path during normal

operation and maintenance works.

A seal integrity check of the analyzer system has to be performed at regular

intervals.

The diluted exhaust gas must be drained out of the installation room of the

analyzer cabinet.

42/23-572 EN Rev. 5 Operator’s Manual ACF-NT, ACF-NT V0309 9

Special Information about the System Design for Measurement of HF

Type Designation ACF-NT V0309

Design of the

Analyzer System

The analyzer system is equipped with a cooling unit which ensures the reliable

operation of the analyzer in a temperature range from 20 °C to 25 °C. The cooling

device guarantees these conditions in an ambient temperature range between

+5 °C and +40 °C.

Operating System

and Software

Versions

The analyzer system must be operated with the following software versions:

FTIR Controller: WindowsXP Professional operating system

FTSW 100: Software version 2.61

AO2000 System Controller: Software version 3.0.6

Maintenance Interval The maintenance interval for the HF sample component is 3 months.

Check of

Water Vapour

Cross-Sensitivity

Checking the water vapour cross-sensitivity must be ensured (see also section

“Calibration”, page 31):

during initial start-up by the manufacturer’s or the supplier’s qualified personnel,

in the annual functional tests by an accredited measurement institute as per

EN 17025.

Use of FFKM Probe

Seals

The filter on the gas sampling probe has FFKM seals.

When they are replaced (see section “Replacing the Filter Element in the Probe”,

page 25), FFKM seals must also be used. For quick replacement, it is recom-

mended that a complete, preassembled filter element be kept at the ready. The

following wearing parts are required:

Module Part No. Comments

Filter stone 730682 The two FFKM O-ring seals from part

number 801994 must be used.

FFKM seal set 801994 Two O-ring seals on the filter stone

FFKM seal set 730722 Filter fixing device with three O-ring seals

The measurement of other components is not affected by the system version for

the measurement of HF sample components.

10 Operator’s Manual ACF-NT, ACF-NT V0309 42/23-572 EN Rev. 5

Chapter 1 Startup

Restart

Initial startup of the analyzer system should be performed by trained personnel of

the manufacturer or the supplier.

Restart Perform the following steps when restarting the analyzer system e.g. after

maintenance or a facility shutdown.

Activating the

Instrument Air Supply

Set the initial pressure (pe= 5–7 bar).

Check the moisture indicator in the air purifier: green = OK, yellow = not OK.

Activate the instrument air supply to the FTIR spectrometer at the earliest 1 hour

after activating the power supply. This will ensure the air is sufficiently dry.

Activating the

Power Supply

Make sure all circuit breakers (fuses) are deactivated.

Turn on the main switch.

Activate the circuit breakers (fuses) – starting with those for the FTIR

spectrometer.

Connecting the

Filtered Air

Check the filtered spectrometer purge air flow rate and set it to approx. 200 l/hr

if necessary.

Checking the

Temperature

Check the temperature of the heated components (gas sampling probe, filter

unit and sample gas line; desired value 180 °C).

Starting the

VOC Analyzer

Start the VOC analyzer following the instructions and information in the AO2000-

MultiFID14 Start-up and Maintenance Manual (Publication No. 41/24-105 EN).

Warm-Up Phase The warm-up phase takes approx. 3 hours.

Calibration Start the manual zero correction (see section “FTIR Spectrometer Zero

Calibration”, page 33).

Autres manuels pour ACF-NT

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels ABB Instrument de mesure

ABB

ABB ReliaGear ASPMETER A 42 Manuel d'installation et d'exploitation

ABB

ABB C1900 Series Manuel utilisateur

ABB

ABB AC211 Manuel utilisateur

ABB

ABB Sensyflow iG Manuel utilisateur

ABB

ABB Advance Optima Caldos 15-Ex Manuel utilisateur

ABB

ABB VLMD-1-2 Manuel utilisateur

ABB

ABB EL3000 Series Manuel utilisateur

ABB

ABB B21 Manuel utilisateur

ABB

ABB Relion 630 Series Fiche technique

ABB

ABB LS4000 Manuel utilisateur

ABB

ABB EIB Delta Manuel utilisateur

ABB

ABB VA Master FAM540 Manuel de formation

ABB

ABB FMT200-ECO2 Manuel utilisateur

ABB

ABB ProcessMaster FEP630 series Manuel utilisateur

ABB

ABB AquaMaster IM9 Manuel utilisateur

ABB

ABB SmartMedia SM2000 Instructions d'installation

ABB

ABB Kent-Taylor AquaProbe Manuel utilisateur

ABB

ABB Endura AZ20 series Manuel utilisateur

ABB

ABB SensyMaster FMT230 Manuel d'installation et d'exploitation

ABB

ABB Relion 670 series Manuel utilisateur

ABB

ABB ScreenMaster RVG200 Manuel utilisateur

ABB

ABB SR100A Manuel utilisateur

ABB

ABB PGC1000 Manuel utilisateur

ABB

ABB B23 Manuel utilisateur

Manuels Instrument de mesure populaires d'autres marques

Suaoki

Suaoki D40 Manuel utilisateur

Elster

Elster BK-G1.6 Manuel utilisateur

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manuel

Duratool

Duratool D03128 Manuel utilisateur

Vega

Vega VEGAPULS 65 Manuel utilisateur

Tonghui

Tonghui TH2618B Manuel utilisateur

Tenmars

Tenmars TM-801 Manuel utilisateur

MSR

MSR 145 Manuel utilisateur

TPS

TPS WP-82 Manuel utilisateur

ELMETRON

ELMETRON CP-511 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 003C30 Manuel utilisateur

Tenma

Tenma 72-10465 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Promag 50 Caractéristiques techniques

Siemens

Siemens SITRANS F Coriolis FCT030 Manuel de la liste des pièces

KLINGER

KLINGER CMF V Series Manuel utilisateur

EXFO

EXFO FTB-2 Manuel d'exploitation et d'entretien

Keysight

Keysight M8290A Manuel utilisateur

ADTEK

ADTEK MW-5 Manuel utilisateur
