AAXA Technologies Showtime 3D Manuel utilisateur

aaxa

TECHNOLOGIES

User Guide

LED Showtime 3D

Caution!

WARNING: Please use this product as instructed. Misuse may cause

injury or death.

DO NOT use while driving

DO NOT expose to water or wet

surfaces. Electric shock may occur.

DO NOT expose the projected LED

image to your eyes or the eyes of

others

DO NOT block or restrict airow

from ventilation holes as this may

cause the projector to overheat

Keep the projector, or charger away

from any heat sources

Caution for Headphones Use

• Prolonged use at high volume may

impair your hearing.

• High volume during walking or driving

may cause distractions and result in

injury or death

Table of Contents

Chapter 1: Showtime at a Glance

Main Unit Front/Back

Remote & Keypad

Accessories

Chapter 2: Getting Started

Powering On / OFF

Focus Adjustment / Throw

Distance

Connecting to a Computer VGA

Connecting to a Computer HDMI

Connecting to Composite Video

Connecting to HDMI Video

Connecting to HDMI 3D Video

Connecting to External Sound

Connecting to a USB Host

Chapter 3: Menu Screens

Onboard Player Main Menu

Video Player Menu

Video FAQ

Photo Viewer Menu

Photo FAQ

Music Player Menu

Music FAQ

Ebook Viewer Menu

Setup Menu Screens

Keystone Adjustments

Chapter 4: 3D Setup Guide

Required Hardware

Installing Graphics Card

Technical Details

Showtime at a Glance

Chapter 1

Headphone Out

USB Port

Main Unit Front/Back

VGA Port

AV Input

Power Button

HDMI

Focus Adjustment

AC Power Input

Remote & Keypad

Power On/Off

Mute

Directional Pad

Exit/Back

Power Button

Both the keypad and remote can be used to navigate through the menus. The Main Menu

Navigation on the remote functions exactly the same as the directional pad on the LED Show-

time 3D unit.

Volume Control

Source

Playback Menu

Navigation Settings

Setting

Exit / Back

Accessories

*Under various circumstances, the actual accessories may be different from

those shown in the pictures above.

Remote Power Adapter A/V Cable

Getting Started

1. Connect the power cord to the LED Showtime 3D.

2. Connect the wall plug into the wall power source.

3. Press the button on the top of the projector or remote control to start the projec-

tor. The button’s LED light will light blue when the projector is on.

Powering ON the projector

Chapter 2

Powering OFF the projector

1. Press the button on the keypad or remote to put the projector in “Stand by mode”.

The optical engine should power off and the fan should stop spinning. The projector

can be turned on using the remote control. “Stand by mode” consumes a little bit of

power

2. To fully turn off the projector, press the button on top of the projector until the

power light turns red. Disconnect the power adapter from the power socket to fully

turn off the projector.

Power Socket

Focus Adjustment / Throw Distance

Focus Adjustment

• Move the focus knob left or right until

the image becomes clear.

DIAGONAL SCREEN SIZE

16:9 Aspect Ratio

Throw Distance Chart

Distance inch (“)

Diagonal Inch (“)

Throw Ratio 1.22

*minimum throw distance: 21 inches

Connecting to a Computer via VGA

Connect the end of the

VGA Cord

to your computer’s

VGA Adapter

Connect the end of the

VGA Cord

to your LED

Showtime 3D’s

VGA Adapter

Step 1:

Step 2:

Step 3:

In the Main Menu

Select “VGA” iconSelect “INPUT” icon

Connecting to a Computer Cont.

Step 4:

Enabling VGA or HDMI output on your Computer – To enable VGA or HDMI output on your

computer most computers require “turning on” the video output feature. Each computer is different.

Please consult your owner’s manual for instructions to enable VGA or HDMI output. Below are

standard instructions for a Windows 7 computer – not all systems are the same.

Press function & “F5” to instruct

the computer to enable multiple

displays.

You can also press Windows+P to

toggle through display settings.

*NOTE: different operating sys-

tems may differ

Step 5:

1. Right click on computer

desktop and select “Screen

Resolution”

2. Display Screen Resolution

window will pop up

3. The secondary monitor (2) is

the projector’s display.

4. If the image is blurry or the

text is not legible, adjust

the screen resolution. We

recommend 1280x800.

Step 6:
