Radio Wireless Wheel Mouse

User’s Guide

MODEL: RFSW-35

—1—

Trademark Recognition

Windows, Office 97 and MS-IntelliMouse are registered trademarks of Microsoft Corp.

MN-RFSW35-NC

THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES.

OPERATION IS SUBJECT TO THE FOLLOWING TWO

CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL

INTERFERENCE AND (2) THIS DEVICE MUST ACCEPT ANY

INTERFERENCE RECEIVED, INCLUDING INTERFERENCE

THAT MAY CAUSE UNDESIRED OPERATION.

Federal Communications Commission Requirements

The equipment has been tested and found to comply with the limits for Class

B Digital Device, pursuant to part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful interference in a

residential installation. This equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in accordance with the

instruction, may cause harmful interference to radio communication.

However, there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one or

more of the following measures:

lReorient of relocate the receiving antenna.

lIncrease the separation between the equipment and receiver.

lConnect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

lConsult the dealer or an experienced radio/TV technician for help.

The changes or modifications not expressly approved by the party

responsible for compliance could void the user's authority to operate the

equipment.

—2—

Congratulations on your purchase! Your new RF-Mouse is easy to install and offers

you a host of useful features. The Radio receiver can be conveniently placed to give

you the freedom you need while working. The vertical wheel allows you to scroll, or

zoom in and out in a document. You can program the mouse buttons to launch the

NetJump or LuckyJump for a quick start to programs you run frequently. And, your

RF-Mouse has a unique ID code, so other RF (Radio Frequency) pointing devices

won’t affect your system.

Connecting the RF-Mouse Receiver

The RF-Mouse receiver connects to your

computer in the same way as a conventional

mouse allowing you to place the receiver

wherever is convenient on your desktop.

1.Locate the round 6-pin PS/2 mouse port on the

back of your computer.

2.Insert the PS/2 connector into the PS/2 port.

Locating the RF-Mouse Receiver

Your RF-Mouse has limitations on the range or distance from

the receiver. To make sure that your mouse sends and receives

properly, refer to the following:

1. For optimal performance, place the receiver at least 8

inches (20 centimeters) away from other electrical

devices, such as the computer, the monitor, or external

storage drives.

2. The RF-Mouse should be no farther than 3.3 feet (1.0

meter) from the mouse receiver. This will ensure optimal

communication between the mouse and receiver.

3. If you are working on a metallic surface, try using a

mouse pad and turning the receiver face down for better

reception.

4. Switch frequency channels to prevent interference from

other RF pointing devices. (See the following section for

more information.)

Selecting the Frequency Channel

—3—

The RF-Mouse operates on

two frequency channels. To

prevent interference when

using two RF Mice in close

proximity a different frequency

channel should be used for

each mouse. Refer to the

following to change the

frequency channel for your

mouse:

1. Set the frequency channel

on the receiver to 1 or 2.

2. Remove the battery cover

from the mouse (see the

following Inserting the

Batteries section).

3. Set the frequency channel

on the mouse to 1 or 2.

(The frequency channel for

mouse and receiver must be

the same.)

—4—

Inserting the Batteries

The RF-Mouse uses two AAA batteries. For

best performance, use only alkaline

batteries. Refer to the following to insert

the batteries:

1. Press the tab on the bottom of the

mouse cover as shown here and

remove the cover.

2. Insert the two AAA batteries. (The

correct polarity is indicated on the

battery compartment casing.)

3. Replace the cover.

Checking the Batteries power

To check the battery power, right-click the

mouse icon in the Taskbar. Choose the

“Check RF-Mouse Status”option to display

the RF-Mouse Status window. The current

battery percentage charge is shown.

Installing the Mouse Software

Before you can take advantage of the many features your mouse offers, you must

install the driver. The driver is on the installation diskette that came packaged with

your mouse.

Windows 95/98/2000/NT4.0 installation

1. Connect the mouse to your computer.

2. Insert the installation diskette into your floppy disk drive.

3. Click the Start button and then click Run.

4. In the Run dialog window, type A:\setup, where “A”is the letter of your

floppy disk drive.

5. Click OK and follow the instructions on your screen to complete the

installation.

The RF-Mouse ID code

Each RF-Mouse is assigned a unique ID code at manufacture, so the receiver only picks

up the signal from your mouse and prevents other RF-Mouse radio signals from

operating on your computer. This feature can also be disabled, allowing other RF-

pointing devices to operate your computer.

Connecting the RF-Mouse ID Code

—5—

When the driver installation is finished your

computer reboots and the RF-Mouse

window (shown on the right) appears.

CONNECT ID: Move the RF-Mouse for a

few seconds to establish a connection, then

click Connect ID. The unique ID code of

your mouse is recognized and another RF

pointing device will not function on your

computer.

Exit: Click Exit if no other RF pointing

devices are within 3 meters range or if you

want other RF pointing devices to be able to

access your computer.

Changing the RF-Mouse ID Code

You can use a new RF-Mouse on your computer without changing the Radio receiver;

you just need to change the ID code. Refer to the following:

1.Press [Shift + Alt + F11] or [Shift + Alt + F12] to call up the RF-Mouse ID Code

window.

2.Move the RF-Mouse for a few seconds to establish a connection, then click Connect

ID.

3.The new ID code is Connected and the RF-Mouse window closes.

4.Click Exit to close the RF-Mouse ID code window.

Identifying Components

The mouse is designed to fit snugly into your hand. The scroll

wheel is positioned on the top allowing for easy operation with

the index finger. Standard mouse buttons are positioned to either

side of the scroll wheels and can be reached comfortably with the

index and ring fingers. A third button is placed under the vertical

wheel and can be easily clicked by pushing down on the wheel.

The following pages will tell you how to configure the scroll

wheels and buttons to suit your specific needs.

Cleaning the Mouse

Clean the mouse regularly to ensure efficient operation. Refer to the following:

—6—

1. Rotate the housing cover counterclockwise until it unlocks

and remove it.

2. Remove the tracking ball.

3. Wash the tracking ball with warm water and soap then

allow it to dry.

4. Use a cotton swab and alcohol to clean the tracking rollers

in the housing.

5. Replace the tracking ball and the housing cover.

6. Rotate the housing cover clockwise until it locks in place.

—7—

With the iWheelWorks software, you have all the advantages of the Microsoft

IntelliMouse wheel, and but you can also scroll in Windows 95/98/2000/NT.

Your mouse has a wheel; the wheel functions as both a wheel and a button. Simply click

the wheel as you would a programmable standard Third button.

Task What is it? How to do it?

Wheel

Scroll Use wheel Scroll

for precise up

and down

movement.

To scroll up, move the wheel

forward; to scroll down, move the

wheel back.

Zoom Use Zoom to

either magnify or

demagnify the

view of a

document in an

application that

supports it.

Place the cursor in an application

that is Microsoft Office 97/2000

compatible. Press and hold the

Ctrl key on the keyboard, then to

zoom in, move the wheel forward;

to zoom out, move the wheel

backwards.

AutoScroll UseAutoScroll in

Windows

95/98/NT/2000

and Microsoft

Office97/2000

compatible

applications to

scroll through

large documents.

AutoScroll

allows you scroll

a document

automatically

without having to

move the mouse

continuously.

Assign AutoScroll to a button on

the mouse if it is not already

assigned.

Place the cursor in an application,

Press the mouse button assigned to

AutoScroll. The AutoScroll icon

appears.

Move the mouse once in the

direction you want to scroll. The

farther you move the pointer from

the starting point, the faster the

scrolling.

To stop AutoScroll, press any

mouse button.

—8—

From the Mouse Properties window you can

customize many settings for your mouse including

button assignments, scroll wheels and cursor

movement. To open the Mouse Properties

window double-click on the mouse icon in the

system tray. The Mouse Properties window has

six tabs that are described below.

System

Tray

Buttons Tab

Button Assignments: Click the down arrow to select the

preferred function for each button. (See the Settings Tab for

more information.)

Double Click Speed: Increase the speed for executing a

double-click.

Button Configuration: Configure your mouse for left- or

right-hand use. The default setting for buttons 1 and 2 will be

reversed.

Pointers Tab

The Pointers tab lets you change the way the cursor appears.

Click the down arrow under Scheme and choose the setting

you want. The available pointers for each scheme are shown

in the pane below. You can browse to additional pointers,

then create your own scheme using the Save As button.

Motion Tab

Pointer Speed: Lets you adjust how fast the cursor moves on

the screen.

SnapTo Button: Check this box to automatically have the

cursor move to the default button in each new dialog box or

window.

Sonar: When this box is checked, pressing and releasing the

[Ctrl] key will highlight the cursor.

Trails: Check this box when you want your cursor to display

pointer trails. This option is useful when using an LCD

display that can make the cursor difficult to see.

Settings Tab

—9—

Command List: Shows all the available commands (including

User-defined Command Menus) that you can assign to either

the NetJump or LuckyJump grids.

NetJump (top grid): The NetJump grid groups commonly

used Web-browsing commands. To change a command, select

a new one from the Command List and click on the icon in

the grid that you want to change.

LuckyJump (bottom grid): The LuckyJump grid groups all-

purpose commands. To change a command, select a new one

from the Command List and click on the icon in the grid that

you want to change.

Wheel: Check the Reverse scrolling direction box to change

the scrolling direction when you turn the scroll wheel. Select

the Scroll or Scroll one “page”per scroll unit radio button to

set the scrolling speed to suit your work habits.

Autres manuels A4Tech Souris

A4Tech

A4Tech G9-370HX Manuel utilisateur

A4Tech

A4Tech GL-6630 Manuel utilisateur

A4Tech

A4Tech G9-630 Manuel utilisateur

A4Tech

A4Tech G6-70MD Manuel utilisateur

A4Tech

A4Tech Wireless Optical Zoom Mouse Manuel utilisateur

A4Tech

A4Tech RFSWOP-80 Manuel utilisateur

A4Tech

A4Tech RFSOP-533 Manuel utilisateur

A4Tech

A4Tech RFW-23 Manuel utilisateur

A4Tech

A4Tech G3-230 Manuel utilisateur

A4Tech

A4Tech G9-550FX Manuel utilisateur

A4Tech

A4Tech G6-19 Manuel utilisateur

A4Tech

A4Tech G7-300 Manuel utilisateur

A4Tech

A4Tech G7-630 Manuel utilisateur

A4Tech

A4Tech NB-60 Manuel utilisateur

A4Tech

A4Tech RFSW-53 Manuel utilisateur

A4Tech

A4Tech G9-557HX Manuel utilisateur

A4Tech

A4Tech G9-555FX Manuel utilisateur

A4Tech

A4Tech RFMSW-15 Manuel utilisateur

A4Tech

A4Tech R7 PowerSaver Manuel utilisateur

A4Tech

A4Tech G9-600FX Manuel utilisateur

A4Tech

A4Tech XL-750BH Manuel utilisateur

A4Tech

A4Tech Wireless 1-Wheel Mouse Manuel utilisateur

A4Tech

A4Tech G7-740NX Manuel utilisateur

A4Tech

A4Tech N-400 Manuel utilisateur

Manuels Souris populaires d'autres marques

Sven

Sven RX-G720 Manuel utilisateur

3DConnexion

3DConnexion CadMouse Pro Manuel utilisateur

Canyon

Canyon Puncher GM-20 Manuel utilisateur

Sharkoon

Sharkoon Light2 180 Manuel utilisateur

Cherry

Cherry MW 8C ERGO Manuel utilisateur

NGS

NGS HIT RB Manuel utilisateur

Sharkoon

Sharkoon FireGlider Manuel utilisateur

Lenovo

Lenovo Wireless Mouse N3902 Manuel utilisateur

BASETech

BASETech BN-S11 Manuel utilisateur

Dell

Dell WM326 Manuel utilisateur

Areson

Areson B213 Manuel utilisateur

HP M17587-371 Manuel utilisateur

Chatpen

Chatpen CHA-30 Manuel utilisateur

GAMDIAS

GAMDIAS DEMETER GMS5000 Manuel utilisateur

HP KJ453AA - Wireless Laser Mouse Manuel utilisateur

Trust

Trust GRAPHIN GXT 960 Manuel utilisateur

Lenovo

Lenovo SD-9082 Manuel utilisateur

Alienware

Alienware AW320M Manuel utilisateur
