ZyXEL Communications P-320W Manuel utilisateur

Secure Broadband Sharing

802.11g Wireless Firewall Router

p-320w

Benefits

Cost-effective 4-in-1 Firewall Router

ZyXEL P-320W is a firewall router with 4-port switch for sharing Internet

access.The built-in IEEE 802.11g Access Point allows you to connect wireless

devices to the network.With the powerful SPI firewall, the P-320W provides

security protection for home computers surfing the Internet.

Wireless Security Setting: It’s That Easy

Why wireless security features are important? Security features are

important to prevent unauthorized or unknown users from sharing your

Internet connection and to protect personal or private information on your

network. ZyXEL’s One-Touch Intelligent Security Technology (OTIST)

automatically establishes a wireless connection and set up the highest level

of security available between the P-320W and any ZyXEL OTIST-enabled

wireless clients.

Complete Protection for Home Network

As a fully-equipped,broadband-capable device, the P-320W is a robust

firewall providing enterprise-class security features:Denial of Service (DoS)

protection and Intrusion Detection using Stateful Packet Inspection (SPI).

In addition, the P-320W allows VPN pass-through to provide a safe

access to Internet.

router

ł

Cost-effective 4-in-1 Broadband Sharing Router

ł

One Touch Intelligent Security Technology (OTIST) for

Quick Wireless Security Setup

ł

Stateful Packet Inspection (SPI) Firewall with

Denial-of-Service (DoS) Protection

802.11g Wireless

Firewall Router

p-320w

65-100-032001G 10/05

System Requirement

• Broadband (cable, DSL, satellite or wireless) Internet

service and modem with Ethernet RJ-45 connector

• Ethernet connection (adapter or cable)

• Windows, Mac or Linux based operating system

• Internet Explorer 6.0 or later

WLAN Standard

• IEEE 802.11g/b compliance

Security

• 64/128-bit WEP Encryption

• WPA (Wi-Fi Protected Access) support

Antenna

• 2dBi antenna

Memory Size

• 1MB Flash, 2MB DRAM

Hardware Specifications

• LAN: Four 10/100Base-T Ethernet, full duplex RJ-45

connector with auto MDI/MDIX support

• WAN:One 10/100Base-T Ethernet, full duplex RJ-45

connector with auto MDI/MDIX support

• Power Supply: 12V AC, 1 A

• Reset Button

• OTIST Button

Physical Specifications

• Dimensions: 115(W) x 162(D) x 33(H) mm

• Weight: 250g

Environmental Specifications

• Temperature: 0˚C ~ 50˚C

• Humidity: 20% ~ 95% (non-condensing)

Specifications

P-320W

802.11g Wireless Firewall Router

G-162

Wireless CardBus Card

G-220F

Wireless USB Adapter

G-360

Wireless PCI Adapter

Application Diagram

ADSL/Cable Modem

ZyXEL One-touch Intelligent Security

Technology (OTIST) functions between

ZyXEL“One-touch Intelligent Security”

enabled wireless devices only.

Internet

other brands, product names, or trademarks mentioned are the property of their respective owners. All specifications are subject to change without notice.

For more product information, visit us on the web www.ZyXEL.com
