ZyXEL Communications G-4100 v2 Manuel utilisateur
All-in-One Wireless
Hotspot Solution for
Hospitality Venues
G-4100 v2
All-in-One Wireless Hotspot
Solution for Hospitality Venues
Integrated Hotspot Service
Scalable User Authentication and
Accounting
Rich Networking Functions
Customized Login Page,
Advertisement URL Link and Walled
Garden Features
Benefits
All-in-One Hotspot Gateway
ZyXEL G-4100 v2 is an all-in-one hotspot gateway that provides free or charged secure Internet access
according to your business’s policies. It provides authentication and accounting functions for both wireless
and wired clients, and supports up to 100 concurrent users. The G-4100 v2 works with ZyXEL’s SP-300E
statement printer to generate and print tickets with account, password, and pre-configured time for
Internet access hours automatically through a few button clicks on SP-300E. All functions required for
hotspot services are self-contained in the G-4100 v2 making it the perfect broadband access solution for
hotels, inns, coffee shops, bed-and-breakfasts, and other multi-guest locations.
Scalable, Easy-to-Manage User Authentication and Accounting
With an easy-configuration authentication server embedded in the G-4100 v2, no additional hardware or
software are required for hotspot operators to offer Internet services. The G-4100 v2 also supports
RADIUS server for large-scale hotspot service deployments in chain stores or airport terminals to provide
roaming service from one spot to another through centralized authentication and accounting features.
Best Hotspot User Experience with Security and Privacy
The G-4100 v2 features rich networking functions such as IP PnP, DHCP server, NAT, MAC address and IP
address filtering. The IP PnP technology enables the ultimate “zero configuration” user experience by
transparently taking care of the IP networking, which dramatically improves user satisfaction and reduces
technical support needs. The user no longer needs to change the IP address, subnet mask, default
gateway, Web proxy or even SMTP server settings. Moreover, V-LAN security for wired and wireless
client, NAT, Layer 2 isolation, as well as MAC and IP address filtering technologies also work behind the
scenes to ensure protected user privacy, keeping sensitive personal data from being exposed to the public.
Tailor-Made Hotspot Gateway for the Hospitality Industry
With powerful marketing features built into the G-4100 v2, operators can customize the login page,
redirect user to advertisement links, or provide limited Internet access to the designated home page.
Additionally, powerful management features such as SSL login page, secure remote function, LAN and
WLAN device management are all specifically designed for hotspot offerings. For easy deployment, the
G-4100 v2 and SP-300E supports Power over Ethernet (PoE), so the hotspot solution can be freely placed
regardless of the power outlet location. The G-4100 v2 is not only a gateway tailor-made for hotspot
deployments, but also customizable to fit business and service needs.
Specifications
IP Plug and Play (iPnP technology)
• Easy-to-Use, Zero Configuration IP Plug and
Play Internet Access
Rich Networking Functions
• NAT
• Outgoing SMTP Server Redirection
• DNS Redirection
• Various WAN connections
(Static IP/DHCP Client/PPPoE/PPTP)
• DHCP Server
• Transparent HTTP Proxy
• NTP (Network Time Protocol) support
User Authentication and
Accounting
• Supports up to 100 concurrent users
• Web-based Authentication
• Idle-timeout Control
Security and Firewall
• Layer 2 Isolation Security
• SSL Login Page and Administration
• VPN (IPSec/PPTP/L2TP) Pass through
• Pass through IP and MAC Address
• Custom SSL Certificate
• Administration Access Control
Management
• Web-based management tool
• TFTP/HTTP firmware upgrade
• Central scheduled firmware upgrade
• Backup/Restore Configuration file
• WLAN/LAN devices Management
• Devices Status Monitor
• Session List
• Syslog Messaging System
• Default printer (SP-300E) support
Marketing Cooperation
• Passthrough IP/MAC/URL
• Custom Login Page
• Login Page Redirect
• Advertisement URL link
• Walled garden
• Portal page redirection
Hardware Specifications
Network Specification
• IEE802.3 10BaseT Ethernet
• IEE802.3u 100BaseTX Fast Ethernet
• IEE802.11g Wireless LAN
Connectors
• 4 LAN Ports and One WAN Port
• 10/100BaseTX with auto MDI/MDI-X
• RS-232 port (For debugging and testing
purpose only)
Wireless Data Rate
• Up to 54 Mbps with auto fallback with 802.11b
Encryption
• WEP 64/128,WPA-PSK
Physical Specifications
External Antenna Type
• 2dBi (Max) Dual detachable diversity antenna
with reverse SMA connector
Power Requirement (G-4100 v2)
• External Power Adapter
- Input: 100-240 VAC, 50/60 Hz, 0.35 A
- Output: 5V, 2A
• 802.3af POE
• Dimensions: 8.4 (W) x 5.5 (D) x 2 (H) in
212.5 (W) x 138.5 (D) x 52.0 (H) mm
• Weight: 1lb (508 g)
LED Indicators
• One POWER LED
• One WAN Link/Activity LED
• Four LAN Link/Activity LEDs
• One Sys LED
• One Blue Wireless Link/Activity LED
Environmental Specifications
Environment Conditions
• Operating Temperature: 32˚F ~ 122˚ F
0˚C ~ 50˚C
• Storage Temperature: -22˚ F ~ 140˚F
-30˚C ~ 60˚C
• Humidity: Max. 90% non-condensing
Copyright © 2009 ZyXEL Communications Corp. All rights reserved. ZyXEL, ZyXEL logo are registered trademarks of ZyXEL Communications Corp.All other
brands, product names, or trademarks mentioned are the property of their respective owners. All specifications are subject to change without notice.
65-100-410003B 10/09
For more product information, visit us on the web at www.ZyXEL.com
Application Diagram
WEP Encryption
WPA
Web-based Authentication
G-4100 v2
xDSL/Cable
Modem
SP-300E
VPN Pass Through
Internet
P-600series
LANDSL INTERNET
1234
PWR/SY
PW
PWR
R/SY
SY
S
ZyAIR
SP-300E Printer
• Cable Type: Ethernet, up to 100 meters
• Thermal Paper: FD410, 58mm width, 50m length
• Roll Diameter: 63mm outside, 12mm inside
Power Requirement (SP-300E)
• External Power Adapter
- Input: 100-240 VAC
- Output: 5V, 2.5A
- 802.3af POE
- Dimensions: 4.3(W) x 6(D) x 3.5(H) in
109(W) x 155(D) x 90(H) mm
