ZyXEL Communications PLA450 v2 Manuel utilisateur

Power Up Your Wireless Network

Benefits

Wireless Super G Technology Doubles Standard 802.11g

Data Rate Up to 108 Mbps

ZyXEL PLA450 v2 offers capability of 802.11b/g wireless standards.User is

able to use 2.4GHz frequencies for wireless connection experience and

flexibility. Simply plug the PLA450 v2 to extend the Powerline Network with

Supper G up to 108M performance. Users are free in wireless now.

Data Rates of Up to 200 Mbps

The PLA450 v2 is an access extension solution for your house to be

completely networked with existing power lines.Thanks to the advanced

HomePlug AV Technology,the PLA450 v2 is capable of transmitting data at

up to 200 Mbps. It allows you to share network resources and enjoy Internet

access through secure high-speed data connection over the house power

lines you already have.

High Speed and QoS for High Definition Video Streams

The inherited advanced QoS features make HomePlug AV Series ideal

access tools for service providers to deliver“triple play”multimedia services

such as high-quality digital video streams, high-speed Internet access and

voice services.

ł

Data Rates of Up to 200 Mbps Over

Powerline

ł

Centralize Control All the Powerline Device

ł

Advanced 128-bit AES Security Network Protection

ł

Super G Technology is the Optimal Wireless Range

and Performance of Up to 108Mbps Data Rate

ł

HomePlug Instant Encrypt Button to Secure Your

Powerline Network

ł

Multi-colored LED to Indicate Data Transmission

Rates Over Powerline

HOMEPLUG

Powerline Wireless

Ethernet Access Point

PLA450 v2

Application Diagram

For more product information, visit us on the web at www.ZyXEL.com

65-100-045002B 01/08

product names, or trademarks mentioned are the property of their respective owners.All specifications are subject to change without notice.

System Specifications

•

AV 200 Mbps

twork

Netw

k Standard

d: HomePlug A

compliance

ce Data Rat

ate

•

ol Modulation,

Modulation: O

OFDM Sym

ymbol

6/64/16, DQPSK,

Supports QAM 1

M 1024/256

ier modulation schemes

DBPSK and ROBO

O Carrie

•

7 MHz to 30 MHz

Frequency Band: 1.7 M

•

p to 300 meters

Coverage Area: up t

•

t AES encryption

Security: 128 bit A

•

11b/g with super G

Wireless: 802.1

Hardware Specifications

• Interface: 10/100 Mbps Ethernet port with MDI/MDIX

• One Power Input:100-240 VAC, 50/60 Hz, 0.2 A (Max)

• LED Display on Top-Case:

- Power

- Powerline Link and Activity

- Ethernet Link and Activity

- Security Status

- Wireless Enable or Disable

- LED throughput indication

Physical Specifications

• Dimensions: 162 (W) x 118 (D) x 35 (H) mm

• Weight: 310 g

Environmental Specifications

Operation Environment

• Temperature: 0ºC ~ 40ºC

• Humidity: 20% ~ 95% RH

Storage Environment

• Temperature: -20ºC ~ 60ºC

• Humidity: 20% ~ 95% RH

Certification

• Safety: UL/cUL, LVD

• EMI: CE,FCC part 15B ,ICID

• HomePlug Certification: HomePlug AV

Specifications

Centralize Control all the Powerline Device

entralize Powerline products.The devices management function presents all the existing Powerline

s an interface for user to cen

Friendly GUI design

nterface for user to ce

n provides a

in your network. Easy t

ge your network.

to manag

Advanced 128-bit AES Security Protection

S) feature, the PLA450 v2 provides secure network connection for Internet access and resource sharing. Just

rity (AES)

With the 128-bit Data

curit

ata Encryp

ption Secu

nd enjoy the fast surfing experience as well as secure file transfer over the internet.

ack an

leave the sweats t

s to the PLA

sit ba

LA450 v2, sit

Powerline Wireless

Ethernet Access Point

PLA450 v2

Powerline

Adapter

Stereo

Gaming

Internet

Ethernet

Extension

3Network Backbone/

Contents Sharing

Network Backbone/

Contents Sharing

ine Bac
