Ultimate Wireless Network

Deployment with 4-in-1

802.11g Wireless AP/Bridge

g-570s

Benefits

Wireless AP, Bridge, Repeater and Wireless Client

4-in-1 Design

Designed for home and small office,ZyXEL G-570S 4-in-1 Access Point with

Wireless Super G technology is capable of boosting data throughput to as

high as 108Mbps.The 4-in-1 design,featuring Access Point, Repeater, Bridge

and Wireless Client modes, provides superior flexibility for wireless network

deployment. Detachable antenna and adjustable transmit power make the

G-570S the best price/performance choice for different application

scenarios in homes and small offices.

Ultra Fast and Secure Wireless Performance

The ZyXEL G-570S is compliant with the 802.11g standard allowing wireless

data throughput of 54Mbps.With the ZyXEL’s “Wireless Super G”mode

enabled, the wireless connection speed between G-570S and Super G-

enabled wireless clients will be boosted to an astounding *108Mbps

instantly. Better yet, with WPA/WPA2/WPA2-PSK encryption technology, the

compact G-570S provides enhanced, interoperable wireless network

security for uncompromised data transmission.

Setup in a Snap

With ZyXEL’s exclusive One-touch Intelligent Security Technology (OTISTTM)

activated,the highest level of security will be automatically established

between G-570S and OTIST-enabled wireless clients to protect the wireless

traffic from hackers or unauthorized users.

ł

Operation Modes: AP, Repeater, Bridge and

Wireless Client

ł

“Wireless Super G”Technology Doubles Standard

802.11g Data Rate to up to *108Mbps

ł

Simplifies Wireless Security Setting with OTIST

Technology Support

ł

Robust Security Protection with WPA/WPA2, 802.1x

and 152-bit WEP Encryption

wire

ess

802.11g Wireless AP/Bridge

g-570s

65-100-057001G 10/05

Standard

• IEEE 802.11b standard compliant

• IEEE 802.11g standard compliant

Memory Size

• 4MB Flash, 16MB DRAM

Hardware Specifications

• One 10/100Base-T Ethernet, full-duplex with auto

MDI/MDIX support

• Power Supply: 12V DC,1A

• One Reverse SMA antenna connector (detachable)

• Reset Button

• OTIST Button

Physical Specifications

• Dimensions: 112.1(W) x 106(D) x 28.5(H) mm

• Weight: 203g

Environmental Specifications

• Temperature: 0ºC ~ 50ºC

• Humidity: 20% ~ 95% (non-condensing)

System Requirement

• Broadband (cable, DSL, satellite or wireless) Internet

service and modem with Ethernet RJ-45 connector

• Ethernet connection (adapter or cable)

• Windows, Mac OS or Linux-based operating system

• Internet Explorer 5.0 or later

* When the Wireless Super G Technology is enabled with

Multi-Channel 108 Mbps Turbo mode, the theoretical data

rate can reach up to 108Mbps among ZyXEL Wireless Super

G-enabled access points and clients. Actual performance

may vary depending on different operating environment.

Specifications

ridge Mode

Bridge Mod

G-570S Repeater Mode

G-570S Bridge Mode

G-570S Client Mode

2nd Floor

1st Floor

Ground Floor

Application Diagram
