Key Features

Ł

Multilayer-aware (L2/L3/L4) ACL

for Security Protection and

Traffic Optimization

Ł

Policy-based QoS Optimizes

Multi-service Quality

Ł

VLAN Stacking (Q-in-Q) Support

for Layer-2 VPN

Ł

Remote Management via IEEE

802.3ah (OAM)

Ł

IPTV Manipulated by MVR and

IGMP Snooping v3

Ł

Minimizes Channels Surfing

Disturbance with Fast Leave

Ł

ZyXEL iStacking™ Technology

Ł

Backup Power System Support

The ZyXEL Switch 3000 Series consists of full-featured Fast Ethernet switches that provide

comprehensive Layer-2 switching capabilities. With multi-layer security, intelligent QoS,

redundant design, quick recovery and convenient network management features,the ZyXEL

Switch 3000 Series are the best Edge switches for enterprises to build reliable, high-

performance networks.

The Switch 3000 Series consists of three models: ES-3124,ES-3124PWR, and ES-3148.The ES-

3124 is a Layer-2 Fast Ethernet managed switch and ES-3124PWR is a Layer-2 Fast Ethernet

managed switch with the Power-over-Ethernet feature.They are the best edge switches for

SME with advanced features like intelligent management, comprehensive security and high-

performance QoS.The ES-3148 is an intelligent high-density Layer-2 managed switch aiming

for networks requiring high QoS and triple-play performance, network security and resiliency

in markets such as enterprises,educational institutes and public sectors.

Key Benefits

Intelligent QoS for Multi-Service Optimization

Harnessing cost-cutting IP applications such as VoIP, IPTV and video conferencing in today’s

modern business environment makes a big difference in market advantages.The Switch 3000

Series provides superior QoS capability to fully utilize the power of applications. Features like multi-

layer (L2/L3/L4) ACL,8 priority queues, DSCP and WFQ scheduling algorithm allow you to maximize

network bandwidth usage and to provide superior network service quality.With support to MVR

and IGMP snooping features,the Switch 3000 Series enables successful IP TV multicasting

transmission across multi-VLAN environments. In addition, Fast Leave eradicates streaming quality

disturbance when user surf between different channels, while bandwidth control with granularity

of 64 kbps brings effortless bandwidth administration to network operators.

Complete Multi-layer Protection

The Switch 3000 Series comes with a 4-layer protection framework against network threats.Multi-

layer (L2/L3/L4) ACL enables policy-based protection by setting (L2/L3/L4) parameters such as

MAC,VLAN, IP Protocol,TCP/UDP, and DSCP. The 4K VLAN range allows maximum administrative

freedom on the network. For device access control, MAC freeze and MAC filtering can be

configured and the number of MAC addresses on a port can be limited as well.Besides user

authentication, IEEE 802.1x provides central network access management and offers further access

control on VLAN, bandwidth and traffic priority queues.The intrusion lock feature on the Switch

3000 Series is designed to prevent unauthorized access, and supports to VLAN Stacking can be

applied for enterprise-class L2VPN applications.The Switch 3000 Series allows you to implement

stricter Layer-1 to Layer-4 security policies.

erne

POWER

12VDC

RESET

CONSOLE

WDS

WLAN

ETHN

PWR/SYS

XGS 4526

10G Switc

124PW

E PoE Switc

-314

tch

GbE Uplink

10G Connection

Server

Aggregation

Core

Network

Edge

Network WLAN AP

GbE Fiber

Human Resources

VLAN 10

Finance

VLAN 20

Sales & Marketing

VLAN 30

POWER

12VDC

RESET

CONSOLE

WDS

WLAN

ETHN

PWR/SYS

WLAN AP

POWER

12VDC

RESET

CONSOLE

WDS

WLAN

ETHN

PWR/SYS

WLAN AP

XGS-4526

10G Switch

0G S

XGS-4528F

10G Switch

G Stacking

0G S

Server

Farm Server

Farm

WALL U

G 10

Unified Securit

atewa

ES-3124PWR

FE Switch

Convenient, Hassle-free Network Management

ZyXEL’s exclusive iStacking™ technology allows you to manage a switch cluster of up to 24 ZyXEL switches through a single master ZyXEL Switch, and

various network management options like Web,Telnet and the console port are supported.Network administrators can choose to manage the switch

using the friendly Web-based configuration or the convenient text-based CLI (Command Line Interface). Since the Switch 3000 Series supports centralized

SNMP-based management software, maintenance tasks can be performed remotely, and this also helps reducing operating cost and improving efficiency.

For security, SSHv1/v2 and SSL are used to encrypt management sessions.With these sophisticated features,network administrators can set up powerful

corporate networks and streamline their management efforts.

High Redundancy and Quick Recovery

The Switch 3000 Series comes with comprehensive features to ensure round-the-clock network operations.With backup power system support, power is

supplied to the switch in case of any unexpected power outage.The IEEE 802.3ad Link Aggregation feature reduces network downtime by providing

redundant paths and bandwidth aggregation to critical connections. By utilizing unique design of 4Gb uplink with trunking function, you can enjoy not

only superb transmission bandwidth, but also extra-secure paths for critical transmission by aggregating Gigabit ports. IEEE 802.1w Rapid Spanning Tree

Protocol (RSTP) and IEEE 802.1s Multiple Spanning Tree Protocol (MSTP) allow immediate recovery from failed links by sending packets via the backup link.

Enterprise LAN

Switches

Switch 3000 Series

Enterprise LAN

Switches

Switch 3000 Series

Key Applications

Specifications

Features

Standard Compliance

• IEEE 802.3 10Base-T Ethernet

• IEEE 802.3u 100 Base-Tx Ethernet

• IEEE 802.ab 1000 Base-T Ethernet

• IEEE 802.3z

• IEEE 802.3x flow control

• IEEE 802.1D spanning tree protocol

• IEEE 802.1w rapid spanning tree protocol

• IEEE 802.1s multiple spanning tree protocol

• IEEE 802.1p class of service, priority protocols

• IEEE 802.1Q VLAN tagging

• IEEE 802.1x port authentication

• IEEE 802.3ad LACP aggregation

• IEEE 802.1ad VLAN stacking

• IEEE 802.3af power over Ethernet

Traffic Management and QoS

• Bandwidth control/rate limiting: policy-based/

port-based bandwidth control, 64 kbps

granularity ingress/egress

• Supports Dual-Rate-Three-Color marking

• Port-based egress traffic shaping

• Broadcast storm control

• Congestion control on all ports

• IEEE 802.1p with 8 hardware priority queues per

port for different types of traffic

• WFQ (Weighted Fair Queuing)/WRR/SPQ

scheduling algorithm

• DSCP to 802.1p priority mapping

• IGMP snooping v1, v2, v3

• MVR (Multicast VLAN Registration)

• BPDU transparency

Link Aggregation

• IEEE 802.3ad LACP link aggregation compliant

• Static manually port trunking

• Up to 6 aggregation groups,per group support

up to 8 ports

Resilient Network

• IEEE 802.1w Rapid Spanning Tree Protocol (RSTP)

• MRSTP—Multiple RSTP

• IEEE 802.1s multiple spanning tree provides link

availability in multiple VLAN environments by

allowing multiple spanning trees

• BPS (Backup Power System) power supply

redundancy

Model ES-3124 ES-3124PWR ES-3148

Product Photo

Port Density

10/100Base-TX 24 - 48

10/100Base-TX PoE - 24 -

1000Base-T 2 2 2

Dual Personality GbE Ports 2 2 2

Performance

Switching Capacity 12.8 Gbps 12.8 Gbps 17 Gbps

Switching Forwarding Rate 9.6 Mpps 9.6 Mpps 13.1 Mpps

Packet Buffer 32 MB 32 MB 32 MB

MAC Address 16K 16K 16K

Power Requirement

Input Voltage od AC AC Power: 100 to 240 V, 50/60 Hz AC Power: 100 to 240 V, 50/60 Hz AC Power: 100 to 240 V, 50/60 Hz

DC Power: -48 to -60 V DC

Max Power Rating of AC 60 Watt 600 Watt 60 Watt

Max Power Consumption 26.5 Watt 436 Watt 39.7 Watt

Environmental Specification

Operating Temperature 0°C ~ 45°C 0°C ~ 45°C 0°C ~ 45°C

Storage Temperature -25°C ~ 70°C -25°C ~ 70°C -25°C ~ 70°C

Operating Humidity 10% ~ 90%, (non-condensing) 10% ~ 90%, (non-condensing) 10% ~ 90%, (non-condensing)

Physical Feature

Dimensions, (W) x (D) x (H) mm 438 x 270 x 44.45 438 x 420 x 44.45 438 x 300 x 44.45

Weight, kg 3.6 6.8 4.2

65-100-300002B 10/09

For more product information, visit us on the web at www.ZyXEL.com

ZyXEL Communications Corp. All other brands, product names, or trademarks mentioned are the property of their

respective owners. All specifications are subject to change without notice.

Features

User Security and Authentication

• MAC filtering per port secures access to each port

• Static MAC forwarding per port: only specified

• MAC addresses can access the network (port

security)

• Limited MAC number per port

• IP filtering

• TCP/UDP socket filtering

• 802.1x port-based authentication, compensated

assignment over VLAN and bandwidth for valid

access

• RADIUS MAC Authentication

• Loop guard prevents a switch from being

affected by another switch which is already in a

looping status

• IP source guard (static IP/MAC binding, DHCP

snooping, ARP inspection)

• IEEE 802.1Q tag-based and port-based VLAN

• GVRP, automatic VLAN member registration

• 1K static VLAN,up to 4K dynamic VLAN

• Full range 4K PVID support

• Port-based VLAN, IP subnet VLAN

• MAC freeze

• Port security, port isolation, port mirroring,

intrusion lock

• Clone feature copies port settings from one port

to other port(s) in one step

• VLAN stacking

Network Administration Security

• User name/password required for web/telnet/

local console administrators

• Two level security by specific SNMP read/write

community

• Multiple log-in session

• Multiple access authorization management

• SSH v1/v2

• SSL/TLS

• RADIUS MAC login

• RADIUS accounting

• TACACS+ authentication, accounting

• NTP, daylight saving

Network Management

• Supports ZyXEL iStacking™, up to 24 switches

can be managed by one IP address

• Intuitive web-based management with all

features configurable

• Text-based configuration file for scripting

• Telnet CLI (Cisco like)

• SNMP v1, v2c, v3

• SNMP trap group

• Out-of-Band management: RS-232c local console

& RJ-45 console

• DHCP relay, DHCP relay per VLAN, DHCP relay

option 82, DHCP client

• 802.3ah Ethernet OAM (Operations,

Administration and Management)

• RMON four RMON groups 1, 2, 3, 9 (history,

statistics, alarms, and events) for enhanced traffic

management, monitoring, and analysis

• Port mirroring: supports source/destination/both

port mirroring

Intelligent ACL

(L2/L3/L4 Access List Control)

• Based on MAC address

• Based on VLAN

• Based on IP address

• Based on protocol type

• Based on TCP/UDP type

• Based on DSCP

MIB Information

• RFC1213 MIB II

• RFC1493 Bridge MIB

• RFC1643 Ethernet MIB

• RFC1757 RMON Group 1, 2, 3, 9

• RFC2011 IP MIB

• RFC2012 TCP MIB

• RFC2013 UDP MIB

• RFC2233 ifVHC Packet Group

• RFC2674 VLAN MIB

• RFC2925 PING-MIB and TRACEROUTE-MIB

• ZyXEL Private MIB

Certification

• UL 60950-1

• CSA 60950-1

• EN 60950-1

• IEC 60950-1

• EU RoHS compliant

Accessories

SFP Transceivers (Optional)

Speed Model Type Description

SFP-1000T RJ-45 connector Up to 100 m using standard Ethernet cable

SFP-SX-D LC connector SFP SX 550 m commercial type transceiver, DDMI version*1

SFP-LX-10-D LC connector SFP LX 10 km commercial type transceiver, DDMI version*1

abit SFP-BX1310-10-D LC connector Bidirectional singlemode, up to 10 km reach, DDMI version*1, *2

SFP-BX1490-10-D LC connector Bidirectional singlemode, up to 10 km reach, DDMI version*1, *2

SFP-LHX1310-40-D LC connector SFP LHX 1310 wavelength 40 km commercial type transceiver, DDMI version*1

SFP-ZX-80-D LC connector SFP ZX 80 km commercial type transceiver, DDMI version*1

*1: Switch 3000 series don't support DDMI (Digital Diagnostics Monitoring Interface) feature.

*2: Bi-directional SFP must be used in pairs (Example: 1 x SFP-BX1310-10-D and 1 x SFP-BX1490-10-D connected together is a solution)

Enterprise LAN

Switches

Switch 3000 Series

Enterprise LAN

Switches

Switch 3000 Series

Autres manuels pour Dimension ES-3124

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels ZyXEL Communications Changer

ZyXEL Communications

ZyXEL Communications Dimension ES-4124 Mode d’emploi

ZyXEL Communications

ZyXEL Communications GS1910 Manuel utilisateur

ZyXEL Communications

ZyXEL Communications ES-2048 Manuel utilisateur

ZyXEL Communications

ZyXEL Communications GS-1116A Manuel

ZyXEL Communications

ZyXEL Communications GS1920v2 Series Manuel utilisateur

ZyXEL Communications

ZyXEL Communications GS-4012F Manuel utilisateur

ZyXEL Communications

ZyXEL Communications ZyXEL Dimension ES-2724 Manuel utilisateur

ZyXEL Communications

ZyXEL Communications ZyXEL Dimension ES-2108-F Manuel utilisateur

ZyXEL Communications

ZyXEL Communications MES-3528 - Manuel utilisateur

ZyXEL Communications

ZyXEL Communications GS1100-8HP Manuel utilisateur

ZyXEL Communications

ZyXEL Communications GS2210-8 Manuel utilisateur

ZyXEL Communications

ZyXEL Communications GS1915 Series Manuel utilisateur

ZyXEL Communications

ZyXEL Communications IES-1000 - ANNEXE 7 Manuel utilisateur

ZyXEL Communications

ZyXEL Communications GS1920v2 Series Manuel utilisateur

ZyXEL Communications

ZyXEL Communications GS1500-24P Manuel utilisateur

ZyXEL Communications

ZyXEL Communications GS1920-24 Manuel utilisateur

ZyXEL Communications

ZyXEL Communications ES1100 Series Manuel utilisateur

ZyXEL Communications

ZyXEL Communications GS2200-24 Series Manuel utilisateur

ZyXEL Communications

ZyXEL Communications Dimension GS-3012 Manuel utilisateur

ZyXEL Communications

ZyXEL Communications AES-100 Manuel utilisateur

ZyXEL Communications

ZyXEL Communications Dimension GS-3012 Manuel utilisateur

ZyXEL Communications

ZyXEL Communications XGS3600 Series Manuel utilisateur

ZyXEL Communications

ZyXEL Communications GS1510 - Manuel utilisateur

ZyXEL Communications

ZyXEL Communications GS-105A Manuel utilisateur

Manuels Changer populaires d'autres marques

URC

URC Total Control MFS-8 Manuel utilisateur

Azbil

Azbil HPQ-D11 Manuel utilisateur

Sony

Sony DFS-900M Manuel utilisateur

SICK

SICK i17S Manuel utilisateur

F&F

F&F SZR-277 Manuel utilisateur

Shure

Shure UAMS/BK Manuel utilisateur

Dräger

Dräger X-zone Switch Off Manuel utilisateur

Asco

Asco Joucomatic 349 Series Manuel utilisateur

BT Mini Hub Manuel utilisateur

D-Link

D-Link DES-1226G Manuel utilisateur

Johnson Controls

Johnson Controls FS80-C Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuel utilisateur

MicroNet

MicroNet SP1200A Manuel utilisateur

Ruijie

Ruijie RG-PF2920 Series Manuel d'installation et d'exploitation

Altinex

Altinex DA1914SX Manuel utilisateur

MiLAN

MiLAN MIL-SM2401M Manuel utilisateur

RJM

RJM MASTERMIND PBC/6X Manuel utilisateur

Atlas

Atlas MMK-KVM8 Manuel utilisateur
