Integrating NAS (network-attached storage) and IP-based SAN (storage area network)

functionality into a unied solution, ZyXEL’s new UNS2700 and UNS2300 Unied Network Storage

are tailor-made for a wide variety of business storage applications including private cloud, server

virtualization, data backup and disaster recovery. The ZyXEL UNS2700 and UNS2300 are 2U, 12-

bay Unied Network Storage with 10-Gigabit connectivity (UNS2700) and support for 4 TB hard

drives. They are designed with enterprise-class features like the ZFS le system, thin provisioning,

data deduplication and SSD caching to deliver rock-solid data integrity, ultra-fast RAID building

times and best-of-class storage eciency. They also provide multiple backup options with

local and remote data replication, and cloud backup with Amazon S3. Designed with the most

advanced hardware and software features within their class, the UNS2700 and UNS2300 Unied

Network Storage are the most ideal storage solution for small- and medium-sized businesses.

Benets

Rock-solid data integrity

Businesses that have ever lost important les or experienced data corruption know that their storage

solutions’ le systems need improvement. Featuring the industry’s most resilient ZFS le system,

the ZyXEL UNS2700 and UNS2300 Unied Network Storage oer much better data integrity than

competitors in the same class. These ZyXEL Unied Network Storage are designed with a focus on

data integrity. Their ZFS le system can detect silent data corruption (errors that go unnoticed in other

les systems) and repair corrupt data on the y with its self-healing architecture. Combining proven

technologies, such as copy-on-write transactional model and 256-bit checksums, the ZyXEL UNS2700

and UNS2300 deliver end-to-end data integrity at all times and protect businesses against costly data

loss.

Ultra-fast RAID building times

The long hours in building new RAID arrays or adding new storage to servers can be very stressful,

especially in business environments where demand for storage is large. As the competitive business

landscape pushes forward the need for faster application deployments and the capacity of hard drives

continue to grow, businesses need a solution that provides faster storage deployment times to stay

competitive and to lower deployment overhead.

• NAS and iSCSI (IP SAN) unied

solution

• Features the industry’s most

resilient ZFS le system

• Silent data corruption detection

and self-healing ensure data

integrity

• Ultra-fast RAID building times

• Thin provisioning, data

deduplication and compression,

and SSD caching

• Local and remote replication, cloud

(Amazon S3) backup

• Free Acronis Backup & Recovery

Server OEM

• Supports RAID 0, 1, 5, 6, 10, 50, 60

• Comes with McAfee VirusScan

Enterprise for Storage (free 3-year

license)

Best-in-class Storage Efciency, Performance

and Data Integrity

UNS2300/UNS2700

Unied Network Storage

UNS2300/UNS2700

Unied Network Storage

The ZyXEL UNS2700 and UNS2300 Unied Network Storage utilize advanced ZFS technology to deliver ultra-fast RAID building times that put competitors

to shame. Compared to other solutions that use legacy le systems, the UNS2700 and UNS2300 oer signicant performance improvements in building

new RAID arrays, recovering from outages, and replacing hard drives. For example, it takes merely 1 minute for a UNS2300 to build a RAID 5 array with six

(6) 1 TB hard drives, while a competitor running on a legacy le system will take over 3 hours to complete the same task. With the ZyXEL UNS2700 and

UNS2300, users can literally have the storage up and running in less than 10 minutes.

RAID Initialization Comparison

Model File System Hard Drives Level Volume Size Build Time

ZyXEL UNS2300 ZFS 6 x 1 TB RAID 5 5 TB 1 min

Other brand EXT3 6 x 1 TB RAID 5 5 TB 3 hrs 3 mins 12 secs

Extraordinary storage eciency

The ZyXEL UNS2700 and UNS2300 Unied Network Storage provide enterprise-class features like thin provisioning, data deduplication and compression,

and SSD caching to optimize disk utilization and storage eciency.

• Thin provisioning allocates storage capacity dynamically, which maximizes the utilization of available storage and minimizes wasted storage space. The

result is much improved disk utilization and more exible resource management.

• Data deduplication and compression allow businesses to get the most out of their available storage space. It reduces data volume and eliminates

duplicate copies of repeating data. This function allows the ZyXEL UNS2700 and UNS2300 to save up to 90% storage space*1.

• SSD caching can vastly improve deduplication and synchronous write speeds to provide faster data backup, database and NFS applications. Each

storage pool supports up to 4 SSDs for read cache and 2 SSDs for write cache. Test results show that SSD caching boosts data backup throughput with

deduplication enabled by up to 210% and synchronous write IOPS (input/output operations per second) by up to 310%.

Complete backup solution

The ZyXEL UNS2700 and UNS2300 Unied Network Storage oer a complete backup solution to fulll every backup demand of small- to medium-sized

businesses. They provide multiple backup options including local le and volume cloning, remote le and volume replication, as well as cloud backup

and disaster recovery with Amazon S3. To form a complete backup solution, these ZyXEL Unied Network Storage support Apple Time Machine, a total of

4,096 snapshots, and comes with Acronis Backup & Recovery Server OEM.

Advanced data protection

In addition to the more commonly supported RAID levels 0, 1, 5, 6 and 10, the ZyXEL UNS2700 and UNS2300 Unied Network Storage oer more

advanced data protection options than competitors with support for RAID 50 and RAID 60. RAID 50 is a RAID 0 array striped across the distributed parity

of RAID 5, and RAID 60 combines RAID 0 with the distributed double parity of RAID 6. With support for RAID 50 and RAID 60, the ZyXEL UNS2700 and

UNS2300 oer both better performance and better protection against drive failures than competitors within their class.

Additionally, the ZyXEL UNS2700 and UNS2300 come with McAfee’s award-winning VirusScan Enterprise for Storage to provide continuous protection for

storage data and to prevent malicious les from spreading in the system. Together with advanced data integrity features and multiple backup options, the

ZyXEL UNS2700 and UNS2300 are the most advanced data protection solution for businesses.

*1: Compression ratios dier according to data type. Data archives can have redundancy rates of up to 90%.

240 GB

Data Backup Throughput

with Deduplication Enabled

100%50% 150% 250%

200%

Data backup throughput tested by copying 240 GB of data

with deduplication turned on.

8 KB

Random

Synchronous Write Input/

Output Operations per Second (IOPS)

100%50% 150% 250% 300% 350%

200%

512 KB

Sequential

512 KB sequential write and 8 KB random write IOPS tested.

No SSD caching

SSD caching with 2 SSDs

No SSD caching

SSD caching with 1 SSD

UNS2300/UNS2700

Unied Network Storage

Key Applications

SMB NAS deployment

SMB iSCSI (IP SAN) deployment

Remote User

GS2200-24

24-port GbE L2 Switch

USG 300

Unified Security

Gateway

XGS3700 Series

24/48-port GbE L2+

Switch with 10GbE Uplink UNS2300

Unied Network Storage

Internet

PWR1

PWR2

SYS

ALM

MAST

GS3700-48

10/100/1000Base-T Port (1-48)

123456789

10 12

17 18

29 30

1G SFP Port (49-52)

50 52

MGMT

CONSOLE

STACK ID

Server Farm

R&D Dept.

NFS and FTP Services

AD/LDAP

Server

Anti-virus

protection

Sales Dept.

CIFS and AFP Services

Gigabit

Traditional Servers

USG 300

Unified Security

Gateway

XGS3700 Series

24/48-port GbE L2+ Switch

with 10GbE Uplink

UNS2700

Unied Network Storage

iSCSI LUN

App App

Virtualization Servers

Internet

AppApp App App

Guest OS Guest OS

Virtualization OS

AppApp App App

Guest OS Guest OS

Virtualization OS

PWR1

PWR2

SYS

ALM

MAST

GS3700-48

10/100/1000Base-T Port (1-48)

123456789

10 12

17 18

29 30

1G SFP Port (49-52)

50 52

MGMT

CONSOLE

STACK ID

10GbE Fiber

Gigabit

iSCSI

UNS2300/UNS2700

Unied Network Storage

Backup solution

Specications

Model UNS2700 UNS2300

Hardware

Form factor 2U, 12-bay rackmount 2U, 12-bay rackmount

CPU Quad-core Intel® Xeon® Processor E3-1225 v2

(3.2 GHz)

Dual-core Intel® Processor i3-3220

(3.3 GHz)

RAM (GB) 16 (DDR3, ECC) 8 (DDR3)

Internal drives 12 x 3.5” HDD or 2.5” HDD/SSD 12 x 3.5” HDD or 2.5” HDD/SSD

Max. capacity (TB) 48 48

Host interface 2 x 10GbE and 2 x 1GbE 6 x 1GbE

Backend SATA III SATA III

USB port 4 x USB 2.0 4 x USB 2.0

COM port 1 1

Power

Input 100 - 240 V AC, 50/60 Hz 100 - 240 V AC, 50/60 Hz

Max. power consumption (watt) 214 210

Power rating (watt) 549 549

Redundant power supply Yes Yes

80 Plus certified Platinum Platinum

Physical Specifications

Item Dimensions (WxDxH)(mm/in.) 442 x 711 x 88/17.4 x 28 x 3.46 442 x 711 x 88/17.4 x 28 x 3.46

Weight (kg/lb.) 15.8/34.83 15.8/34.83

Packing Dimensions (WxDxH)(mm/in.) 590 x 910 x 230/23.23 x 35.83 x 9.06 590 x 910 x 230/23.23 x 35.83 x 9.06

Weight (kg/lb.) 24/52.91 24/52.91

Environmental Specifications

Operating Temperature 0°C to 40°C/32°F to 104°F 0°C to 40°C/32°F to 104°F

Humidity 10% to 90% (non-condensing) 10% to 90% (non-condensing)

Storage Temperature -30°C to 70°C/-22°F to 158°F -30°C to 70°C/-22°F to 158°F

Humidity 10% to 90% (non-condensing) 10% to 90% (non-condensing)

MTBF (hr) 120,000*2 120,000*2

Heat dissipation (BTU/hr) 730.198 716.55

Certifications

EMC FCC Part 15 (Class A); CE EN 55022: 2010/AC: 2011, EN 55024: 2010;

C-Tick AS/NZS CISPR 22: 2009/A1: 2010 (Class A); BSMI CNS 13438

Safety LVD: EN 60950-1: 2006 + A11: 2009 + A1: 2010 + A12: 2011; BSMI: CNS 14336-1: 2010

Other

Warranty 3 years 3 years

USG 300

Unified Security

Gateway

XGS3700 Series

24/48-port GbE

L2+ Switch with

10GbE Uplink

UNS2700

Unied Network Storage

10GbE Fiber

Gigabit

Remote replication

with deduplication

and compression

Local cloning

and snapshot

backup

UNS2300

Unied Network Storage

Servers

Internet

Amazon S3

PWR1

PWR2

SYS

ALM

MAST

GS3700-48

10/100/1000Base-T Port (1-48)

123456789

10 12

17 18

29 30

1G SFP Port (49-52)

50 52

MGMT

CONSOLE

STACK ID

Encrypted

storage

RAID pool

iSCSI Volume

NAS File System

iSCSI Volume

NAS File System

iSCSI Volume

NAS File System

Apple Time

Machine

*2: Excluding hard drives

UNS2300/UNS2700

Unied Network Storage

Features

Operating System

• Embedded Linux

Supported Clients

• Microsoft Windows XP, Vista, 7, 8

• Windows Server 2003, 2003 R2

• Windows Server 2008, 2008 R2, 2012

• Red Hat Linux 5, 6

• Mac OS X

• Solaris 10, 11

Supported Browsers

• Microsoft Internet Explorer 8, 9

• Mozilla Firefox 8, 9, 10

• Apple Safari 4, 5

• Google Chrome

File System

• Internal hard drive: ZFS

• External hard drive: EXT3, EXT4, NTFS, FAT32

Networking

• TCP/IP (IPv4 & IPv6: dual stack)

• Multiple Gigabit NICs with jumbo frame:

■

Multi-IP settings

■

Port trunking/NIC teaming (modes: balance-

rr, IEEE 802.3ad link aggregation and

balance-alb)

• Virtual LAN (VLAN)

• DHCP client

• Protocols: CIFS/Samba (3.6.4), AFP (v3.3), NFS

(v3, v4), FTP, HTTP(S), SSH, iSCSI, SNMP, SMTP

Backup

• Local clone:

■

Manual & scheduled backup

■

Local cloning (volume to volume)

■

Local cloning (le system to le system)

• Remote replication:

■

Manual & scheduled backup

■

Remote UNS (volume to volume)

■

Remote UNS (le system to le system)

• Server backup via Acronis Backup & Recovery

Server OEM for Windows

• Apple Time Machine support with backup

management

• Cloud data backup and disaster recovery with

Amazon S3

• Total of 4,096 snapshots supported

Security

• IP ltering and policy-based automatic IP

blocking

• CIFS host access control for shared folders

• McAfee anti-virus protection

• Storage pool-based encryption

• Instant alert via email, instant messaging

(Windows Messenger), and buzzer

Disk Management

• Single disk, RAID 0, 1, 5, 5 + hot spare, 6, 6 +

hot spare, 10, 10 + hot spare, 50 + hot spare,

60 + hot spare

• Online pool capacity expansion

• Bad block scan & hard drive S.M.A.R.T.

• Pool scrubbing

• Dedicated hot spare drive

• RAID recovery

iSCSI (IP SAN)

• iSCSI target:

■

Multi-LUNs per target

■

Up to 256 targets/LUNs combined

■

Online LUN capacity expansion

■

Supports SPC-3 persistent reservation

■

Supports MPIO & MC/S

• iSCSI LUN backup, one-time snapshot, and

restore

Server Virtualization & Clustering

• Supports VMware vSphere

• Supports Citrix XenServer

• Supports Windows Server 2012 Hyper-V &

failover clustering

Power Management

• Wake on LAN

• Internal hard drive standby mode

• Automatic power on after power recovery

• Console and network UPS support with SNMP

management

Access Right Management

• Max. no. of local accounts: 10,000

• Max. no. of local groups: 512

• Batch user creation

• Import/Export users

• User quota management

• Subfolder permissions support for CIFS/

Samba, AFP, FTP and Web le manager

Domain Authentication Integration

• Microsoft Active Directory (AD)

• LDAP server

• Domain user login via CIFS/Samba, AFP, FTP

Storage Plug & Play

• ZyXEL UNS Finder for Windows

Web Administration

• Web-based user interface

• Smart fan control

• SNMP (v2 & v3)

• Resource monitor

• System logs (events & connections)

• Syslog client

• Firmware update

• Restore to factory default

File Server

• File sharing across Windows, Mac, and Linux/

UNIX

• Shared folder aggregation (CIFS/Samba)

FTP Server

• FTP over SSL/TLS (explicit)

• Max. no. of concurrent connections: 256

• Passive FTP port range control

• FTP bandwidth, client & connection control

• Unicode support

Anti-Virus

• Powered by McAfee

• Virus database update on manual, online, or

scheduled basis

• Excluded le type and shared le system

support

• Multiple scan tasks with custom folder

selection and scheduled scanning

• Anti-virus report for virus detection

• Clear infected les

Data Eciency

• Thin provisioning

• Deduplication

• SSD caching:

■

Supported read cache up to 4 SSD drives

■

Supported write cache up to 2 SSD drives

with RAID protection (RAID 0, RAID 1)

• Compression:

■

Real-time compression

■

Compresses data up to 80 percent

■

Works in both iSCSI and NAS environments

UNS2300/UNS2700

Unied Network Storage

For more product information, visit us on the web at www.ZyXEL.com

of ZyXEL Communications Corp. All other brands, product names, or trademarks mentioned are the property of

their respective owners. All specications are subject to change without notice.

5-100-00613001 07/13

Accessories

Disk Pack

Item Capacity/Amount Speed Type

HDD206 2 TB x 6 7200 RPM Enterprise-grade 3.5” SATA III

drive pack

Autres manuels pour UNS2300

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels ZyXEL Communications Matériel réseau

ZyXEL Communications

ZyXEL Communications IES-1248 Manuel utilisateur

ZyXEL Communications

ZyXEL Communications FMG3010-R20A Manuel utilisateur

ZyXEL Communications

ZyXEL Communications PoE-10 Manuel utilisateur

ZyXEL Communications

ZyXEL Communications NSA-2400 Manuel utilisateur

ZyXEL Communications

ZyXEL Communications UNS2300 Manuel

ZyXEL Communications

ZyXEL Communications GS3700 Series Manuel utilisateur

ZyXEL Communications

ZyXEL Communications PLA450 Series Manuel utilisateur

ZyXEL Communications

ZyXEL Communications NXC Series Mode d’emploi

ZyXEL Communications

ZyXEL Communications NSA-210 Manuel

ZyXEL Communications

ZyXEL Communications POE-12 Guide de référence

ZyXEL Communications

ZyXEL Communications POE-12 Guide de référence

ZyXEL Communications

ZyXEL Communications ZYWALL OTPV2 - Manuel utilisateur

ZyXEL Communications

ZyXEL Communications Network Storage Appliance NSA-220 Manuel utilisateur

ZyXEL Communications

ZyXEL Communications ZyWall Manuel utilisateur

ZyXEL Communications

ZyXEL Communications USG FLEX 500 Manuel utilisateur

ZyXEL Communications

ZyXEL Communications EOC350 Series Manuel utilisateur

ZyXEL Communications

ZyXEL Communications ZyWALL SSL 10 Manuel utilisateur

ZyXEL Communications

ZyXEL Communications VPN Series Manuel utilisateur

ZyXEL Communications

ZyXEL Communications ATP Series Manuel utilisateur

ZyXEL Communications

ZyXEL Communications ZYAIR EXT-109 Manuel utilisateur

ZyXEL Communications

ZyXEL Communications Prestige 2602HW Series Manuel utilisateur

ZyXEL Communications

ZyXEL Communications GS1900 Series Manuel utilisateur

ZyXEL Communications

ZyXEL Communications ZyAIR B-320 Manuel utilisateur

ZyXEL Communications

ZyXEL Communications P-2802HWL-I - V3.70 Manuel utilisateur

Manuels Matériel réseau populaires d'autres marques

Matrix Switch Corporation

Matrix Switch Corporation MSC-HD161DEL Manuel utilisateur

B&B Electronics

B&B Electronics ZXT9-IO-222R2 Manuel utilisateur

Yudor

Yudor YDS-16 Manuel utilisateur

D-Link

D-Link ShareCenter DNS-320L Manuel utilisateur

Samsung

Samsung ES1642dc Instructions d'utilisation

Honeywell Home

Honeywell Home LTEM-PV Instructions de montage

evertz

evertz 7700 Series Manuel utilisateur

D-Link

D-Link ShareCenter DNS-343 Manuel utilisateur

Asante

Asante AsanteBridge 1012 Manuel utilisateur

FireBrick

FireBrick FB2700 Manuel utilisateur

Audiovox Electronics

Audiovox Electronics ARWH2T Manuel utilisateur

ADC

ADC DSX-1 Manuel

NetComm

NetComm NF2 Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 5620 Manuel utilisateur

Dell EMC

Dell EMC XC6420 Series Manuel utilisateur

Lanner

Lanner NCA-1020A Manuel utilisateur

Allied Telesis

Allied Telesis AT-TN121-A Manuel utilisateur

Arista

Arista CCA-ETM-Q12 Manuel utilisateur
