Zte SD6200 Instructions originales
1
SD6200
WebUI User Manual and Safety
Information
1
About This Manual
Thank you for choosing this mobile device. To keep your device in its best condition, please read
this manual and keep it for future reference.
Notice
This manual has been designed with the utmost care to ensure the accuracy of its content.
However, all statements, information and recommendations contained therein do not constitute a
warranty of any kind, either expressed or implied. Please refer to For Your Safety to be sure to
use your phone properly and safely.
Disclaimer
Images and screenshots used in this manual may differ from the actual product. Content in this
manual may differ from the actual product or software.
Trademarks
Other trademarks and trade names are the property of their respective owners.
Version No.: R1.0
Edition Time: June 22 2018
2
Getting Started............................................................5
Know Your OBD2 (On-Board Diagnostic) Device............... 5
Status LED Indicator .......................................................... 6
Reset the OBD2 Device..................................................... 7
Restart the OBD2 Device................................................... 7
Installing the micro-SIM Card............................................. 8
Installing your OB2 Device ......................................10
Manage Your OBD2 Device and Settings ...............12
Connect Devices to Your OBD2 Device’s Wi-Fi ............... 12
Connect a wireless device manually ................................ 12
Use Your OBD2 Device.............................................13
4G Mobile Hotspot Configuration Page............................ 13
Security Credentials.................................................14
3
Manage Wi-Fi.............................................................14
View Connected Devices .................................................14
Set Maximum Number of Connected Devices..................15
Add / removed Devices ....................................................17
Security......................................................................18
Change Wi-Fi Network Name and Password. ..................18
Change 4G Mobile Hotspot Configuration Page Access
Settings ............................................................................19
Change Wi-Fi Security Types...........................................20
Configure Data Network Options......................................21
Advanced Settings....................................................23
Manage Wi-Fi...................................................................23
Change Advanced Settings......................................24
View WAN Information .....................................................24
Enable Port Mapping........................................................24
Enable MAC/ IP/Port Filtering ..........................................24
Configure APN details ......................................................25
4
Troubleshooting .......................................................27
Compatible vehicles.................................................28
Working Voltage........................................................28
Specifications ...........................................................29
Regulatory and Safety Information.........................30
Warranty ....................................................................33
5
Getting Started
Know Your OBD2 (On-Board Diagnostic) Device
Your OBD2 device enables you to create a Wi-Fi network in your vehicle. You can use that Wi-Fi
network to connect your smartphone and other Wi-Fi capable devices to your network provider’s
mobile broadband network and connect to the Internet.
Device reset hole
micro-SIM card slot
Restart key
LED 1
LED 2
OBD2
Interface
6
Status LED Indicator
LED INDICATOR LED STATUS
7
Reset the OBD2 Device
You can reset the OBD2 device to the factory setting on the OBD2 device or the 4G Mobile
Hotspot configuration page. (This is useful if you have lost your Admin Login for the 4G Mobile
Hotspot configuration page.)
NOTE:
If you reset the modem to factory settings, all your customizations will be lost. If you want to
keep them, save them before doing the reset, and then restore them afterward. Note: When you
reset the OBD2 device, any currently connected devices will lose access and will have to be
reconnected after the OBD2 device restarts.
On the OBD2 device:
Insert a pin into Reset hole and hold for about 3 seconds until the LED1 indicator turns red.
After the device has reset, reconnect Wi-Fi devices.
On the 4G Mobile Hotspot configuration page:
•Log in as Administrator.
•Select Settings > Device Settings.
•Select Reset.
Restart the OBD2 Device
You can restart the OBD2 device by pressing the restart key.
8
Installing the micro-SIM Card.
1. Insert the tip of the tray eject tool to eject the SIM card tray.
2. Place the micro-SIM card on the tray with the gold-colored contacts facing down and slide
the tray back into place.
