ZTE MF608

Wireless Access Terminal

User Manual

WELCOME

Thank you for choosing the ZTE MF608 Wireless Access

Terminal (modem). Please read this manual carefully to ensure

your modem is always working in its best condition.

The pictures, symbols and contents in this manual are just

for your reference and might not be completely identical with

your modem.

iii

Glossary

AC: Alternating Current

APN: Access Point Name

BATT: Rechargeable battery

CID: Caller Identification

DC: Direct Current

DNS: Domain Name System (or Service or Server)

EDGE: Enhanced Data GSM Evolution

Ethernet: A frame-based computer networking technology

for local area networks (LANs).

GSM: Global System for Mobile Communications

GPRS: General Packet Radio Service

HSDPA: High Speed Downlink Packet Access

IP: Internet Protocol

LAN: Local Area Network

LED: Light Emitting Diode

MHz: Megahertz.

PDP: Packet Data Protocol

RSSI: Radio Signal Strength Indicator

SIM: Subscriber Identification Module

WCDMA: Wideband CDMA (Code-Division Multiple

Access).

Contents

1 General Information....................................................... 1

1.1 Best Practice .............................................................. 1

1.2 Cleaning and Maintaining the Modem ...................... 2

1.3 Limited Warranty....................................................... 3

1.4 Limitation of Liability ............................................... 4

2 Getting started................................................................. 5

2.1 Parts Supplied............................................................ 5

2.2 Modem Appearance................................................... 7

2.2.1 LED indicator .................................................... 7

2.2.2 Switch ................................................................ 9

2.3 Interface and installation ........................................... 9

2.3.1 Interface description........................................... 9

2.3.2 Installation ....................................................... 10

2.4 Power Supply .......................................................... 18

2.5 About SIM card ....................................................... 19

3 Voice Calls ..................................................................... 21

3.1 Making a call........................................................... 21

3.2 Answering the Call .................................................. 22

4 Internet Accesses........................................................... 23

4.1 Connecting to the Internet ....................................... 23

4.2 Default Settings ....................................................... 24

4.2.1 System Info...................................................... 25

4.2.2 Network Connect ............................................. 25

4.2.3 Network Select................................................. 26

4.2.4 APN Configure ................................................ 27

4.2.5 Help.................................................................. 29

4.3 Disconnecting from the Internet.............................. 29

5 Troubleshooting ............................................................ 30

6 Appendix........................................................................ 36

6.1 Modem Technical parameters.................................. 36

1 General Information

1.1 Best Practice

Please use the modem far away from TV sets, radio and

other electronic equipment so as to avoid electromagnetic

interference.

The modem is not water-resistant, so do not use it in

places where there is high humidity.

Please use original accessories or accessories that are

authorized by ZTE. Using any unauthorized accessories

may affect your modem’s performance, damage your

modem or even cause danger to your body and violate

related national telecom regulations about modems.

Do not attempt to dismantle the modem by yourself. Non-

expert handling of the device may cause damage.

Do not disassemble or modify the rechargeable battery.

Do not allow the modem, rechargeable battery or

accessories to come into contact with liquids or moisture

at any time. Do not immerse in any liquid.

Do not put any object on the modem to avoid over-

heating.

Do not expose your modem to direct sunlight or store it in

hot areas. High temperatures can shorten the life span of

electronic devices.

Please do not touch the antenna with your hands while

making a call or browsing the Internet. Covering the

antenna may affect the call quality, may cause the handset

to operate at higher power level than needed, and may

shorten the talk time and standby time.

Do not allow children to play with the modem, charger or

rechargeable battery.

It is highly recommended to charge the rechargeable

battery before initial use. The rechargeable battery might

have been discharged during storage and delivery.

Please switch off the modem if you are not using it.

Please remove the rechargeable battery from the modem

if you will not be using the modem for long periods of

time (ex. 10 days or more).

Keep the length of the cable between the modem and

phone less than 10 meters apart.

1.2 Cleaning and Maintaining the Modem

Use an anti-static cloth to clean the modem. Do not use

chemical or abrasive cleaners as these could damage the

plastic case. Turn off your modem before you clean it.

Use the modem within the temperature range of

-10°C~55°C and the humidity range of 25%~85%.

Do not use your modem during a thunderstorm.

Do not take out your SIM card if there is no necessity.

The damaged SIM card may cause problems in

maintaining the modem.

1.3 Limited Warranty

This warranty does not apply to defects or errors in the

Product caused by:

(a) Reasonable Modem Appearance Disfiguration;

(b) End User’s failure to follow ZTE’s installation,

operation or maintenance instructions or procedures;

(c) End User’s mishandling, misuse, negligence, or

improper installation, disassemble, storage, servicing or

operation of the Product;

(d) Modifications or repairs not made by ZTE or a ZTE-

certified individual;

(e) Power failures, surges, fire, flood, accident, actions of

third parties or other events outside ZTE’s reasonable

control.

(f) Usage of products of third Parties, or usage in

conjunction with third party products provided that such

defects is due to the combined usage;

(g) Any other cause beyond the range of normal usage for

Products. End User shall have no right to reject, return, or

receive a refund for any Product from ZTE under the

above-mentioned situations.

This warranty is end user’s sole remedy and ZTE’s sole

liability for defective or nonconforming items, and is in

lieu of all other warranties, expressed, implied or statutory,

including but not limited to the implied warranties of

merchantability and fitness for a particular purpose,

unless otherwise required under the mandatory provisions

of the law.

1.4 Limitation of Liability

ZTE shall not be liable for any loss of profits or indirect,

special, incidental or consequential damages resulting from or

arising out of or in connection with using of this product,

whether or not ZTE had been advised, knew or should have

known of the possibility of such damages, including, but not

limited to lost profits, interruption of business, cost of capital,

cost of substitute facilities or product, or any downtime costs.

2 Getting started

The modem can work under WCDMA/HSDPA network

and GSM/GPRS/EDGE network, and supports both voice and

data service.

2.1 Parts Supplied

Modem （1）

External power adapter (1)

Antenna (1) * Ethernet cable

(Cross- RJ45) (1)

Phone cable (RJ11) (1)
