Zte ZXA10 C320 Mode d’emploi

ZXA10C320

OpticalAccessConvergenceEquipment

HardwareDescription

Version:V2.0.0

ZTECORPORATION

No.55,Hi-techRoadSouth,ShenZhen,P .R.China

Postcode:518057

Tel:+86-755-26771900

Fax:+86-755-26770801

URL:http://support.zte.com.cn

E-mail:[email protected]

LEGALINFORMATION

Thecontentsofthisdocumentareprotectedbycopyrightlawsandinternationaltreaties.Anyreproductionor

distributionofthisdocumentoranyportionofthisdocument,inanyformbyanymeans,withoutthepriorwritten

consentofZTECORPORATIONisprohibited.Additionally,thecontentsofthisdocumentareprotectedby

contractualcondentialityobligations.

Allcompany,brandandproductnamesaretradeorservicemarks,orregisteredtradeorservicemarks,ofZTE

CORPORATIONoroftheirrespectiveowners.

Thisdocumentisprovided“asis”,andallexpress,implied,orstatutorywarranties,representationsorconditions

aredisclaimed,includingwithoutlimitationanyimpliedwarrantyofmerchantability,tnessforaparticularpurpose,

titleornon-infringement.ZTECORPORATIONanditslicensorsshallnotbeliablefordamagesresultingfromthe

useoforrelianceontheinformationcontainedherein.

ZTECORPORATIONoritslicensorsmayhavecurrentorpendingintellectualpropertyrightsorapplications

coveringthesubjectmatterofthisdocument.ExceptasexpresslyprovidedinanywrittenlicensebetweenZTE

CORPORATIONanditslicensee,theuserofthisdocumentshallnotacquireanylicensetothesubjectmatter

herein.

ZTECORPORATIONreservestherighttoupgradeormaketechnicalchangetothisproductwithoutfurthernotice.

UsersmayvisitZTEtechnicalsupportwebsitehttp://ensupport.zte.com.cntoinquirerelatedinformation.

TheultimaterighttointerpretthisproductresidesinZTECORPORATION.

RevisionHistory

RevisionNo.RevisionDateRevisionReason

R1.02013-08-31Firstedition

SerialNumber:SJ-20130520170233-004

PublishingDate:2013-08-31(R1.0)

SJ-20130520170233-004|2013-08-31(R1.0)ZTEProprietaryandCondential

Contents

AboutThisManual.........................................................................................I

Chapter1Shelf...........................................................................................1-1

Chapter2Cards..........................................................................................2-1

2.1SMXACard........................................................................................................2-2

2.2GPONInterfaceCards........................................................................................2-5

2.3P2PInterfaceCard.............................................................................................2-8

2.4PowerCard......................................................................................................2-10

2.5Backplane........................................................................................................2-12

2.6FanUnit...........................................................................................................2-13

Chapter3Cables........................................................................................3-1

3.1PowerCable......................................................................................................3-1

3.2NetworkCable...................................................................................................3-2

3.3SerialPortCable................................................................................................3-3

3.4FiberPigtail........................................................................................................3-4

Glossary..........................................................................................................I

SJ-20130520170233-004|2013-08-31(R1.0)ZTEProprietaryandCondential

AboutThisManual

Purpose

TheZXA10C320OpticalAccessConvergenceEquipment(ZXA10C320forshort)isa

2U-heightOLTdevice,whichsatisesthemarketrequirementforsmall-capacityOLT s.

ThismanualdescribesthehardwarestructureoftheZXA10C320.

IntendedAudience

Thismanualisintendedfor:

lPlanningengineer

lInstallationsupervisionengineer

lDebuggingengineer

WhatIsinThisManual

Thismanualcontainsthefollowingchapters:

ChapterSummary

1,ShelfDescribestheshelfstructureandcongurations.

2,CardsDescribesthecards.

3,CablesDescribesthecables.

SJ-20130520170233-004|2013-08-31(R1.0)ZTEProprietaryandCondential

Chapter1

Shelf

Appearance

TheZXA10C320shelfisa19-inchshelfwith2Uinheight.Figure1-1showsthe

appearanceoftheZXA10C320shelf.

Figure1-1ShelfAppearance

Congurations

Figure1-2showsthecongurationsoftheshelf.

Figure1-2ShelfCongurations

Note:

WhentheZXA10C320usesACpowersupply,theACpowercardPRAMisinstalledin

slot3.

TechnicalSpecications

Table1-1liststhetechnicalspecicationsoftheshelf.

1-1

SJ-20130520170233-004|2013-08-31(R1.0)ZTEProprietaryandCondential

ZXA10C320HardwareDescription

Table1-1TechnicalSpecicationsoftheShelf

ItemSpecication

Dimensions86.1mm×482.6mm×270mm(height×width×depth)

Weight2.5kg(empty)

6.9kg(fullconguration)

1-2

SJ-20130520170233-004|2013-08-31(R1.0)ZTEProprietaryandCondential

Chapter2

Cards

TheZXA10C320iscomposedofcardsandafanunit,seeT able2-1.

Table2-1CardList

NameDescriptionFunctionInterface

SMXASwitchingandcontrol

card

Controlsthesystemand

switchesservices.

Providespowersupplytothe

system.

Oneout-of-bandNetwork

Management(NM)interface

Onedebuggingserialport

One10GEopticalinterface

(canbeconguredasoneGE

opticalinterface)

OneGEopticalinterface

OneGEelectricalinterface

Oneenvironmentmonitoring

interface

One-48VDCpowerinterface

GTGH16-portGPON

interfacecard

ProvidesGPONaccess.16GPONinterfaces

GTGO8-portGPONinterface

card

ProvidesGPONaccess.8GPONinterfaces

FTGK48-portP2Pinterface

card

ProvidesP2Paccess.48GE/FEinterfaces

PRAMACpowercardProvidespowersupplytothe

system.

OneACpowerinputinterface

OneDCpoweroutputinterface

Onebatteryinterface

Onetemperaturesensor

interface

MWMTBackplaneProvidestheelectrical

interconnectionofeachcard

inthesystem.

FAN-

C320

FanunitProvidesventilationforthe

system.

TableofContents

SMXACard................................................................................................................2-2

GPONInterfaceCards...............................................................................................2-5

2-1

SJ-20130520170233-004|2013-08-31(R1.0)ZTEProprietaryandCondential

ZXA10C320HardwareDescription

P2PInterfaceCard.....................................................................................................2-8

PowerCard..............................................................................................................2-10

Backplane................................................................................................................2-12

FanUnit...................................................................................................................2-13

2.1SMXACard

Overview

TheswitchingandcontrolcardSMXAistheserviceswitching,management,andcontrol

centeroftheZXA10C320.

Panel

Figure2-1showsthepaneloftheSMXAcard.

Figure2-1TheSMXAPanel

Indicators

Table2-2describestheindicatorsontheSMXAcard.

Table2-2SMXAIndicatorsDescription

IndicatorStatusDescription

LEDisOFF.Thepoweroftheequipmentisnotsuppliedfromthepanel,

butcanbesuppliedfromthebackplane.

GreenLEDisON.Thepowersupplyfromthepanelisproper.

PWR

RedLEDisON.Thepowersupplyfromthepanelisproper.

LEDisOFF.Thecardisnotpoweredon,ortheCentralProcessingUnit

(CPU)isnotstarted.

GreenLEDashes

slowly(0.5Hz).

Thecardrunsproperly.

GreenLEDisON.lThecardpassestheselftest,butfailstoobtaindata

fromtheswitchingandcontrolcardorNMS.

lThecardisrunningthebootingprogram,orisdown-

loadingasoftwareversionfromtheswitchingandcon-

trolcard.

lThecardcannotoperatebecausethereisnolegalsoft-

wareversion.

RUN

2-2

SJ-20130520170233-004|2013-08-31(R1.0)ZTEProprietaryandCondential
