Zte MF970 Manuel utilisateur
49
MF970
Quick Start Guide
50
Getting to Know Your Device
Appearance
Thefollowinggureisforyourreferenceonly.
1. micro-SIM card slot cover and reset hole
2. FUNC key
3. Power key
4. LCD screen
5. Charging/micro-USB jack
6. External antenna connector
51
Getting to Know Your Device
Indicators
When the device is powered on, the following icons
may be displayed on the LCD screen. For a description
of the icons, refer to the following table.
Icon Description
Network signal strength
4G / 3G / 2G Network type
Theuserisinroamingstatus.
Connected to the Internet.
Connected to the Internet in the
Internet Access Point mode.
New message (s)
Wi-Fi status and the number of
connected users
Battery level
52
Getting to Know Your Device
Connection Scenarios
ThedevicecanaccesstheInternetintwowaysand
it allows multiple clients to surf on the Internet at the
sametime.Thefollowingguresareforyourreference
only.
• 4G Mode: A micro-SIM card can be used to access
the Internet.
• Internet Access Point Mode: Your device can be
connected to a WLAN device (such as a hotspot
device or wireless router) through Wi-Fi to access
theInternet.TheWLANdevicemustbealready
connected to the Internet.
53
Getting to Know Your Device
NOTE:
Your device and the WLAN device must be in different
subnets.
54
Installing the micro-SIM Card
1. Open the micro-SIM card slot cover, and install a
micro-SIM card to the micro-SIM card slot.
NOTE:
Do not remove the cover rudely, because it is
connected with the device.
WARNING!
Toavoiddamagetothedevice,donotuseanyother
kind of SIM cards, or any non-standard micro-SIM card
cut from a SIM card. You can get a standard micro-SIM
card from your service provider.
2. Close the micro-SIM card slot cover.
If the SIM card PIN code is activated a page will open
where you can enter the PIN code. If that page doesn´t
open please go to http://elisa.home and log in with
the administrator password (administrator password
is “admin”), thereafter you can enter the SIM card PIN
code.
55
Connecting to Your Device
Using Wi-Fi
1. Power on your device.
2. Ensure that your computer or other client devices
have enabled Wi-Fi, and search for available
wireless networks.
NOTE:
Refer to your Wi-Fi-enabled client device manual
for further details on how to search for wireless
networks. If you use a computer, you need
to set your computer to obtain an IP address
automatically.
3. Select the Wi-Fi name (SSID) of your device, and
click Connect.
4. Enter the Wi-Fi password if necessary, and click
OK.
NOTE:
Refer to the chapter Getting to Know the Wi-Fi
SSID and Password to get the default Wi-Fi SSID
and password.
5. Wait until the client device is connected to your
device successfully.
56
Connecting to Your Device
Using a USB Cable
1. Connect a computer to your device with a USB
cable.
2. Poweronyourdevice.Theoperatingsystem
detectsandidentiesnewhardware,and
automatically installs the hardware.
NOTE:
If the system does not automatically launch installation,
you can Double-click the device installation icon in My
Computer to install the software.
3. Wait until the computer is connected to your device
successfully.
Getting to Know the Wi-Fi SSID and
Password
You can use the following methods to get the default
Wi-Fi SSID and password.
• Viewthelabelonthedevice.
• PresstheFUNC key to access the options menu.
Select Device Info and the Wi-Fi SSID and
password are displayed on the screen.
57
Logging in to the 4G Mobile Hotspot
Conguration Page
1. Ensure that the connection between your device
and the client device is correct.
2. Launch the Internet browser and enter
http://192.168.0.1 or http://elisa.home in the
address bar.
3. Enter the password to log in to the 4G Mobile
Hotspotcongurationpage.
NOTE:
Thedefaultpasswordisadmin.
Changing the Wi-Fi SSID or Password
1. Logintothe4GMobileHotspotconguration
page.
2. Select Settings below Wi-Fi and then click Main
SSID.
3. Change the WiFi Name or the WiFi Password in
the Main SSID area.
4. Click Apply.
58
Accessing the Internet
4G Mode
After a client device is successfully connected to your
device, you can access the Internet in Automatic or
Manualmode.ThedefaultmodeisAutomatic.
Mode Operation
Automatic
Your device is automatically connected
to the Internet, and you can surf on the
Internet through the client.
Manual
1. Log in to the 4G Mobile Hotspot
congurationpage.
2. Select Settings > Connection Mode
> Manual, and then click Apply.
3. Click to back to the home page,
and click or .
You can also press the FUNC Key and
select Network Connection. Select Yes
or No.
NOTE:
Tomodifytheparametersofyourdevice,logintothe
4GMobileHotspotcongurationpage.
