H1essential Firmware Update Guide
Copyright(C) 2024 ZOOM CORPORATION. All Rights Reserved.
Proper display is not possible on grayscale devices.
Introduction
■Item to prepare
■Firmware update process
1. Download the firmware update file.
2. Extract the ZIP file.
3. Copy the extracted firmware update file to a microSD card.
4. Update the firmware.
5. Confirm that the firmware has been updated correctly.
H1essential
Windows or macOS computer
with Internet access
USB Type-C cable
microSD card
Supported recording media
microSDHC: 4 GB – 32 GB
microSDXC: 64 GB – 1 TB
Always format microSD cards on the
H1essential after purchasing them new
or using them with a different device.
2
Updating the Firmware
This guide explains firmware update to version 1.10 as an example.
1. Download the firmware update file.
Download the ZIP file that contains the firmware update file from the H1essential download page.
H1essential Firmware
System Version 1.10
3
On Windows
2. Extract the ZIP file
Select the folder that contains the downloaded ZIP file. Click ①“Compressed Folder Tools” and then click ②
“Extract all”. This extracts the ZIP file.
①
②
H1e_v1.10_E.zip
H1essential_Fir
mware_Update_
Guide_E.pdf
H1essential_Fir
mware_Version_
History_E.pdf
H1essential.BIN
H1essential_v1.10_E
4
3. Copy the firmware update file to a microSD card.
Copy the “H1essential.BIN” file to a microSD card.
Firmware update file
Copy the firmware update file
to a microSD card.
microSD
H1essential_Fir
mware_Update
_Guide_E.pdf
H1essential_Fir
mware_Version
_History_E.pdf
H1essential.BIN
H1essential.BIN
H1essential_v1.10_E ZOOM_H1E (F:)
ZOOM_H1E (F:)
5
On macOS
2. Extract the ZIP file.
After downloading, open the ①“Downloads” folder which appears at the right end of the Dock by default.
Then, click ②. Downloaded files will be shown.
3. Copy the firmware update file to a microSD card.
Copy the “H1essential.BIN” file to a microSD card.
①
②
H1essential.BIN
H1essential_v1.10_E
H1essential_Fir
mware...e_E.pdf
H1essential_Firm
ware...ory_E.pdf
microSD
Firmware update file
Copy the firmware update file
to a microSD card.
ZOOM_
H1essential.BIN
6
The following procedures are the same on both Windows and macOS.
4. Connect the power source (AC adapter, USB bus power or portable battery) to the USB port (Type-C) of H1essential.
NOTE
•When performing a firmware update using batteries, the update may not be possible depending on the remaining
battery charge.
5. Insert the microSD card into the H1essential.
6. Slide toward .
This turns the H1essential power on and opens the Home Screen on the display.
7
7. Press .
This opens the Menu Screen on the display.
8. Use and to select “System” and press to confirm.
9. Use and to select “Firmware” and press to confirm.
10.press to confirm.
11.Use and to select “Execute” and press to execute.
12.Slide toward until “Goodbye! See You!” appears on the display.
The display will become empty, and the power will turn off.
8
13. Slide toward again.
The update will be executed automatically, and the REC indicator will blink slowly.
After about 1 minute, a completion screen will appear.
NOTE
During the firmware update, do not turn the power off or remove the microSD card.
If the update fails, the REC indicator will blink rapidly. If this happens, turn the power off once and confirm that
the microSD card is loaded correctly. Then, turn the power on and try updating again.
14.Turn the power off.
NOTE
If the firmware update failed, starting the unit might not be possible and the REC indicator might stay lit.
Turn the power off and repeat the steps from the beginning.
9
Confirming that the firmware has been updated correctly
Check the firmware versions used by the H1essential.
1. Press .
This opens the Menu Screen on the display.
2. Use and to select “System” and press to confirm.
3. Use and to select “Version” and press to confirm.
4. Check the firmware version.
10
・Copying or reprinting this manual in part or in whole without permission is prohibited.
・Windows® is a trademark or registered trademark of Microsoft® Corporation.
・macOS® is a trademark or registered trademark of Apple Inc.
・microSDXC logos are trademarks of SD-3C LLC.
・Other product names, registered trademarks and company names in this document are the property of their
respective companies.
・All trademarks and registered trademarks in this document are for identification purposes only and are not
intended to infringe on the copyrights of their respective owners.
・The illustrations in these instructions might differ from actual screens.
©2024 ZOOM CORPORATION Z2I-5186-01
● ZOOM CORPORATION will bear no responsibility for any losses or third-party claims
resulting from the use of this software. Moreover, distribution, sale, leasing, rental, alteration,
and reverse engineering without permission of this software are prohibited. The specifications
of this software and the contents of this document could be changed without notice in the future.
