USER MANUAL
AL10B Digital Lock with Voice Guide
Version: 1.3
Date: December 2018
Table of Contents
Read Before Use.........................................................................................................4
Safety Precautions....................................................................................................................4
Structure........................................................................................................................................4
Basic Function ............................................................................................................6
User Introduction.....................................................................................................................6
Initialization..................................................................................................................................7
Random Password...................................................................................................................7
Volume Setting..........................................................................................................................8
Language Setting.....................................................................................................................8
Lockout Mode............................................................................................................................8
Low Battery Warning..............................................................................................................9
9V External Battery ...............................................................................................................10
How To Change Handle Direction..............................................................................11
Emergency Mechanical Key...........................................................................................12
How to Use................................................................................................................13
Register First Administrator.............................................................................................13
Register Other Administrator.........................................................................................14
Register Normal User..........................................................................................................15
Delete Admin...........................................................................................................................16
Delete Normal User .............................................................................................................17
Back Up Enroll..........................................................................................................................18
Volume Setting.......................................................................................................................19
Language Setting..................................................................................................................20
Lockout mode.........................................................................................................................21
Always open mode..............................................................................................................22
Page | 4
Safety Precautions
1. The factory setting of all new locks will allow ANY verifications to open them.
2. One administrator must be registered on newly installed locks. Ordinary users cannot
be registered until an administrator is registered.
3. The lock is equipped with a mechanical key. Store the mechanical key in a safe place.
4. Four alkaline AA batteries (not included) are required to power on the lock,
Non-alkaline and rechargeable batteries ARE NOT RECOMMENDED.
5. Do not remove batteries from the lock in working state.
6. Batteries should be replaced soon when the lock prompts the low battery warning.
7. If the lock does not have any activity for ten seconds it will go into sleep mode.
8. Go to bit.ly/al20bov to watch our operation video.
Read
Before Use
Page | 5
Structure
Front view Rear view Bottom view
9
10
5
6
7
8
1
Card Area
2
Keypad & Card Detection Area
3
Mechanical Key Hole
4
Handle
5Battery Area
6Reset Button
7Louckout Switch
8Battery Cover
99V Battery Interface
10 Speaker
1
2
3
4
Page | 6
User Introduction
Group Verification Mode Function Capacity
Administrator
Card Register / Delete User,
Open The Door,
Access in menu
Max.100
Password Max.100
Normal User
Card
Open the door
Max.100
Password Max.100
Note:
1. The maximum card/password capacity of lock is 100.
2. Password is of six digits.
Basic Function
Page | 7
Initialization
After installing the lock, you must perform initialization process as explained below:
1. Press and hold the reset button, then touch the pad, keep holding the reset button
until you hear "Restore to default settings, wait a moment" voice prompt.
2. After 10 seconds the lock will prompt "Completed".
Random Password
To protect the password, user may enter their password with random digits before or
after, the maximum number of digits entered must be 32 or less.
For example:
If the correct password is 123456, the random password can be 89123456807,
1234562363, 389123456, etc.
Page | 8
Volume Setting
The lock volume can be set, which has three modes, high volume mode, low volume
mode and silent mode.
Language Setting
It supports combination of either "English and Spanish" or "English and Portuguese"
language.
Lockout Mode
Lockout mode means that only administrator can unlock the door.
It can be activated in two different ways:
1. Lockout switch on the indoor unit (picture).
2. Operating the menu on the lock (refer page 18).
Page | 9
Low Battery Warning
"Low battery, Replace the batteries !!" will prompt when the battery has low power.
Note: Menu options can't be accessed in low battery status.
Page | 10
9V External Battery
9V external battery is used to operate the lock when the battery is fully discharged.
Note: The above battery must be 9V alkaline battery (6LR61).
