Due to regular upgrades of systems and products, ZKTeco could not guarantee exact consistency between the actual product and the written information in this manual.ProFace X (DS)Version: 1.0Installation Guide

1How to Install the Device?①Attach the mounting template sticker to the wall, and drill holes according to the mounting paper.②Fix the backplate on the wall using wall mounting screws.③Attach the device to the backplate.④Fasten the device to the backplate with a security screw.Install on the wall1241.5m3Please refer to the following recommendations for installation.AVOID DIRECT SUNLIGHT AND EXPOSUREAVOID GLASS REFRACTIONKEEP EFFECTIVEDISTANCE0.3-2.5mKEEP DISTANCE10ft

6.5ft

window

①②

2Install on the barrier gate12Please thread the wire through the bracket before installation.①Drill a hole on the barrier gate, insert the bracket into the hole and fix it with a nut.②Adjust the angle of the device. 30mm①②

3Door Sensor, Exit Button & Alarm ConnectionDoor SensorAlarm Power AlarmDetector Power SmokeDetectorExitButton

-+-+

AUXAL+AL-NC

COM

NOBUTGNDSENGNDGNDNOCOMWiegand Reader ConnectionAccess controller+12VGNDWiegand readerINWD0INWD112VGNDWD0WD1

4Barrier ConnectionRS485 ConnectionBarrier gate+12VGNDGND485+485-12V485B485AGNDTXD1RXD1GNDGNDGND12V12V485 reader12V485B485AGNDTXD1RXD1GNDGNDGND12V12VNote: 485A and 485B can be connected to the Barrier gate or the 485 Reader, separately, but cannot be connected to the gate and reader at the same time.

Ethernet ConnectionConnect the device and computer software over an Ethernet cable. An example is shown below: : 192.168.1.201Default IP address: 255.255.255.0 Subnet mask : 192.168.1.130IP address: 255.255.255.0 Subnet maskNote: In LAN, IP addresses of the server (PC) and the device must be in the same network segment when connecting to ZKBioSecurity software.Click on [Comm.] > [Ethernet] > [IP Address], input the IP address and click on [OK].Power Connection12V3ADCRecommended power supply: 12V - 3ATo share the power with other devices, use a power supply with higher current ratings. 5ZKBioSecurity

RS232PrinterPrinter Connection12V485B485AGNDTXD1RXD1GNDGNDGND12V12VDownload CenterScan the QR Code to download the User Manual, Installation Guide and Quick Start Guide.

QR Code (Download Center)
