SpeedFace-V3L (Lite)
Due to regular upgrades of systems and products, ZKTeco could not guarantee exact consistency between
the actual product and the written information in this manual.
Installation Guide
How to install the device?
INSTALL INDOORS
ONLY
AVOID DIRECT
SUNLIGHT
AND EXPOSURE
AVOID INSTALLATION
NEAR
GLASS WINDOWS
AVOID USE OF ANY
HEAT SOURCE
NEAR THE DEVICE
Installation on the wall
①
②
③
④
Attach the mounting template sticker to the wall, and drill holes
according to the mounting paper.
Fix the backplate on the wall using wall mounting screws.
Attach the device to the backplate.
Fasten the device to the backplate with a security screw.
1 2
43
1.5m
Baseline
1
1
2
Installation Environment
Please refer to the following recommendations for installation.
2
How to connect the device?
Refer to the following wiring to connect the device.
Terminal Block
Exit Button, Door Sensor & Bell Connection
Exit Button
Door Sensor
Bell
BUT
GND
SEN
BELL-
BELL+
TX+
TX-
BUT
GND
SEN
BELL-
BELL+
RX-
RX+
GND
+12V
NO
COM
NC
Network
Interface
Power In
Lock
Exit Button
Sensor
Bell
3
Power Connection
Recommended AC adapter: 12V ± 10%, at least 1500mA.
Use an AC adapter with a higher current rating to share power
with the other devices.
AC Adapter
DC12V
Ethernet Connection
Connect the device and the computer software over an Ethernet cable.
As shown in the example below:
Default IP address: 192.168.1.201
: Subnet mask 255.255.255.0
: 192.168.1.130IP address
: 255.255.255.0 Subnet mask
Click [COMM.] > [Ethernet] > [IP Address] to change the IP address
and then click [OK].
Note: In LAN, the IP addresses of the server (PC) and the device must
be in the same network segment while connecting to the software.
ZKBioAccess
Lock Relay Connection
The system supports Normally Opened Lock and Normally Closed
Lock. The NO LOCK (normally opened at power on) is connected
with 'NO' and 'COM' terminals, and the NC LOCK (normally closed
at power on) is connected with 'NC' and 'COM' terminals.
Take NC Lock as an example below:
Device not sharing power with the lock
GND
+12V
NO
COM
NC
DC12V
DC12V
Normally Closed Lock
FR107
Download Center
Scan the QR Code to download the User Manual, Installation Guide and
Quick Start Guide.
4
ZKTeco Industrial Park, No. 32, Industrial Road,
Tangxia Town, Dongguan, China.
Phone : +86 769 - 82109991
Fax : +86 755 - 89602394
www.zkteco.com
Copyright © 2022 ZKTECO CO., LTD. All Rights Reserved.
