ZERO-X ZX-40 Manuel utilisateur
4K UHD Action Camera with Dual Display & WiFi
USER MANUAL
ZX-40
3
CONTENTS
1.0 INTRODUCTION............................................................................... 6
2.0 ABOUT THE ZX-40 .......................................................................... 6
3.0 WHATS IN THE BOX......................................................................... 7
4.0 COMPONENTS................................................................................. 7
5.0 GETTING STARTED ........................................................................................... 8
5.1 CHARGING THE BATTERY .................................................................9
5.2 MICRO SD CARD COMPATIBILITY.................................................. 10
5.3 TOUCH SCREEN COMPONENTS ...................................................10
5.4 POWERING ON YOUR ZX-40...........................................................10
5.5 FORMAT YOUR MICRO SD CARD...................................................11
6.0 ZX-40 CONTROLS AND FUNCTIONS............................................ 12
6.1 POWER ON/OFF BUTTON .............................................................. 12
6.2 SHOOT/RECORD BUTTON .............................................................12
6.3 ACCESSING SYSTEM SETTINGS..................................................... 12
6.4 SETTING THE TIME........................................................................... 13
6.5 SETTING THE TIME FORMAT ..........................................................14
6.6 SETTING THE DATE.......................................................................... 15
4
6.7 AUTO POWER OFF...........................................................................16
6.8 WiFi ............................................................................................... 17
6.9 WiFi INFORMATION .........................................................................18
6.10 RESET WiFi......................................................................................... 19
6.11 USE FRONT SCREEN VIEW..............................................................20
6.12 ROTATE IMAGE.................................................................................21
6.13 DVR MODE ........................................................................................ 22
6.14 SCREEN SAVER..................................................................................23
6.15 LED INDICATOR ................................................................................24
6.16 KEYPAD TONE................................................................................... 25
7.0 PICTURE & VIDEO SETTINGS ........................................................ 26
7.1 VIDEO MODE ....................................................................................27
7.2 SLOW MODE..................................................................................... 29
7.3 LOOP MODE .....................................................................................31
7.4 LAPSE MODE.....................................................................................33
7.5 PHOTO MODE ..................................................................................35
7.6 AUTO MODE .....................................................................................37
7.7 BURST MODE ....................................................................................39
5
7.8 TIMER MODE..................................................................................... 41
7.9 PLAYBACK MODE ............................................................................. 43
8.0 RESTORE DEFAULT SETTINGS....................................................... 44
9.0 FIRMWARE VERSION ..................................................................... 45
10.0 INSTALLING AND USING THE ZX-ACTION APP .......................... 46
11.0 MANUAL STEPS FOR CONNECTING TO THE ZX-ACTION APP... 46
11.1 ZX-ACTION APP ................................................................................47
11.2 SAVING PHOTOS AND VIDEOS VIA THE APP...............................48
11.3 REMOTE PHOTO/RECORD VIA THE APP ......................................49
11.4 ADJUSTING SETTINGS VIA THE APP .............................................50
12.0 WARRANTY TERMS & CONDITIONS............................................. 51
6
1.0 INTRODUCTION
Thank you for purchasing the ZX-40 action camera. Please read through the
User Manual before attempting to use the ZX-40.
FEATURES
• 4K UHD Recording
• 1.4”LCD Front Display Screen
• 2.0” LCD Rear Display Screen
• Waterproof Case
2.0 ABOUT THE ZX-40
The Zero-X ZX-40 shoots footage with dynamic realism, where action is
effortlessly captured into moments you can keep. The ZX-40 comes with a
range of included accessories to create fully immersive footage. To learn
more about our extended accessory range and for details on stockists,
please visit the Zero-X website.
www.zero-x.com.au | www.zero-x.co.nz.
7
3.0 WHATS IN THE BOX
4.0 COMPONENTS
1 x ZX-40 Action Camera
1 x USB Charging & Data Cable
1 x Waterproof Casing
1 x Bike Mount
2 x Quick Release Mounts
2 x 3M Adhesive Mounts
3 x 3 Way Mounts
1 x Frame Mount
4 x Straps
1 x Helmet Base
1 x Adaptor Mount
1 x Metal Tether
2 x 3M Adhesive Pads
1. Mode On/Off Button
2. Shoot/Record Button
3. Up/WiFi On-Off
4. Down/Switch Screen
5. Front Screen
6. Micro USB Charging
Port
7. Micro HDMI Out Port
8. Micro SD Card Slot
12
9
5
4
3
6
8
7
MODE
8
5.0 GETTING STARTED
CAUTION:
Before using your action camera please ensure you read and understand the following
product and safety precautions.
• Do not use the ZX-40 in water without the waterproof case.
Do not use the ZX-40 with the waterproof case in water deeper than 30m.
• Always check the waterproof case seal is clean and free of debris prior to use in water.
• Do not attempt to open the ZX-40 or modify it in any way. If the ZX-40 has been tampered
with the warranty will be void. Maintenance and repairs should only be performed by
Zero-X.
• If you have wet hands, do not handle or charge the ZX-40 without it enclosed in the
waterproof case. Failure to do so may result in damage to the camera and/or injury.
• Only recharge the ZX-40 battery using the supplied USB cable.
• Do not use the ZX-40 in temperatures that exceed 55°C.
• Do not drop, crush, pierce, bend, deform, microwave, incinerate or shoot the ZX-40.
9
BATTERY WARNING
Always charge the ZX-40 using the provided USB Cable. If the ZX-40 is not charged as
directed in this manual, the battery may become damaged and fail.
• Never dismantle the ZX-40 or expose the internal battery cell.
• Do not dispose of the ZX-40 in fire.
• Please dispose of the ZX-40 mindfully and observe local regulations, especially in regards
to the safe disposal of the internal battery. Check your local recycling facility for more
information.
• Only use a certified 5V 1A USB charger to charge the ZX-40. Using non certified chargers
could potentially damage the ZX-40, or the ZX-40 battery and void the warranty.
• Do not let the battery charge overnight.
• If the ZX-40 seems to still need charging after three hours, temporarily remove it from
its charger as the battery may overheat. Let it cool down for 30 minutes and try charging
again.
5.1 CHARGING THE BATTERY
We recommend that you fully charge your ZX-40 before use. A full
charge will take approximately 2.5 hours using a 5V 1A Charger.
10
5.2 MICRO SD CARD COMPATIBILITY
The ZX-40 requires a Micro SD Card (not included) to save the files.
We recommend you use a maximum 128GB, UHS Class 3 or higher
Micro SD Card from a well known brand.
NOTE: There is only one correct way to insert the Micro SD Card into your ZX-40. It should
easily slide in. Do not force the card into the slot as it may damage the unit and the
card.
5.3 TOUCH SCREEN COMPONENTS
5.4 POWERING ON YOUR ZX-40
To power ON your ZX-40 follow the below steps:
1. Insert the battery into the unit.
2. PRESS and hold the ON/OFF BUTTON on the front of the unit
until the start up screen appears.
1
2 3 4
765
1. Current Mode
2.
Micro SD Card Inserted
3. Microphone ON
4. Battery Level
5. Playback
6. Mode Selection
7. Settings
