ZeeVee ZyPer4K Manuel utilisateur

ZyPer4K Decoder with

integrated Dante Transmitter

HDMI 2.0

IP A/V DISTRIBUTION SYSTEM

User Manual

Updated October 2019

About ZeeVee:

ZeeVee is the leading manufacturer of high-quality encoder/modulator/decoder products for

video distribution over any type of transmission media; be it RF coax, ﬁber, or copper ethernet.

Established in 2007, ZeeVee has been manufacturing industry-leading products while operating

the company responsibly in compliance with the strictest levels of regulatory and environmental

requirements. The standards by which we govern our corporate conduct are far higher than that

required by law.

Our mission is to completely fulﬁll the toughest customer application requirements with the

highest quality products we can produce. After the sale, we strive to support the customer with

award-winning support and service. Our goal is that no customer shall be ever be dissatisﬁed.

It is both our mission and our passion.

ZeeVee, Incorporated

295 Foster Street, Suite 200

Littleton, Massachusetts

01460, USA

www.zeevee.com

[email protected]

Phone: 1-877-493-3833

CONTENTS

Decoder Function 1.................................................................................

Decoder 2.......................................................................................................

Enclosure variants 2.............................................................................

Common Ports 2..................................................................................

Optional Ports: 10Gb Ethernet 4..........................................................

Optional Ports: USB 5..........................................................................

Optional Ports: Display Port 5..............................................................

Option: Dante Transmitter 6.................................................................

Dante Operation 7................................................................................

Device Technical Speciﬁcations 13.........................................................

Encoder and Decoder HDMI Video Speciﬁcations 13..........................

Dante Transmitter Speciﬁcations 15....................................................

Physical and Environmental 16............................................................

Physical Dimension Diagrams 17...........................................................

Disclaimers 18.........................................................................................

iii

ZyPer4K

Decoder Function

The function of the ZyPer4K Decoder device (Decoder) is to accept 10G Ethernet trafﬁc that

represents the information to be decoded and displayed. When the appropriate IP stream is

received the Decoder unit will ﬁrst strip off the encryption that protects the payload on its transit

across the network. It then reformats the video and audio information for display and plays it

out its HDMI video output. Audio is also played out the appropriate port as included.

Other ports on the Decoder devices are for the carriage of USB, IR, RS232 and audio data as

well as a 1Gbit/second utility port for general purpose connectivity of devices to the 10Gb bulk

data infrastructure.

Common Interfaces on all Decoders:

•Power Input (12VDC)

•RS232 Input/Output

•1Gbit/sec Utility Ethernet Port

•Analog Audio Output

•Infrared Input and Output

•HDMI 2.0 Output

•Equipotential Grounding Lug

Ethernet Bulk Media Interface:

10Gb Fiber or 10Gb Copper

Optional Interfaces on Decoder Units:

DisplayPort:

(none) or present

USB:

(none) or

2x USB Type-A Interface

Dante Transmitter:

(none) or present

In total there are 14 different, unique Decoder types that can be ordered.

HDMI Fiber

HDMI Fiber with USB

HDMI Copper

HDMI Copper with USB

DisplayPort Fiber

DisplayPort Fiber with

USB

DisplayPort Copper

DisplayPort Copper with

USB

HDMI Fiber with Dante

Transmitter

HDMI Fiber with USB

and Dante Transmitter

HDMI Copper with

Dante Transmitter

HDMI Copper with

USB and Dante

Transmitter

HDMI Fiber (Quiet/

Fanless)

HDMI Copper (Quiet/

Fanless)

Z4K Dante User Manual

Page of118

ZyPer4K

Decoder

The function of the ZyPer4K Decoder is to accept a 10Gb IP feed containing the video

information to be displayed. It decrypts, decodes and formats the video and audio information

for display on the attached viewing device. The decoder is capable of outputting any HDMI 2.0

resolution supplied by the encoder including full 4K, 4:4:4 at 60Hz. There are several different

variations based on the user’s desired media type and USB options.

Enclosure variants

There are three sizes of the ZyPer4K Decoder unit enclosure.

Common Ports

The following ports are common to all decoders, regardless

of the interface options.

Output Function

Box Size

HDMI Output

Base unit: 175mm Wide x 43mm High x 144mm Deep

HDMI Output (Quiet/Fanless)

Base unit: 164mm Wide x 44mm High x 145mm Deep

HDMI and DisplayPort Output

Base unit: 175mm Wide x 43mm High x 144mm Deep

HDMI + Dante Transmitter

Extended unit: 227mm Wide x 43mm High x 144mm Deep

Port Name

Index

Deﬁnition

Power

12VDC from supply at 1.2A (center +, ring-)

Port Name

Z4K Dante User Manual

Page of218

ZyPer4K

Utility

Network

10/100/1000Base-T Ethernet port. Used for general purpose

device attachment to network. Trafﬁc will be switched on to

media network. (Not available on models with Dante transmitter)

Ground Lug

For equipotential referencing of the box, this lug may be

connected the environmental ground using a customer-supplied

ground lead.

Index

Deﬁnition

Port Name

Index

Deﬁnition

HDMI Output

HDMI 2.0 Output port. Capable of up to 4K60 4:4:4 with embedded

audio and HDCP2.2 encryption.

Port Name

Index

Deﬁnition

RS 232 Port

RS232 Control Port for sending and receiving side-band serial trafﬁc to/from

encoders as directed by ZyPer Management Platform. (ZMP)

LED PWR

LED illuminated when unit is powered

LED VID

LED Illuminated when active video is being processed

Port Name

Z4K Dante User Manual

Page of318

ZyPer4K

Optional Ports: 10Gb Ethernet

Audio

Audio Output Jack. Drives line-level stereo audio on 3.5mm jack. (Not

available on models with Dante Transmitter)

IR-OUT

Infrared Commands information passed FROM Encoders to Decoders as

conﬁgured by ZMP.

IR-IN

Infrared Commands to be passed TO Encoders as conﬁgured by ZMP.

RESET

Reset to factory defaults. Using a wire or paper clip, lightly press into this hole

while unit is being powered on. Hold for 10 seconds to reset the unit to factory

defaults.

Index

Deﬁnition

Port Name

Index

Deﬁnition

10G Fiber

10 Gigabit Ethernet Connection. Uses standard 10Gb SFP

devices.

10G Copper

10Gb Ethernet over Cat6a or better cabling. RJ45

Z4K Dante User Manual

Page of418

ZyPer4K

Optional Ports: USB

The ZyPer4K Decoder device can be ordered with optional USB

connectivity.

Shown to the left is a unit with the USB option (top) and without the

USB option (bottom) installed. This is a build-time option and is not

retroﬁttable to the product.

Important Note

The USB system requires its own IP Address that is different and independent from the IP

Address of the ZyPer4K itself. Customers that are using a DHCP server to generate IP

Addresses must ensure the pool of available IP Addresses accounts for any ZyPer4K USB

devices in the system.

If no DHCP server is available, the USB controller will assign itself a Link-Local address.

However, if there is a DCHP server, but there are not enough addresses available in the pool,

USB connections may fail.

There is no means of setting the USB controller with a Static IP address.

Optional Ports: Display Port

The ZyPer4K Decoder device can be ordered with an optional

DisplayPort output.

Note: DisplayPort output port does not support any Audio

capabilities.

Port Name

Index

Deﬁnition

USB

2 ports of USB 2.0 Type-A connectivity. Either port may be used

and both operate simultaneously.

Z4K Dante User Manual

Page of518

ZyPer4K

Option: Dante Transmitter

The ZyPer4K Decoder device can be ordered

with an optional internal Dante Transmitter.

Note this is an extended box to accommodate

the Dante Transmitter hardware.

Important Note

The Dante Transmitter requires its own IP Address that is different and independent from the IP

Address of the ZyPer4K itself. Customers that are using a DHCP server to generate IP

Addresses must ensure the pool of available IP Addresses accounts for any ZyPer4K decoders

with Dante Transmitters in the system.

If no DHCP server is available, the Dante Transmitter will assign itself a Link-Local address.

However, if there is a DCHP server, but there are not enough addresses available in the pool,

Dante connections may fail.

The Dante Transmitter can be assigned a Static IP address via the Dante Controller software.

Z4K Dante User Manual

Page of618

ZyPer4K

Dante Operation

It is expected that the user is familiar with Dante and the use of Dante networks. It is beyond the

scope of this document to provide Dante training.

The Dante Transmitter found in the ZyPer4K decoder will automatically insert the Down-mix

Audio stream that it is receiving onto the Dante Network. Refer to the ZyPer Management

Platform User Guide for details on streaming audio/video from an encoder to a decoder.

https://cdn2.hubspot.net/hubfs/4316736/SUPPORT/USER-GUIDES/ZyPer-Management-

Platform-User-Manual.pdf

Network settings are the same as standard ZyPer4K encoders/decoders.

Some switches may require additional settings to work with a Dante network. For example the

Netgear M4300 series requires settings detailed at the following location:

https://kb.netgear.com/000060205/M4300-Conﬁguration-Guide-for-Dante-Audio-Devices

The user should consult the documentation for the switch provider being used.

In Dante Controller the device will appear as a Transmitter with the name ZV-XXXXXX-YYYYYY

XXXXXX - Represents the ﬁnal bytes of the ZyPer4K MAC Address

YYYYYY - Represents the ﬁnal bytes of the Dante AVIOAI2 Transmitter MAC Address

Note that the device can be renamed in Dante Controller software.

Below are screen shots from Dante Controller.

Z4K Dante User Manual

Page of718
