Zavio D8520 Manuel utilisateur
Motorized Outdoor Dome
86085A3000010
1
Please follow the installation steps below to set up Motorized Outdoor Dome IP
Camera.
Check the package contents against the list below. See P.1
Physical overview. See P.2
I/O Terminal Block Circuit. See P.3
I/O Terminal Block Pin Definition. See P.3
LED Indicator Definition. See P.4
Power mode. See P.4
Install the hardware and connect all cables. See P.5
Microsoft OS: Use the software CD to install Intelligent IP Installer. See P.8
Access the IP Camera using Intelligent IP Installer. See P.9
Mac OS using Safari Browser. See P.11
Change light environment setting. See P.12
Change the Web Interface into your preferred language. See P.12
Application of IP Camera. See P.13
For more information, please check the User Manual available in the Software CD.
Package Contents
Note:
Power Adapter and CAT5 cables are supplied by user. 2pin I/O terminal block is for
DC 12V Power Adapter used.
Camera
Motorized Outdoor Dome IP Camera
Quick
Installation
Guide
Brief product information and quick installation
Software CD
IP surveillance software
Intelligent IP Installer
User manuals
Language packs
Accessory
Mounting plate
Screw pack for wall and ceiling mounting
Alignment sticker
L-type hex key wrench
2pin I/O terminal block for power
2
Physical overview
Dome bubble
Conduit hole
Network / PoE
Lens
SD card slot
Reset
Network Link status indicator
Power status indicator
DC 12V/1.5A
Light Sensor
IR LEDs (16units,
Distance 20m)
I/O Terminal Block:
1: Ground,
2: +12VDC,
3: Audio in,
4: Audio out,
5: Digital Output 1,
6: Digital Output 2,
7: Digital Input 1,
8: Digital Input 2
Fan
RCA
Smart focus
control
NTSC/ PAL
switch
SD Card status indicator
3
I/O Terminal Block Circuit
I/O Terminal Block Pin Definition
This Camera provides an external I/O terminal block which is used to connect
input/ output devices. The pin definitions are described below.
PIN
Definition
Description
Max. V/A
1
Ground
-
2
+ 12VDC
12V DC
1.2 W
3
Audio In
Unbalanced, 1.4Vp-p, 1Vrms, terminal block
-
4
Audio Out
Unbalanced, 1.4Vp-p, 1Vrms, terminal block
-
5
Digital
Output 1
Uses an NPN transistor with the emitter
connected to the GND pin. If used with an
external relay, a diode must be connected in
parallel with the load for protection against
voltage transients.
100 mA
24V
6
Digital
Output 2
Uses an NPN transistor with the emitter
connected to the GND pin. If used with an
external relay, a diode must be connected in
parallel with the load for protection against
voltage transients.
100 mA
24V
7
Digital
Input 1
Connected to GND to activate, or leave
floating (or unconnected) to deactivate.
30V DC
8
Digital
Input 2
Connected to GND to activate, or leave
floating (or unconnected) to deactivate.
30V DC
4
LED Indicator Definition
LED
Color
Indication
Network
Blue
Steady blue for Network link
Flash blue while Network activity
Power
Red
Steady red for booting up process
Blue
Steady blue for booting up completion
Unlit
when reset button pressed for at least 5 sec.
to factory default
SD Card
Yellow
Steady yellow means SD card ready
Flashes yellow while accessing SD card
Reset: When the device is empowered, press the Reset Button to reboot the
device, or hold the Reset Button for
10 seconds to the settings back to factory default.
Reset process: Press reset button until indicator Unlitsteady red (booting up
process)steady blue (booting up completion)
Reset to default process: Press until indicator steady bluesteady red (booting
up process)steady blue (booting up completion)
Power Mode
PoE
Mode
at
Power
Requirement
PoE (IEEE802.3at) with Class 4
Power
Consumption
3.67W, without IR/ Fan
12.79 W, with max. IR on
5.04 W, with max. Fan on
14.05 W, with max. IR(100%) and Fan on
af
Power
Requirement
PoE (IEEE802.3af) with Class 3
Power
Consumption
3.67 W, without IR/ Fan
9.21 W, with max. IR on
5.04 W, with max. Fan on
10.81 W, with max. IR(70%) and Fan on
Adaptor
Mode
Power
Requirement
12V/1.5A Adaptor
Power
Consumption
3.67 W, without IR/ Fan
13.1 W, with max. IR on
5.04 W, with max. Fan on
14.26 W, with max. IR and Fan on
Note: Fan will be actived while the inner temparature above 50℃and will be
inactivated while it drops under 45℃.
(for F3105)
5
Install the hardware and connect all cables
A. Hardware installation
a. Connect the power adaptor to the supplied 2pin I/O terminal block. Please
make sure the red wire of the power adapter is connected with the positive
polarity of the terminal block.
b. Loosen the tamper-proof screws using supplied L-type Hex Key Wrench and
remove the dome cover. Be careful not to scratch the dome cover.
c. Disassemble the cable gland as shown in below illustration.
d. Feed the network and I/O cable through the sealing nut, claw and cable gland.
Connect the cables to the camera. Attach the cable gland to the conduit hole.
Push the claw into the cable gland and tighten the sealing nut to secure the
cables.
e. Use the supplied blind plug to fill unused conduit hole.
f. Use of the cable gland is optional. For vandal-proof requirement of the cables,
use vandal-proof conduits instead.
B. Wall mounting and ceiling mounting
a. Attach the alignment sticker to the wall/ceiling. Drill five holes into the wall,
four for screws and one for the cable. Then hammer the supplied plastic
anchors into the screw holes and secure the mounting plate with supplied
screws.
b. Attach the camera to the mounting plate and turn the camera clockwise until
the clips snap to the mounting plate.
c. Put the O-rings on the two supplied screws and fix the camera to the mounting
plate from inside with them to prevent unauthorized removal.
6
C. Connect all cables
c1. Without Power over Ethernet (PoE) connection
1. Connect the power adaptor to the IP Camera.
2. Connect the IP Camera to a normal Hub / Switch / Router.
c2. Power over Ethernet (PoE)
1. Connect the IP Camera to a PoE-enabled Hub /
Switch / Router.
Note:
If using a non-PoE switch, please use a PoE power injector to connect the camera.
7
D.To adjust the view angle- 3 axis mechanism design
1. Turn the lens module right and left to your desired pan position.
2. Turn the lens module up and down to your desire tile position.
3. Turn the lens module to adjust the image orientation to satisfied angle.
Important:
Do not rotate the IR LEDs so that it gets blocked by the housing as it will
affect the IR performance (as shown below). If the image is upside down,
please use the image rotate function in Video Setting.
8
E. Completion
1. Clean the dome bubble to remove the dust and finger print.
2. Fix the tamper-proof screws using supplied special hex. Be careful do not
scratch the cover glass.
3. The installation is complete now.
Microsoft OS: Use the software CD to install Intelligent IP Installer
Power on your PC and insert the CD-ROM. The setup page will show up
automatically. Please follow these steps to install the firmware.
Select “Intelligent IP Installer” and follow the installation process to
complete the installation.
9
Access the IP Camera using Intelligent IP Installer
1. Please check two settings before using Intelligent IP Installer .
a. Browser’s Internet Properties
→Security
→Default Level
b. Browser’s Internet Properties →
Privacy →Uncheck Pop-up Blocker
2. Click the Intelligent IP Installer Icon on your desktop. The main page will
show up listing all active camera and video server devices. Select the
relevant IP camera from the list and click Link to IE.
