Zaber Technologies Inc. Sentry 2.0 Manuel utilisateur
User Manual
Console-Sized Gaming PC Case
User Manual
2Foreword
Dear User
Thank You for your interest in Sentry PC case. We hope you will enjoy using our product.
Sentry is a product directed to the tech-sa y customers and as such requires prior knowledge
and understanding of its principles, e en before ordering parts for a computer assembled in it.
Sentry targets ATX (mITX/SFX) and PCI-E compliant components for their attainability, howe er not all
components (especially GPU’s) on the market follow the ATX and PCI-E specifications mechanical
references, making it impossible to fit all of them inside such small form factor chassis.
Please read the following instructions before your first attempt to build inside Sentry. If you are missing
any parts or ha e other issues with the case, please contact us at sentry@zaber.com.pl.
Sentry Team
User Manual
3Safety Warnings
Package contains small elements that are not safe for small
children and pets.
Package contains bags that pose risk of choking for small
children and pets.
Assemble the product and keep the lefto er accessories
away from small children and pets
Assembled de ice including internal computer components
has significant weight reaching 7KG. Ne er position the
de ice where it poses a risk of falling on someone.
In transportation always put the bag with de ice on the
ehicle floor because in e ent of rapid breaking or collision
such hea y rigid object may become a deadly projectile.
Children should not carry this de ice in a backpack.
User Manual
4A out the manual
Please follow this manual to a oid problems during your PC installation.
Installing parts in wrong order may force you to start o er your build.
It is especially important if you plan on using All-In-One Liquid Cooling.
Important details for each step are marked with colours to be clearly isible.
Most of the images in this manual are ector graphics – you can see more
detail after zooming in on them.
Shapes of cables and other flexible elements are depicted in symbolic way.
Take note of the orientation of chassis in the drawings. Some steps require
orienting the case ertically for user-friendly installation of components.
If you encounter a situation when the parts do not seem to fit, do not try to force them to fit, as it poses
a risk of damaging the case or your computer components, which could oid warranty for them as well.
Some of the elements of the case ha e complex shapes, but they are designed to fit together properly,
If they don’t, or instructions may not be clear enough, please contact us at sentry@zaber.com.pl.
User Manual
5Preparations
Before you proceed to start your build inside Sentry 2.0, make sure
your components work outside the case. In situation of a part being
faulty and not working out of the box, it will sa e your time.
Always ground yourself when working with electronic components.
Prepare some space on a table or desk before starting your build.
It is recommended to use some kind of soft surface for the build,
like a full desk mouse pad/anti-esd build mat or a blanket.
Make sure there aren’t any loose screws, any sharp elements or
small crystalline particles on the build surface, that could scratch
either the case or your table, before placing the case body on it.
Always make sure to keep loose screws in one place where you
ha e control o er them. Magnetic tray may help you organise them.
User Manual
6Screws and small pieces
M3x6
x20
M3x6
x20
Feet
x4
Included in Sentry 2.0 package
6-32x6
x4
6-32x30
x4
washer
x4
Required in AIO Cooler package
6-32x6
x4
Required for 3.5” HDD Installation
OR
6-32x6
x4
washer
x4
6-32x6
x4
Required in PSU package
6-32x6
x4
OR
User Manual
7Body Disassem ly
1
2
3
User Manual
Sentry 2.0 AIO configuration makes cable management extremely
challenging and is recommended only to experienced PC builders.
If you plan on using 120 mm All-In-One closed-loop liquid cooling
inside your Sentry 2.0, please read the following instructions carefully.
It is recommended to use standard profile memory sticks when using
AIO in Sentry 2.0, as most of the space abo e them will be occupied by
cables mo ed there in order to make space for liquid cooling hoses.
Before you start, detach any mounting brackets from your AIO liquid
cooler CPU block. If your cooler is in factory condition, don’t remo e
the cold plate protection just yet.
Wrap the CPU block with some soft material like a towel or packaging
foam and make sure it won’t fall off on its own. This will pre ent it from
scratching anything around while you are focused on mounting other
components in the case.
It is important because the liquid cooler CPU block will be mounted on
the CPU as one of the last components in your build. If you can’t find a
safe way to wrap it, you can ask someone to hold it for you while you
are building your system, but it will take some time.
8AIO Build Preparations
User Manual
9
AIO Package Compati ility
optional step – AIO CONFIG
Total space for 120 mm AIO Liquid Cooling radiator and fan package is 50 mm.
Recommended configurations
- Standard 27 mm thick radiator + Slim 20 mm thick fan (total package thickness of 47 mm)
- Slim 22 mm thick radiator + Standard 25 mm thick fan (total package thickness of 47 mm)
Radiators thicker than 27 mm were not tested and are most likely incompatible due to tube bending
radius limitation. Tubes need to bend tightly in order to fit under the chassis cover.
Getting close to 50 mm of total package thickness will limit airflow between the fan and chassis cover.
50mm
FAN
RADIATOR
User Manual
10AIO Radiator installation
optional step – AIO CONFIG
1
3
2
Use washers if your M3.5 screws have an uneven bottom to prevent them from scratching powder
coating surface on the outside of chassis.
6-32x6
x4
6-32x6
x4
washer
x4
OR
