Yoshimura 070BG131001 Manuel utilisateur

RESEARCH&DEVELOPMENT OF AMERICA, INC.

www.yoshimura-rd.com

FENDER ELIMINATOR KIT

070BG131001

Yamaha FZ-10

5420 DANIELS STREET STE A, CHINO CA., 91710 · (800) 634-9166 · (909) 628-4722 · FAX (909) 591-2198

THIS PRODUCT IS NOT DOT APPROVED.

Yoshimura R&D of America, Inc. is not liable or responsible for any resulting event caused by the

installation of this product. Check with local laws and regulations for compliance prior to

installation and use. This product is not intended for use on public highways.

! !

No.

Item

Description

Qty.

13100-FEBKT

Fender Eliminator Bracket

12200-FEBKT

License Plate bracket

070BG-LH-K1

LED License Plate Light

070BG-LPF

License Plate Frame

13630-TSBL-00

Left Turn Signal Bracket

13630-TSBR-00

Right Turn Signal Bracket

M4X6BHS

4mm x 6mm Button Head Screw

M6X10BHS

6mm x 10mm Button Head Screw

M6X14BHS

6mm x 14mm Button Head Screw

M6X16BHS

6mm x 16mm Button Head Screw

M6X20BHS

6mm x 20mm Button Head Screw

6MMWASHER

6mm Washer

6MMLN

6mm Nylon Lock Nut

BN-SSS-22-18

Butt Connectors

ZT-300

Cable Ties

17029

Yoshimura Sticker Sheet

Optional Parts

***

070BGUNVTBKT

Universal Turn Signal Bracket Kit

*** The Yoshimura Universal Turn Signal Bracket Kit is to be used with aftermarket stud-mounted turn signals and is sold separately.

Assembly Diagram

1. Remove rider seat.

2. Remove left and right rear side cover as per

Factory Service/Owners Manual.

3. Remove the four bolts securing the seat bracket

plate to the frame.

4. Locate and disconnect the license plate light

and rear turn signal connectors.

5. While supporting the stock fender assembly,

remove the four nuts securing the fender

assembly to the frame.

Note: Take precaution when removing the stock

fender assembly and avoid snagging the

stock license plate light and turn signal

connectors as they will be re-used.

6. Remove the plastic key hole cover from the

stock fender assembly.

Note: Key hole cover will be re-used. Do not

damage during disassembly.

7. Remove left and right turn signals from the

stock fender assembly.

8. Cut the stock license plate light connector wires

on the stock fender assembly side. Be sure to

cut at least a 6” section of wire from the

connector.

Removal

Installation

1. Install (No. 3) 070BG-LH-K1, Yoshimura license

plate light onto (No. 2) 12200-FEBKT,

Yoshimura license plate bracket using (No. 7)

M4X6BHS, 4mm button head screws provided

in the kit.

2. Install (No. 1) 13100-FEBKT, fender eliminator

bracket using (No. 11) M6X20BHS, 6mm button

head screws along with the stock nuts.

3. Install (No. 2) 12200-FEBKT, license plate

bracket onto (No. 1) 13100-FEBKT, fender

eliminator bracket using (No. 8) M6X10BHS,

6mm button head screws as shown in the

diagram below.

4. Install the stock plastic key hole cover onto

(No. 1) 13100-FEBKT, fender eliminator

bracket by inserting the key hole cover pins into

holes A and B.

Note: Check fitment and function of plastic key

hole cover. Confirm that the plastic key

hole cover is secure. If required, adjust

13100-FEBKT, fender eliminator bracket

by pinching the two sides and tightening

the four mounting screws.

5. Using the BN-SSS-22-18 butt connectors

provided in the kit, connect the Yoshimura

license plate light wires to the stock license

plate light wires as follows:

Blue w/ Red Stripe -to- Red Wire

Black Wire -to- Black Wire

a) Strip the stock fender light wire ends

1/4” - 1/2” and insert into BN-SSS-22-18,

butt connectors provided in the kit.

b) Center the spliced wire ends in the

middle and using a heatgun or lighter,

apply heat evenly on the outer edges of

the butt connector to shrink and hold

wires in place.

c) Making sure that the stripped ends are

centered, heat the center of the butt

connector evenly until the solder begins

to liquify.

d) Allow to cool completely and tug both

ends of the wires to verify that connection

is secured.

Scan for link to butt connector instruction video.

6. Install stock left and right turn signals onto

(No. 5,6) 13630-TSBL/R-00, turn signal

brackets.

7. Install (No. 5,6) 13630-TSBL/R-00, turn signal

brackets and (No. 4) 070BG-LPF, license plate

frame using the (No. 9,10) M6X16BHS and

M6X14BHS, 6mm button head screws as

shown below.

8. Route wires between the stock key hole cover

and (No. 1) 13100-FEBKT, fender eliminator

bracket and under the seat.

9. Reconnect left and right turn signal and license

plate light wires.

10. Re-install seat.

11. Check for proper function of license plate light,

turn signals, brake light, and that all brackets

and components are secure prior to riding.
