York XP SERIES W/SIMPLICITY Manuel utilisateur

R-410A

XP SERIES W/SIMPLICITY SE

15/20 Ton

60 Hertz

5168273-YIM-A-1115

TABLE OF CONTENTS

General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Limitations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Location. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Rigging And Handling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Ductwork . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Condensate Drain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Compressors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Power And Control Wiring. . . . . . . . . . . . . . . . . . . . . . . . . 14

Field Installed Electric Heat Accessories . . . . . . . . . . . . . 23

Options/Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Economizer Sequences . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Dry Bulb Changeover . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Single Enthalpy Changeover. . . . . . . . . . . . . . . . . . . . . . . 23

Dual Enthalpy Changeover . . . . . . . . . . . . . . . . . . . . . . . . 23

Auto. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Free Cooling Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Power Exhaust . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Setpoints . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Optional BAS-Ready Economizer Power Exhaust Damper

Set Point Adjustment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Air Balance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Sequence Of Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Cooling Sequence Of Operation . . . . . . . . . . . . . . . . . . . . 36

Cooling Operation Errors . . . . . . . . . . . . . . . . . . . . . . . . 36

Electric Heating Sequence Of Operations . . . . . . . . . . . . 37

Defrost Termination . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Interval between Defrosts . . . . . . . . . . . . . . . . . . . . . . . 38

Forced Defrost . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Electric Heat Operation Errors . . . . . . . . . . . . . . . . . . . . 38

Start-Up (Cooling) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Charging The Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Normal Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Motors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Blower Shaft Bearing . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Outdoor Coil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Simplicity™ SE (Smart Equipment) Firmware Version 3.

Basic Unit Control Board Navigation Examples: . . . . . . . . 42

Start-Up Sheet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

LIST OF TABLES

1 XP180/240 Unit Limitations . . . . . . . . . . . . . . . . . . . . . . . . 6

2 XP180/240 Unit Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

3 XP180/240 Unit Accessory Weights . . . . . . . . . . . . . . . . . 9

4 XP180/240 Unit Clearances . . . . . . . . . . . . . . . . . . . . . . 12

5 Control Wire Sizes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

6 Electrical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

7 XP180/240 Physical Data . . . . . . . . . . . . . . . . . . . . . . . . 21

8 Electric Heat Minimum Supply Air . . . . . . . . . . . . . . . . . . 23

9 Simplicity SE Economizer Board Details . . . . . . . . . . . . 25

10 Altitude/Temperature Correction Factors . . . . . . . . . . . . 30

11 Air Flow Performance - Side Duct Application . . . . . . . . 32

12 Air Flow Performance - Bottom Duct Application . . . . . . 33

13 RPM Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

14 Indoor Blower Specifications . . . . . . . . . . . . . . . . . . . . . 34

15 Power Exhaust Specifications . . . . . . . . . . . . . . . . . . . . 34

16 Additional Static Resistance . . . . . . . . . . . . . . . . . . . . . . 35

17 Limit Control Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

18 Electric Heat Anticipator Setpoint . . . . . . . . . . . . . . . . . . 39

19 Simplicity SE UCB Details . . . . . . . . . . . . . . . . . . . . . . . 44

LIST OF FIGURES

1 XP240 Component Location . . . . . . . . . . . . . . . . . . . . . . 6

2 XP240 Unit 4 Point Load Weight . . . . . . . . . . . . . . . . . . . 8

3 XP240 Unit 6 Point Load Weight . . . . . . . . . . . . . . . . . . . 8

4 XP180 Unit 4 Point Load Weight . . . . . . . . . . . . . . . . . . . 8

5 XP180 Unit 6 Point Load Weight . . . . . . . . . . . . . . . . . . . 8

6 Center of Gravity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

7 XP240 Unit Dimensions Front View . . . . . . . . . . . . . . . . . 9

8 XP180 Unit Dimensions Front View . . . . . . . . . . . . . . . . 10

9 XP180/240 Unit Dimensions Rear View . . . . . . . . . . . . 11

10 XP180/240 Unit Dimensions Rain Hood . . . . . . . . . . . . 12

11 XP180/240 Roof Curb . . . . . . . . . . . . . . . . . . . . . . . . . . 12

12 Fixed Outdoor Air Damper . . . . . . . . . . . . . . . . . . . . . . . 13

13 Condensate Drain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

14 Field Wiring Disconnect - Heat Pump Unit With/Without

Electric Heat. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

15 Typical Field Wiring 24 Volt Thermostat . . . . . . . . . . . . 16

16 SE-ECO1001-0 Economizer Controller . . . . . . . . . . . . . 25

17 Belt Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

18 Altitude/Temperature Correction Factors . . . . . . . . . . . . 30

19 Pressure Drop Across A Dry Indoor Coil Vs. Supply Air CFM

For All Unit Tonnages . . . . . . . . . . . . . . . . . . . . . . . . . . 34

20 XP180 (15 Ton) Charging Chart . . . . . . . . . . . . . . . . . . 40

21 XP240 (20 Ton) Charging Chart . . . . . . . . . . . . . . . . . . 40

22 Unit Control Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

5168273-YIM-A-1115

2Johnson Controls Unitary Products

General

YORK®Model XP units are single package Heat Pump with

electric heaters (Field Installed Accessory Only). Designed for

outdoor installation on a rooftop or slab.

The units are completely assembled on rigid, permanently

attached base rails. All piping, refrigerant charge, and electrical

wiring is factory installed and tested. The units require electric

power, duct connections and fixed outdoor air intake damper

(units without economizer or motorized damper option only) at

the point of installation.

The electric heater accessories have nickel-chrome elements

and utilize single point power connection.

Safety Considerations

This is a safety alert symbol. When you see this symbol on

labels or in manuals, be alert to the potential for personal injury.

Understand and pay particular attention the signal words

DANGER, WARNING or CAUTION.

DANGER indicates an imminently hazardous situation, which,

if not avoided, will result in death or serious injury.

WARNING indicates a potentially hazardous situation, which,

if not avoided, could result in death or serious injury.

CAUTION indicates a potentially hazardous situation, which, if

not avoided may result in minor or moderate injury.It is also

used to alert against unsafe practices and hazards involving

only property damage.

Due to system pressure, moving parts, and electrical

components, installation and servicing of air conditioning

equipment can be hazardous. Only qualified, trained service

personnel should install, repair, or service this equipment.

Untrained personnel can perform basic maintenance functions

of cleaning coils and filters and replacing filters.

Observe all precautions in the literature, labels, and tags

accompanying the equipment whenever working on air

conditioning equipment. Be sure to follow all other applicable

safety precautions and codes including ANSI Z223.1 or CSA-

B149.1- latest edition.

Wear safety glasses and work gloves. Use quenching cloth and

have a fire extinguisher available during brazing operations.

Inspection

As soon as a unit is received, it should be inspected for possible

damage during transit. If damage is evident, the extent of the

damage should be noted on the carrier’s freight bill. A separate

request for inspection by the carrier’s agent should be made in

writing.

Improper installation may create a condition where the

operation of the product could cause personal injury or

property damage. Improper installation, adjustment,

alteration, service or maintenance can cause injury or

property damage. Refer to this manual for assistance or

for additional information, consult a qualified contractor,

installer or service agency.

This product must be installed in strict compliance with

the installation instructions and any applicable local,

state and national codes including, but not limited to

building, electrical, and mechanical codes.

Before performing service or maintenance operations on

unit, turn off main power switch to unit. Electrical shock

could cause personal injury. Improper installation,

adjustment, alteration, service or maintenance can

cause injury or property damage. Refer to this manual.

For assistance or additional information consult a

qualified installer or service agency.

This system uses R-410A Refrigerant which operates at

higher pressures than R-22. No other refrigerant may be

used in this system. Gage sets, hoses, refrigerant

containers and recovery systems must be designed to

handle R-410A. If you are unsure, consult the equipment

manufacturer. Failure to use R-410A compatible servicing

equipment may result in property damage or injury.

This product must be installed in strict compliance with

the enclosed installation instructions and any applicable

local, state and national codes including, but not limited

to, building, electrical, and mechanical codes.

5168273-YIM-A-1115

Johnson Controls Unitary Products 3

Reference

Additional information is available in the following reference

forms:

• Technical Guide - XP180/240, 5168280

• General Installation - XP180/240, 5168273

• Electric Heat Accessory Installation - 5128261

• SSE Control Quick Start Guide - 1136326

Renewal Parts

Contact your local York® parts distribution center for authorized

replacement parts.

Approvals

Design certified by CSA as follows:

1. For use as a Heat Pump unit with supplemental electric

heat.

2. For outdoor installation only.

3. For installation on combustible material..

Improper installation may create a condition where the

operation of the product could cause personal injury or

property damage.

This system uses R-410A Refrigerant which operates at

higher pressures than R-22. No other refrigerant may be

used in this system.

5168273-YIM-A-1115

4Johnson Controls Unitary Products

Nomenclature

X P 180 CA2 A 1 A1A A 1

Product Category

X = HP, Single Pkg., R-410A

B = Standard Static

D = High Static

E = VFD/VAV Std Static

G = VFD/VAV High Static

H = VFD/VAV w/Bypass Std Static

K = VFD/VAV w/Bypass High Static

L = VFD/VAV Customer Std Static

N = VFD/VAV Customer High Static

P = VFD IntelliSpeed Std Static

R = VFD IntelliSpeed High Static

S = VFD w/Byp IntelliSp Std Static

U = VFD w/Byp IntelliSp Hi Static

V = VFD Cust IntelliSp Std Static

X = VFD Cust IntelliSp Hi Static

Blower Option

Product Generation

1 = First Generation

C = Cooling Only

Heat Type

Heat Capacity

Nominal Cooling Capacity

180 = 15 Ton

240 = 20 Ton

Product Identifier

P = Pkg HP Std Eff

Voltage

2 = 208/230-3-60

4 = 460-3-60

5 = 575-3-60

Additional Options

1 = STD Throwaway Filter

2 = 2" Pleated Filters (Merv 8)

3 = 4" Pleated Filters (Merv 13)

4 = Coil Guard (CG), STD Filter

5 = 2" Pleated Filter,CG

6 = 4" Pleated Filter,CG

A = No Economizer

B = Economizer w/Barometric RLF1

C = Economizer w/o Barometric RLF

D = Economizer w/Power EXH1

H = Motorized Damper

J = Motorized Damper w/Baro RLF1

Outdoor Air Option

1 = No Service Options

2 = DSC (Disconnect Switch)

3 = NCO (Non-PWR Conv. Outlet)

4 = PCO (Powered Conv. Outlet)

5 = DSC,NCO

6 = DSC,PCO

7 = SCCR (High SCCR)

8 = SCCR,DSC

9 = SCCR,DSC,NCO

Refrigeration

A = Standard Refrigeration

B = ECC (ElectroFin Cond Coil)

C = EEC (ElectroFin Evap Coil)

F = ECC,EEC

Service Options

A = Stand Alone Simplicity SE

C = BACnet MSTP,Mdbs,N2 COM Card

D = CPC Control, DFS, APS

F = Fault Detection Diagnostics

G = Novar UCM Ctrl, DFS, APS

H = Hnywll Excel 10 CTRL,DFS,APS

J = CCS Single Zone

K = CCS Change Over Bypass

L = CCS VAV, APS

Controls Option

15 & 20 Ton York®Model Number Nomenclature

00 = Cooling Only

Note: 1. Available Downflow Only

A = Std Cabinet

B = HFD (Hinged FLTR/Toolless DR)

C = HCD (Hinged & Toolless ACS DR)

E = SSD (SST Drain Pan)

F = SSD,HFD

G = SSD,HCD

H = SSD,DBW/HCD

A = No Sensors

B = PHM (Phase Monitor)

C = DFS (Dirty Filter Switch)

D = SAD (Supply Air Smoke DET)

E = RSD (Return Air Smoke DET)

F = PHM,DFS

G = PHM,SAD

H = PHM,RSD

J = DFS,SAD

K = DFS,RSD

L = SAD,RSD

M = PHM,DFS,SAD

N = PHM,DFS,RSD

P = PHM,SAD,RSD

Q = DFS,SAD,RSD

R = PHM,DFS,SAD,RSD

Sensors

Cabinet Options

5168273-YIM-A-1115

Johnson Controls Unitary Products 5

Installation

Installation Safety Information

Read these instructions before continuing this appliance

installation. This is an outdoor combination heating and cooling

unit. The installer must assure that these instructions are made

available to the consumer and with instructions to retain them

for future reference.

1. This equipment is not to be used for temporary heating of

buildings or structures under construction.

2. If a factory option convenience outlet is installed, the

weatherproof outlet cover must be field installed. The cover

shall be located in the unit control box. To install the cover,

remove the shipping label covering the convenience outlet,

follow the instructions on the back of the weatherproof

cover box, and attach the cover to the unit using the (4)

screws provided.

Limitations

These units must be installed in accordance with the following:

In U.S.A.:

1. National Electrical Code, ANSI/NFPA No. 70 - Latest

Edition

2. Local building codes, and

3. Local electric utility requirements

In Canada:

1. Canadian Electrical Code, CSA C22.1

2. Installation Codes, CSA - B149.1.

3. Local plumbing and waste water codes, and

4. Other applicable local codes.

Refer to unit application data found in this document.

If components are to be added to a unit to meet local codes,

they are to be installed at the dealer’s and/or customer’s

expense.

Size of unit for proposed installation should be based on heat

loss/heat gain calculation made according to the methods of Air

Conditioning Contractors of America (ACCA).

This furnace is not to be used for temporary heating of buildings

or structures under construction.

208/230-3-60 units with factory installed Powered

Convenience Outlet Option are wired for 230v power

supply. Change tap on transformer for 208-3-60. See

unit wiring diagram.

The Simplicity® control board used in this product will

effectively operate the cooling system down to 0°F when

this product is applied in a comfort cooling application

for people. An economizer is typically included in this

type of application. When applying this product for

process cooling applications (computer rooms,

switchgear, etc.), please reference applications bulletin

AE-011-07 or call the applications department for

Unitary Products @ 1-877-UPG-SERV for guidance.

Additional accessories may be needed for stable

operation at temperatures below 30°F.

5168273-YIM-A-1115

6Johnson Controls Unitary Products

Figure 1: XP240 Component Location

Table 1: XP180/240 Unit Limitations

Size

(Tons) Unit Voltage Unit Limitations

Applied Voltage Outdoor DB Temp

Min Max Max (°F)

180

(15)

208/230-3-60 187 252 125

460-3-60 432 504 125

575-3-60 540 630 125

240

(20)

208/230-3-60 187 252 125

460-3-60 432 504 125

575-3-60 540 630 125

Simplicity

SE Control Board

110 Volt Convenience

Outlet (“Powered” or

“Non-Powered” Optional)

Disconnect Location

(Optional Disconnect Switch)

Bottom Power and

Control Wiring Entry

Electric Heater Location

(Electric Heat Offered as a Field-Installed Accessory Only)

Belt Drive

Blower Motor

14 Gauge

Base Rails

with Lifting Holes

1” NPT

Condensate Drain

Thermal

Expansion

Valve

Copper Tube/

Aluminum Fin

Evaporator

Coils

2” Disposable Filters

(4” Filters Optional)

Slide In/ Plug In

Internal Economizer

(Optional)

5168273-YIM-A-1115

Johnson Controls Unitary Products 7

Location

Use the following guidelines to select a suitable location for

these units:

1. Unit is designed for outdoor installation only.

2. Condenser coils must have an unlimited supply of air.

Where a choice of location is possible, position the unit on

either north or east side of building.

3. Suitable for mounting on roof curb.

4. For ground level installation, use a level concrete slab with

a minimum thickness of 4 inches. The length and width

should be at least 6 inches greater than the unit base rails.

Do not tie slab to the building foundation.

5. Roof structures must be able to support the weight of the

unit and its options/accessories. Unit must be installed on a

solid, level roof curb or appropriate angle iron frame.

6. Maintain level tolerance to 1/2” across the entire width and

length of unit.

Clearances

All units require particular clearances for proper operation and

service. Refer to Table 4 for clearances required for

combustible construction, servicing, and proper unit operation.

Rigging And Handling

Exercise care when moving the unit. Do not remove any

packaging until the unit is near the place of installation. Rig the

unit by attaching chain or cable slings to the lifting holes

provided in the base rails. Spreader bars, whose length

exceeds the largest dimension across the unit, MUST be used

across the top of the unit.

Units may be moved or lifted with a forklift, from the side only,

providing an accessory skid is used.

LENGTH OF FORKS MUST BE A MINIMUM OF 90 INCHES.

Do not permit overhanging structures or shrubs to

obstruct condenser air discharge outlet, or vent outlets.

If a unit is to be installed on a roof curb other than a

York®roof curb, gasketing must be applied to all

surfaces that come in contact with the unit underside.

Before lifting, make sure the unit weight is distributed

equally on the rigging cables so it will lift evenly.

All panels must be secured in place when the unit is

lifted.

The condenser coils should be protected from rigging

cable damage with plywood or other suitable material.

5168273-YIM-A-1115

8Johnson Controls Unitary Products

Figure 2: XP240 Unit 4 Point Load Weight Figure 3: XP240 Unit 6 Point Load Weight

Figure 4: XP180 Unit 4 Point Load Weight Figure 5: XP180 Unit 6 Point Load Weight

Figure 6: Center of Gravity

FRONT

Table 2: XP180/240 Unit Weight

Size

(Tons) Model Weight (lbs.) Center of Gravity 4 Point Load Location (lbs.) 6 Point Load Location (lbs.)

ShippingOperatingX Y ABCD A B C D E F

180 (15) XP 2145 2140 77.1 45 454 592 619 475 290 344 413 431 359 303

240 (20) XP 2655 2650 88.8 46 462 863 863 462 280 405 640 640 405 280

LEFT FRONT

5168273-YIM-A-1115

Johnson Controls Unitary Products 9

Figure 7: XP240 Unit Dimensions Front View

NOTE: All entry holes should be field sealed to prevent rain water

entry into the building.

Table 3: XP180/240 Unit Accessory Weights

Unit Accessory Weight (lbs.)

Shipping Operating

Economizer 165 160

Power Exhaust 90 85

Electric Heat1

1. Weight given is for the maximum heater size available

(72KW).

40 40

Double Wall2

2. Available on XP240 only.

260 260

Motorized Damper 150 150

Barometric Damper 50 45

Econ./Motorized Damper Rain Hood 60 55

Econ./Power Exhaust Rain Hood 95 90

Wood Skid 220 220

Roof Curb 190 185

Utilities Entry

Hole Opening Size

Diameter Used For

A1-1/8” KO Control Wiring Front

3/4” NPS (Fem.) Bottom

B3-5/8” KO Power Wiring Front

3” NPS (Fem.) Bottom

6-7/8

(A) CONTROL WIRING

ENTRY

COIL

GUARD

KIT

CONDENSER

COILS

(B) POWER

WIRING ENTRY

43-3/4

9-3/4

5-7/8

136-1/4

DOT PLUG

(For pressure

drop reading)

BLOWER

COMPARTMENT

ACCESS

(Auxillary)

CONTROL BOX

ACCESS

BLOWER MOTOR

ACCESS BLOWER

ACCESS

52-5/8

180-19/32 COMPRESSOR ACCESS

DISCONNECT

SWITCH

LOCATION

ECONOMIZER / MOTORIZED DAMPER

FIXED OUTDOOR INTAKE AIR AND

POWER EXHAUST RAIN HOODS

35-1/4

2-3/4 3-3/4

(B) POWER WIRING

ENTRY

BOTTOM SUPPLY

AND RETURN

AIR OPENINGS

(See Note)

(A) CONTROL WIRING

ENTRY

21-1/2

UNIT BASE RAILS

Shown separately to illustrate

Bottom Duct openings. Power

location.

RETURN

AIR

NOTE:

For curb mounted units, refer to the curb hanger

dimensions of the curb for proper size of the

supply and return air duct connections.

12-1/2

9-1/4

8-1/8

9-3/4

SUPPLY

AIR

14-3/4

OPTIONAL

ELECTRIC HEAT

ACCESS

5168273-YIM-A-1115

10 Johnson Controls Unitary Products

Figure 8: XP180 Unit Dimensions Front View

NOTE: All entry holes should be field sealed to prevent rain

water entry into the building.

Utilities Entry

Hole Opening Size

Diameter Used For

A1-1/8” KO Control Wiring Front

3/4” NPS (Fem.) Bottom

B3-5/8” KO Power Wiring Front

3” NPS (Fem.) Bottom

RETURN

AIR

SUPPLY

AIR

BOTTOM SUPPLY

AND RETURN

AIR OPENINGS

(See Note)

(B)

POWER WIRING

ENTRY

(A)

CONTROL WIRING

ENTRY

NOTE:

For curb mounted units, refer to the curb hanger

dimensions of the curb for the proper size of the

supply and return air duct connections.

UNIT BASE WITH RAILS

Shown separately to illustrate

Bottom Duct openings and Power

Connection locations

12-1/2"

9-1/4"

8-1/8"

9-3/4"

3-3/4"

(B)

POWER WIRING

ENTRY

(A)

CONTROL WIRING

ENTRY

92"

CONDENSER

COILS

OPTIONAL COIL

GUARD KIT

52-5/8"

COMPRESSOR

ACCESS

(See detail "X")

ECONOMIZER / MOTORIZED DAMPER,

FIXED OUTDOOR INTAKE AIR AND

POWER EXHAUST RAIN HOODS

(See detail "Y")

FIELD-SUPPLIED

DISCONNECT SWITCH

LOCATION

BLOWER

ACCESS

BLOWER MOTOR

ACCESS

BLOWER

COMPARTMENT

ACCESS

(Auxiliary)

DOT PLUG

(For pressure

Drop Reading)

FRONT

VIEW ELECTRIC HEAT

ACCESS

CONTROL BOX

ACCESS

136-1/4"

21"

9-3/4"

11-1/2"

2-3/4" 21-1/2"

33"

35"

5-7/8"

35-1/4"

RETURN AIR

SUPPLY A IR

OUTDOOR A IR

(Economizer)

OPTIONAL

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels York Chauffage électrique

York

York XA Series Manuel utilisateur

Manuels Chauffage électrique populaires d'autres marques

Heatscope

Heatscope PURE Guide rapide

Sunbeam

Sunbeam Calentador SFH457A Manuel utilisateur

Dura Heat

Dura Heat DH2000C Manuel utilisateur

Harvia

Harvia K10.5GS Manuel utilisateur

Harvia

Harvia GL70 Manuel utilisateur

Heylo

Heylo DE 2 XL Manuel utilisateur

Heylo

Heylo DE 20 SH Manuel utilisateur

Harvia

Harvia PP70SP Manuel utilisateur

Tylo

Tylo SENSE SPORT Manuel utilisateur

Dirna

Dirna ecodirna SUN Mode d’emploi

Creda

Creda Heating Solution Manuel utilisateur

THERMEx

THERMEx Frame E Wi-Fi Series Manuel utilisateur

SHUFT

SHUFT UniMAX-R 1400VE EC Manuel utilisateur

HUUM

HUUM CLIFF Series Manuel utilisateur

Harvia

Harvia HL70S Manuel utilisateur

Dimplex

Dimplex DHEBHT Manuel utilisateur

Radialight

Radialight SIRIO Manuel utilisateur

Polaris

Polaris PRE E 0715 H Manuel utilisateur
