YEYIAN SIGURO 3501 Manuel utilisateur
31.5” CURVED GAMING MONITOR / MONITOR GAMING CURVO 31.5”
SIGURD 3501
WELCOME TO YEYIAN
A NEW LEVEL OF WORLD GAMING
PRODUCT REGISTRATION
You’re one of the millions of gamers. You can be the socially engaged, the sport
fun, the explorer, the soldier, the builder or the strategist. All require sobrenatural
reexes, powerful machines, consistency and a strong tolerance for suffering
hundreds of defeats at the hands of other players before the fun kicks in. But there is
something unique required in a game, disruptive and exciting; a moment that allows
you to control what happens next; the millisecond you feel intimidated, the move
that will set you apart from the rest. Your decision in that moment, your condence,
your passion, and your determination to win, will take you to the monumental Victory.
Informatio n
and releases
Promotions
and update s
Giveaways
and gift s
Choose big, don’t settle and always keep going.
Be part of the game.
Thank you for choosing us and welcome to our family.
Registering your products, you can enjoy exclusive news, contest, and giveaways.
USA: www.yeyian.us I MX: www.yeyian.mx IES: www.yeyian.es
EMC COMPLIANCE
This device has been tested and found to comply with the standards for a class B
digital device, pursuant to Part 15 of FCC Rules. Those standards are designed
to provide reasonable protection against harmful interference in a residential
installation. This device generates and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful
interference to radio communications.
If this device does cause harmful interference to radio or television reception,
which can be determined by turning the device off and on, user is encouraged to
try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the device and receiver.
- Plug the device into a wall outlet different from that connected to the reciever.
- Consult the dealer or an experienced radio/TV technician for help.
CAUTION: Any change or modication not expressly illustrated in this manual
may void the warranty.
NOTE: Any unshielded cable is not allowed to
be used in the device.
The terms HDMI®, HDMI® High-Denition Multimedia Interface, and the HDMI® Logo
are trademarks or registered trademarks of HDMI® Licensing Administrator, Inc.
IMPORTANT PRECAUTIONS
1. Before using this device, please read all the instructions in this manual carefully.
2. Please keep the manual for future reference.
3. Unplug this device from the wall outlet before cleaning. Do not use liquid
cleaners or aerosol cleaners. Use a damp or wet cloth to clean. Please use LCD
screen detergent for cleaning if it is still dirty.
4. Do not use parts not recommended by the manufacturer, otherwise it may cause
a hazard.
5. When unplugging the power cord of the monitor or adapter, please hold the plug
with your hand, do not pull the cord directly.
6. Do not place any object on the power cord. Do not trample it either.
7. Do not use the device near water sources, example: bathtub, basin, kitchen sink,
or washing machine. Do not place the device on a wet oor, or near a swimming
pool etc. Do not touch the screen with your ngers or other hard objects.
8. Slots and openings on housing and its back or bottom are provided for
ventilation. To ensure reliable operation of the components and to protect them
from overheating, these openings must not be blocked or covered placing the
device on a bed, sofa, rug, or other similar surface. The device should never be
placed near or over a radiator or heater and should not be placed in a built in
installation unless proper ventilation is provided.
9. Make sure that the device is at least 5 cm distance from the wall or other objects
around when it is in use.
10. The power supply must respond to that stated on the rating plate. If you have
any query about the power supply, please refer to the dealer or local power supply
provider.
11. As a safeguard measure, the monitor or adapter is equipped with a power cord
with three-terminal plug, the third terminal is grounded. If the plug cannot be
insterted into the outlet, please contact an electrical technician for replacing the
original outlet while keeping the safeguard measure in effect.
12. Ensure that the power socket and cord in use are able to take the sum of the
electric current of all the products.
13. Do not put the device at the place where user is subject to mal-function.
14. Observe all the warnings and instructions described in the manual.
15. Do not overload the power outlet or use any extension cord, otherwise it may
cause re or electric shock.
16. Do not attempt to repair this device yourself since opening or removing covers
may expose you to dangerous voltage or other hazards. Refer servicing to qualied
service personnel.
17. Unplug this monitor or AC/CD adapter from the wall outlet and refer servicing to
qualied service personnel under the following conditions:
A. When the power cord or plug is damaged or worn.
B. If the device has been dropped or its housing has been damaged.
C. When the performance of the device deteriorates distinctly.
18. The power cord is the main facility to turn on/off the device; unplug it if the
device is not used for a long period of time.
19. Store the device at a place of good ventilation; avoid strong sunlight, high
temperature or humidity.
20. Store the device at a place at -20°C - 55°C room temperature. Otherwise, it may
cause permanent damage.
INTRODUCTION
General
Thank you for purchasing the latest GAMING MONITOR SIGURD SERIE 3501, with the
advantages of high display performance and lightweight etc. Meanwhile with the
power saving and none-radiation features, the latest GAMING MONITOR SIGURD
SERIE 3501 will bring you comfortable, safe and environmental protection and a
brand new visual experience.
Your purchase and use of this product is highly appreciated!
Features
- Micro Computer digital technology control, no radiation, no glare, built in
multimedia speaker system (optional).
- Built in AV signal connection terminal - HDMI® - Display Port-DVI
- Comply with DPMS International Power Saving Regulation.
- Support DDC 1/2B and Windows PNP Plug & Play.
- Microprocessor based with OSD (On Screen Display) control, be able to adjust the
image to optimum performance.
Packing List
Please make sure the following items are included with your
GAMING MONITOR SIGURD SERIES 3501 before installation:
1 Gaming Monitor (with pedestal)
1 AC/DC Adapter
1 Power Cable
1 Display Port Cable
1 User Manual
1 Warranty Policy (Digital)
If any of these items are missing, please contact with your dealer for technical
support and customer service.
NOTE: Be sure to save original box and all packaging material
for transport in future if the display need.
INSTALLATION
USB
Line Out
DisplayPort
HDMI (x2)
USB
DC
Connection of the Display Port Cable
Insert one end of the display port cable into the monitor’s input connector, and
the other end to the video output of your computer (either dedicated or integrated
video card).
Connecting the HDMI® Cable
Insert one end of the HDMI® cable into the monitor’s input connector, and the other
end to the video output of your computer (either dedicated or integrated video
card).
Connecting the DVI Cable
®
Insert one end of the DVI cable into the monitor’s input connector, and the other
end to the video
output of your computer (either dedicated or integrated video card).
Audio Output
You can connect headphones or speakers directly to the audio output of the
monitor through an audio cable with 3.5mm connectors.
Power Cord Connection
First, insert one end of power cord cable into the power input jack of the monitor,
and another end into the power outlet.
Power On
Turn on the monitor and computer, the indicator will light green ( or blue ) when the
screen is under normal condition. Please check to see if there is any wrong with
the connection of video signal cable if the indicator lights red.
Self-Inspection
If the monitor inspects that there is no horizontal and vertical signal, it will prompt
to check the video input,please refer to the illustration below, and the monitor will
enter into power saving mode after several seconds,the indicator will light red. The
screen will restore to normal display once receiving video signal.
Image Adjustment
Please adjust the image according to your need; please refer to the “Operation” in
Section Three.
OPERATION
Function Keys
A. AUTO/SELECT KEY
When with only VGA mode: without OSD menu, this key is used to auto-adjust, to
adjust the geometrical setting to the best condition. Under OSD menu, this key is
used as conrmation. Under VGA+DVI mode, this key is used to switch the signal
between VGA and DVI.
B. +/- or >/< KEY
In the OSD menu, these two keys are used to scan and select the menu on the left
or right and the volume setting. If the monitor does not have any audio signal press
-/<, this can be used as a shortcut key for brightness; if the monitor does not have
any audio signal function press +/- or >/<, this is only used for adjusting the volume.
C. MENU KEY
Menu Key is use to enter into menu and exit from menu.
OSD
Main Menu Item Submenu Item Discription
Luminance
Brightness Adjusts Monitor Brightness
Contrast Adjusts Monitor Contrast
LED Mode Selects the LED Mode
Logo Light Adjusts Laser Logo Light, ON
or OFF.
