YASKAWA MOTOMAN FS100 Manuel utilisateur

MANUAL NO.

164104-1CD

Part Number: 164104-1CD

Revision: 0

FS100

OPTION ADDENDUM

FOR EXPANDED I/O MAPPING

Upon receipt of the product and prior to initial operation, read these instructions thoroughly and retain

for future reference.

MOTOMAN INSTRUCTIONS

FS100 I/O MAPPING MANUAL

FS100 INSTRUCTIONS

FS100 OPERATOR’S MANUAL

FS100 MAINTENANCE MANUAL

The FS100 operator’s manual above corresponds to specific usage.

Be sure to use the appropriate manual.

164104-1CD

FS100

Introduction

This addendum supplies the instructions for the expanded Input/Output 

(I/O) mapping of the FS100.

MANDATORY

General items related to safety are listed in Section 2 of the FS100

Controller Manual. To ensure correct and safe operation, carefully read

the FS100 Controller Manual before reading this manual.

CAUTION

• Yaskawa Motoman may modify this model without notice when

necessary due to product improvements, or changes in

specifications.

• If such a modification is made, the manual number will also be

revised.

• If the addendum is damaged or lost, contact a Yaskawa Motoman

Customer Service Representative to order a new copy. The

representatives are listed on the back cover of this addendum. Be

sure to tell the representative the manual number listed on the front

cover.

• YASKAWA is not responsible for incidents arising from unauthorized

modification of its products. Unauthorized modification voids the

products warranty.

164104-1CD

FS100

List of Tables

FS100 Standard I/O LIO-08R Circuit Board - Connector CN2 ...............................................5

FS100 Standard I/O LIO-08R Circuit Board - Connector CN1 ...............................................6

FS100 Expanded I/O LIO-08R-A Circuit Board - Connector CN-2A ......................................8

FS100 Expanded I/O LIO-08R-A Circuit Board - Connector CN-1A ......................................9

FS100 Expanded I/O LIO-08R-B Circuit Board - Connector CN-2B ....................................11

FS100 Expanded I/O LIO-08R-B Circuit Board - Connector CN-1B ....................................12

FS100 Expanded I/O LIO-08R-C Circuit Board - Connector CN2-C ....................................14

FS100 Expanded I/O LIO-08R-C Circuit Board - Connector CN1-C ....................................15

FS100 Expanded I/O LIO-08R-D Circuit Board - Connector CN2-D ....................................17

FS100 Expanded I/O LIO-08R-D Circuit Board - Connector CN1-D ....................................18

FS100 Standard I/O LIO-08R Circuit Board - Connector CN2

164104-1CD

FS100

FS100 Standard I/O LIO-08R Circuit Board - Connector CN2

CN2 Pin # CI/O Description Signal Type Inform Name

159804-2

Breakout Card

Pin #

1n/a Input common 1

5n/a Input common 2 5

220010 External Start Input n/a 2

20 20011 External Hold Input n/a 21

320012 Call master job Input n/a 3

21 20013 Alarm/Error reset Input n/a 22

420014 External Servo ON Input n/a 4

22 20015 Select Play mode Input n/a 23

620016 Select Teach mode Input n/a 6

24 20017 Digital Input 7 Input n/a 25

720020 Digital Input 8 Input n/a 7

25 20021 Digital Input 9 Input n/a 26

820022 Work prohibited Input n/a 8

26 20023 Digital Input 11 Input n/a 27

20024 n/a n/a n/a

20025 n/a n/a n/a

20026 n/a n/a n/a

20027 n/a n/a n/a

9n/a Input Common 1_24V 9

27 n/a Input Common 2_24V 28

19 n/a Input Common 1_0V 20

23 n/a Input Common 2_0V 24

13 n/a 24V for output load 13

16 n/a 24V for output load 16

31 n/a 24V for output load 32

10 30010 Running Output n/a 10

28 30011 Servo ON Output n/a 29

11 30012 Top of master job Output n/a 11

29 30013 Alarm/error occurred Output n/a 30

14 30014 Battery alarm Output n/a 14

32 30015 Remote mode selected Output n/a 33

15 30016 Play mode selected Output n/a 15

33 30017 Teach mode selected Output n/a 34

17 30020 In cube 1 Output n/a 17

35 30021 Digital Output 9 Output n/a 36

18 30022 Work home position Output n/a 18

36 30023 Intermediate start OK Output n/a 37

30024 n/a n/a n/a

30025 n/a n/a n/a

30026 n/a n/a n/a

30027 n/a n/a n/a

FS100 Standard I/O LIO-08R Circuit Board - Connector CN1

164104-1CD

FS100

FS100 Standard I/O LIO-08R Circuit Board - Connector CN1

CN1 Pin # CI/O Description Signal

Type Inform Name 159804-3 Break-

out Card Pin #

1Input common 3 1

6Input common 4 6

220030 User Input Input IN#(1) 2

27 20031 User Input Input IN#(2) 19

320032 User Input Input IN#(3) 3

28 20033 User Input Input IN#(4) 20

420034 User Input Input IN#(5) 4

29 20035 User Input Input IN#(6) 21

520036 User Input Input IN#(7) 5

30 20037 User Input Input IN#(8) 22

720040 User Input Input IN#(9) 7

32 20041 User Input Input IN#(10) 24

820042 User Input Input IN#(11) 8

33 20043 User Input Input IN#(12) 25

920044 User Input Input IN#(13) 9

34 20045 User Input Input IN#(14) 26

10 20046 User Input Input IN#(15) 10

35 20047 User Input Input IN#(16) 27

20050-7 LIO-08R Status bits Status IN#(17-24)

20060-7 LIO-08R Status bits Status IN#(25-32)

11 Input common 3_24V 11

36 Input common 4_24V 28

26 Input common 3_0V 18

31 Input common 4_0V 23

15 +24V for output load 15

22 +24V for output load 42

25 +24V for output load 48

40 +24V for output load 32

47 +24V for output load 43

12 30030 User Output Output OT#(1) 12

37 30031 User Output Output OT#(2) 29

13 30032 User Output Output OT#(3) 13

38 30033 User Output Output OT#(4) 30

16 30034 User Output Output OT#(5) 16

41 30035 User Output Output OT#(6) 33

17 30036 User Output Output OT#(7) 17

42 30037 User Output Output OT#(8) 50

19 30040 User Output Output OT#(9) 36

44 30041 User Output Output OT#(10) 37

20 30042 User Output Output OT#(11) 38

45 30043 User Output Output OT#(12) 39

23 30044 User Output Output OT#(13) 44

48 30045 User Output Output OT#(14) 45

164104-1CD

FS100

FS100 Standard I/O LIO-08R Circuit Board - Connector CN1

24 30046 User Output Output OT#(15) 46

49 30047 User Output Output OT#(16) 47

30050-7 System Reservation n/a n/a

30060-7 System Reservation n/a n/a

CN1 Pin # CI/O Description Signal

Type Inform Name 159804-3 Break-

out Card Pin #

FS100 Expanded I/O LIO-08R-A Circuit Board - Connector CN-2A

164104-1CD

FS100

FS100 Expanded I/O LIO-08R-A Circuit Board - Connector CN-2A

CN2 Pin # CI/O Description Signal

Type Inform Name 159804-2

Breakout Card

Pin #

1n/a Input common 1 1

5n/a Input common 2 5

220070 User Input Input IN#(33) 2

20 20071 User Input Input IN#(34) 21

320072 User Input Input IN#(35) 3

21 20073 User Input Input IN#(36) 22

420074 User Input Input IN#(37) 4

22 20075 User Input Input IN#(38) 23

620076 User Input Input IN#(39) 6

24 20077 User Input Input IN#(40) 25

720080 User Input Input IN#(41) 7

25 20081 User Input Input IN#(42) 26

820082 User Input Input IN#(43) 8

26 20083 User Input Input IN#(44) 27

20084 n/a n/a n/a

20085 n/a n/a n/a

20086 n/a n/a n/a

20087 n/a n/a n/a

9n/a Input Common 1_24V 9

27 n/a Input Common 2_24V 28

19 n/a Input Common 1_0V 20

23 n/a Input Common 2_0V 24

13 n/a 24V for output load 13

16 n/a 24V for output load 16

31 n/a 24V for output load 32

10 30070 User Output Output OT#(33) 10

28 30071 User Output Output OT#(34) 29

11 30072 User Output Output OT#(35) 11

29 30073 User Output Output OT#(36) 30

14 30074 User Output Output OT#(37) 14

32 30075 User Output Output OT#(38) 33

15 30076 User Output Output OT#(39) 15

33 30077 User Output Output OT#(40) 34

17 30080 User Output Output OT#(41) 17

35 30081 User Output Output OT#(42) 36

18 30082 User Output Output OT#(43) 18

36 30083 User Output Output OT#(44) 37

30084 n/a n/a n/a

30085 n/a n/a n/a

30086 n/a n/a n/a

30087 n/a n/a n/a

164104-1CD

FS100

FS100 Expanded I/O LIO-08R-A Circuit Board - Connector CN-1A

CN1 Pin # CI/O Description Signal

Type Inform Name 159804-3 Break-

out Card Pin #

1Input common 3 1

6Input common 4 6

220090 User Input Input IN#(49) 2

27 20091 User Input Input IN#(50) 19

320092 User Input Input IN#(51) 3

28 20093 User Input Input IN#(52) 20

420094 User Input Input IN#(53) 4

29 20095 User Input Input IN#(54) 21

520096 User Input Input IN#(55) 5

30 20097 User Input Input IN#(56) 22

720100 User Input Input IN#(57) 7

32 20101 User Input Input IN#(58) 24

820102 User Input Input IN#(59) 8

33 20103 User Input Input IN#(60) 25

920104 User Input Input IN#(61) 9

34 20105 User Input Input IN#(62) 26

10 20106 User Input Input IN#(63) 10

35 20107 User Input Input IN#(64) 27

20110-7 LIO-08R Status bits Status IN#(65-72)

20120-7 LIO-08R Status bits Status IN#(73-80)

11 Input common 3_24V 11

36 Input common 4_24V 28

26 Input common 3_0V 18

31 Input common 4_0V 23

15 +24V for output load 15

22 +24V for output load 42

25 +24V for output load 48

40 +24V for output load 32

47 +24V for output load 43

12 30090 User Output Output OT#(49) 12

37 30091 User Output Output OT#(50) 29

13 30092 User Output Output OT#(51) 13

38 30093 User Output Output OT#(52) 30

16 30094 User Output Output OT#(53) 16

41 30095 User Output Output OT#(54) 33

17 30096 User Output Output OT#(55) 17

42 30097 User Output Output OT#(56) 50

19 30100 User Output Output OT#(57) 36

44 30101 User Output Output OT#(58) 37

20 30102 User Output Output OT#(59) 38

45 30103 User Output Output OT#(60) 39

23 30104 User Output Output OT#(61) 44

FS100 Expanded I/O LIO-08R-A Circuit Board - Connector CN-1A

164104-1CD

FS100

48 30105 User Output Output OT#(62) 45

24 30106 User Output Output OT#(63) 46

49 30107 User Output Output OT#(64) 47

30110-7 System Reservation n/a 65-72

30120-7 System Reservation n/a 73-80

CN1 Pin # CI/O Description Signal

Type Inform Name 159804-3 Break-

out Card Pin #

Autres manuels pour MOTOMAN FS100

Table des matières

Autres manuels YASKAWA Contrôleurs

YASKAWA

YASKAWA CC-Link Manuel utilisateur

YASKAWA

YASKAWA MP23xxxiec Series Manuel utilisateur

YASKAWA

YASKAWA SGD7S series Manuel utilisateur

YASKAWA

YASKAWA MOTOMAN Series Manuel utilisateur

YASKAWA

YASKAWA SGLGW Manuel utilisateur

YASKAWA

YASKAWA Z1000 CIMR-ZU*A Series Manuel du propriétaire

YASKAWA

YASKAWA PROFINET 1000 Series Manuel utilisateur

YASKAWA

YASKAWA MP210 Series Manuel utilisateur

YASKAWA

YASKAWA SI-T3 MECHATROLINK-II A1000 Series Manuel utilisateur

YASKAWA

YASKAWA GA700 Manuel utilisateur

YASKAWA

YASKAWA SigmaLogic7 Compact Manuel utilisateur

YASKAWA

YASKAWA YASNAC J50 Guide de démarrage rapide

YASKAWA

YASKAWA PROFINET V1000 Manuel utilisateur

YASKAWA

YASKAWA MP3100 Series Manuel utilisateur

YASKAWA

YASKAWA MP2300Siec Manuel utilisateur

YASKAWA

YASKAWA Motoman DX200 Manuel utilisateur

YASKAWA

YASKAWA Servopack CACR-SR Series Manuel utilisateur

YASKAWA

YASKAWA PROFIBUS-DP 1000 Series Manuel utilisateur

YASKAWA

YASKAWA Z1000U Series Manuel du propriétaire

YASKAWA

YASKAWA MP2000 Series Manuel de programmation

YASKAWA

YASKAWA PG-X3 Manuel utilisateur

YASKAWA

YASKAWA JAPMC-CP3301-1-E Manuel utilisateur

YASKAWA

YASKAWA FSDrive-MV1000 Series Manuel utilisateur

YASKAWA

YASKAWA SI-EM3 Manuel utilisateur

Manuels Contrôleurs populaires d'autres marques

Digiplex

Digiplex DGP-848 Mode d'emploi

Sinope

Sinope Calypso RM3500ZB Manuel utilisateur

Isimet

Isimet DLA Series Style 2 Manuel d'installation

LSIS

LSIS sv-ip5a Manuel utilisateur

Rockwell Automation

Rockwell Automation 1769-L31 Manuel utilisateur

Airflow

Airflow Uno hab Manuel utilisateur

ABB

ABB ACS580-01 drives Manuel utilisateur

Panasonic

Panasonic GM1 Series Manuel utilisateur

Emerson

Emerson SW93 Manuel utilisateur

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manuel utilisateur

Panasonic

Panasonic FP? Positioning Unit RTEX Manuel utilisateur

Samson

Samson Type 5824 Manuel de service

Alpha IP

Alpha IP MIOB 21001 Manuel utilisateur

Siemens

Siemens OpenAir GMA 1 Series Manuel utilisateur

Surecom

Surecom SR-629 Manuel utilisateur

Fishman

Fishman TriplePlay Manuel utilisateur

Regulus

Regulus SRS1 T Manuel utilisateur

3M MicroTouch EX113 Manuel utilisateur
