Yanmar SD20 Manuel utilisateur
SD20,SD50/SD50-4T
OPERATION MANUAL
EN
SD-Series
SAIL-DRIVE
MODEL: SD20, SD50/SD50-4T
OPERATION MANUAL
Applicable Engine Model:
1GM10C, 2YM15, 3YM20, 3YM30, 3JH4E, 4JH4E 4JH3-TCE
All rights reserved. This manual may not be reproduced or copied, in whole or in part,
without the written permission of YANMAR CO., LTD.
Copyright © 2004 Yanmar CO., LTD
EN
Introduction ................................................... 3
1. For Your Safety ........................................ 4
1.1 Safety Precautions For Inspection .... 4
2. Specifications ........................................... 7
3. Selecting Lubricating Oil ........................... 8
3.1 Choice of lube oil .............................. 8
3.2 Kind of lube oil .................................. 8
3.3 Lube oil viscosity ............................... 9
4. Starting the New Sail-Drive for the First
Time .................................................. 10
4.1 Filling with lubricating oil ................. 10
4.1.1 SD20 and SD50/-4T .............. 10
4.2 Check of instrument panel alarm sys-
tem: 11
4.3 Remote-Control Device Check ........ 12
4.4 Fitting for Fixed Propeller (2-blade) . 14
4.5 Recommended Propeller Size (Max.) .
14
5. Method of Operation .............................. 16
5.1 Engine Cooling Water ..................... 16
5.1.1 SD20 ..................................... 16
5.1.2 SD50/SD50-4T ...................... 17
6. Periodic Inspections and Maintenance ... 18
6.1 Lubricating oil system ...................... 19
6.1.1 SD20 ..................................... 19
6.1.2 SD50/-4T ............................... 20
6.2 Procedure for filling and removing oil in
the Sail-Drive; SD50/-4T 21
6.2.1 When the boat is in the water 22
6.2.2 When the boat is out of the water
26
6.3 Anticorrosive zinc ............................ 29
6.3.1 SD20 and SD50/ SD50-4T .... 29
6.4 Rubber diaphragms (A) and (B) (SD20
and SD50/-4T) 29
6.5 When the boat hull is raised onto a
block, inspect the following: 30
7. Electrical Wiring Diagrams ......................31
3
EN
Introduction
This Installation and Operation Manual describes Sail-Drive Models SD20, SD50,
SD50-4T.
For engine handling and operation, refer to the respective operation manuals for Engine
Models 1GM10C, 2YM15, 3YM20, 3YM30, 3JH4E, 4JH4E and 4JH3-TCE. However, in-
structions for the marine gear box are not necessary as they are included.
Engines and sail-drive combinations are available as follows:
Engine model Sail-drive model
1GM10C SD20
2YM15
3YM20, 3YM30
3JH4E SD50
4JH4E
4JH3-TCE SD50-4T
4
1. For Your Safety
EN
1. For Your Safety
1.1 Safety Precautions For Inspection
Battery
Never smoke or permit sparks near the battery, because it may emit ex-
plosive hydrogen gas. Place the battery in a well-ventilated place.
Fuel
Use only diesel fuel. Never use other fuels, including gasoline, kero-
sene, etc., because they could cause a fire. The wrong fuel could also
cause the fuel injection pump and injector to fail due to lack of proper
lubrication. Be sure to check that you have selected the correct diesel
fuel before filling the fuel tank.
Do not use starting fluids or sprays. Their use may cause explosion, se-
rious injury and engine damage.
Fire Prevention
Be sure to stop the engine and confirm that there are no open flames in
the vicinity before fueling. If you do spill fuel, wipe such spillage careful-
ly and dispose of the wiping materials properly. Wash your hands thor-
oughly with soap and water.
Never place oil or other flammable material in the engine room.
Install a fire extinguisher near the engine room, and familiarize yourself
with its use.
Exhaust Gas
Exhaust gas contains poisonous carbon monoxide and should not be
inhaled.
Be sure to install ventilation ports or ventilators in the engine room and
ensure good ventilation during engine operation.
Moving Parts
Do not touch or let your clothing get caught in the moving parts of the
engine, such as the front drive shaft, V-belt or propeller shaft, during en-
gine operation. You will be injured.
Never operate the engine without covers on the moving parts.
DANGER
DANGER
WARNING
WARNING
WARNING
1. For Your Safety
5
EN
Burns
The whole engine is hot during operation and immediately after
shut-down. The exhaust manifold, exhaust pipe and high pressure fuel
lines are very hot. Never touch these parts with your body or clothing.
Alcohol
Never operate the engine while you are under the influence of alcohol.
Never operate the engine when you are ill or not feeling well.
Battery Fluid
Battery fluid is dilute sulphuric acid. It can blind you if it gets in your
eyes, or burn your skin. Keep the fluid away from your body.
If you touch it, wash it off immediately with a large quantity of fresh wa-
ter and call your doctor for treatment.
Fire by Electric Short-Circuits
Always turn off the battery switch before inspecting the electrical sys-
tem.
Failure to do so could cause short-circuiting and fires.
Stop the engine before you service it.
Turn the battery switch off. If you must inspect while the engine is in op-
eration, never touch moving parts. Keep your body and clothing well
clear of all moving parts.
Scalds
When extracting oil from the engine while it is still hot, don't let the oil
splash on you.
Wait until the temperature has dropped before extracting cooling water
from the engine. Don't let it splash on you.
CAUTION
WARNING
DANGER
WARNING
WARNING
CAUTION
6
1. For Your Safety
EN
Forbidden Modifications.
Never release the limiting devices such as the engine speed limit, fuel
injection limit, etc.
Modification will impair the safety and performance of the product and
shorten product life.
Also note that any troubles arising from modification are not covered by
our warranty.
Precautions for Treating Waste.
Never dispose of waste oil or other fluid in a field, sewer, river, or the
sea.
Treat waste matters safely observing regulations or laws.
Ask a waste recovery company to collect it.
DANGER
DANGER
2. Specifications
7
EN
2. Specifications
Note: A propeller with rubber bushing must be used in all SD series sail-drives.
Model SD20 SD50 SD50-4T
Reduction gear system Constant mesh gear with
dog clutch use
Cone clutch
Direction of
rotation
Input shaft Counter-clockwise viewed from stern
Propeller shaft Counter-clockwise viewed
from stern
Counter-clockwise or clockwise viewed from
stern
Reduction ratio Ahead 2.64 2.32
Astern 2.64 2.32
Propeller speed (min-1) 1364 1293 1638
Lubrication system Oil bath type
Lubrication oil
capacity
Standard unit 2.2 L 2.2 L
Long-reach
unit
2.5 L 2.35 L (Extension 58), 2.45 L (Extension
100)
Dry weight 30 Kg 39 kg 41 kg
Remote-con-
trol device
Control head Single control lever
Cable "MORSE" 33C (equivalent)
Applicable engine model (Fuel
stop power at crankshaft)
1GM10C (6.7kW/3600
min-1)
2YM15 (10.3kW/3600 min-1)
3YM20 (16.2kW/3600 min-1)
3YM30 (22.1kW/3600 min-1)
3JH4E
(29.4 kW/3000 min-1)
4JH4E
(40.5 kW/3000 min-1)
4JH3-TCE
(55.2kW/3800min-1)
8
3. Selecting Lubricating Oil
EN
3. Selecting Lubricating Oil
3.1 Choice of lube oil
The choice of lube oil is very important to
a Sail-Drive. If an unsuitable oil is used, or
oil change is neglected, it may result in
damage, and a shorter Sail-Drive life.
When selecting the lube oil, it must be one
of the following:
3.2 Kind of lube oil
Use only oil of quality “GL-4" or "GL-5" in
the API service, and SAE No. 90 or
80W90.
(Except model SD20 x 1GM10C and
SD50/-4T)
Use only oil of quality "cc" or greater in the
API service, and SAE no. 10W30.
(Applicable model: SD20 x 1GM10C)
For SD20 (except if coupled with the 1GM10C) and SD50/-4T
Use "Quicksilver High Performance Gear
Lube" for the SD50/-4T.
This lube oil is available through all Mer-
Cruiser, Mercury, Mariner and Force out-
lets in their Quicksilver accessories
program.
Engine series GM, YM JH3, JH4
Engine model 1GM10C 2YM15 3YM20 3YM30 3JH4E 4JH4E 4JH3-TCE
Sail-drive model SD20 SD50 SD50 SD50-4T
Lubrication oil for
the sail-drive
API CC or
greater and
SAE 10W30
API GL4 or GL5 and SAE
80W90 or 90
API GL4 or GL5 and SAE
80W90 or 90 or Quicksil-
ver High Performance Gear
Lube
Quicksilver
High Perfor-
mance Gear
Lube
Supplier Brand Name API Service SAE No.
SHELL Shell Spilax oil EP 90 GL-4 90
SHELL Shell Spilax oil HD 90 GL-5 90
CALTEX Multipurpose thuban EP GL-4/GL-59 90
MOBIL Mobilub HD 80W-90 GL-5 80W-90
ESSO Esso gear oil GP 90 GL-4 90
ESSO Esso gear oil GX 90 GL-5 90
3. Selecting Lubricating Oil
9
EN
This High Performance Gear Lube is avail-
able in the following sizes:
3.3 Lube oil viscosity
The viscosity of the lube oil greatly influ-
ences Sail-Drive performance
Volume Part number Package
300 ml 92-802851Q1 case of 24 tubes
1 L 92-802854Q1 case of 12 plastic
bottles
10 L 92-802856Q1 case of 2 cans
60.5 L 92-802857Q1 single drum
208 L 92-802858Q1 single drum
