Yamaha YAS-107 Instructions générales

This Guide provides instructions for updating firmware on the

following products.

•YAS-107

• YAS-207

• ATS-2070*

* Sold only in certain countries or regions

See product pages on the Yamaha website for details regarding

the issues resolved, and functions added, by updating firmware.

Equipment required for

firmware update

Prepare the following items before attempting to update firmware.

• USB flash drive

Use a USB flash drive that meets all of the following

requirements.

– Supports the USB mass storage device class

– Formatted in FAT16 or FAT32 format

– No encryption applied

– No data stored on the device (empty)

• Computer that can be connected to the Internet

Download the firmware from the Yamaha website.

• USB cable (for YAS-107 only)

Use the USB cable supplied with the unit.

Update Guide

Manual Development Group

Published 07/2017 KS-B0

AV17-0035

Preparing the firmware

1Download the latest version of firmware from

the Yamaha website to a computer.

See product pages on the Yamaha website for more

information.

2Decompress the downloaded file and save

the firmware data file to the USB flash drive.

Be sure to save the firmware data file in the top folder (root

folder) of the USB flash drive.

Do not change the file name when saving it. File names are

as follows:

• YAS-107: YAS-107-xxxx.ybin

• YAS-207: YAS-207-xxxx.ybin

• ATS-2070: ATS-2070-xxxx.ybin

“xxxx” is a set of pre-determined alphanumeric characters.

Updating the unit’s firmware

1Turn off the unit.

2Unplug the power cable from the AC wall

outlet.

3Connect the USB flash drive to the UPDATE

ONLY jack on the unit.

YAS- 10 7

YAS- 20 7

ATS-2070

4Plug the power cable into an AC wall outlet.

NOTICE

Depending upon how the unit has been installed and the

shape of the USB flash drive, connecting the USB flash drive

to the unit may be difficult. If this is the case, disconnect any

cables connected to the unit, and be sure that there is enough

space around the unit to properly perform the update process.

UPDATE

ONLY

USB cable

(supplied)

USB flash drive

containing the

firmware data

file

USB flash drive

containing the

firmware data file

5Touch and hold and together for at

least 3 seconds.

The firmware update begins. The indicators will glow as

shown below while the firmware is being updated.

The indicators will flash as shown below when the firmware

update has been successfully completed.

If indicators flash differently than shown above, or fail to glow

or flash at all, see “Troubleshooting” (p. 6 and 7).

6Touch when the firmware update is

complete.

The unit will turn off.

7Disconnect the USB flash drive.

The firmware update has been completed.

Running display (glow in succession) Glows

Flash

NOTICE

Do not unplug the power cable or disconnect the USB flash

drive until the following procedures are completed.

3D surround playback

This firmware update supplies the unit with the 3D surround

playback function. When 3D surround is selected, DTS Virtual:X

makes it possible to hear sound not only from horizontal

directions, but also from varying heights.

1Press the z(power) key on the remote

control to turn on the unit.

2Press the SURROUND key on the remote

control to switch to 3D surround playback;

the SURROUND indicator will glow blue.

The unit switches between 3D surround playback and

surround playback each time the SURROUND key is

pressed.

Glows blue: 3D surround playback

Glows green: surround playback

The input source will be played with 3D surround sound.

See “Operations” in the Owner’s Manual for more information.

For DTS patents, see http://patents.dts.com. Manufactured under

license from DTS, Inc. DTS, the Symbol, DTS and the Symbol

together, DTS Digital Surround, and DTS Virtual:X are registered

trademarks or trademarks of DTS, Inc. in the United States and/or

Troubleshooting

If the firmware update fails, the indicators will flash as illustrated below. Confirm the problem and try updating the firmware again.

Flashing (red) indicator

Cause Remedy

The USB flash

drive is not

connected to the

unit correctly.

1. Terminate the update by touching z.

2. Connect the USB flash drive to the

unit correctly.

3. Try updating the firmware again.

Flashes (red)

Cause Remedy

The firmware data

file was not

properly saved to

the USB flash

drive.

1. Terminate the update by touching z.

2. Disconnect the USB flash drive and

be sure that the firmware data file has

been saved as follows.

• The file name has not been

changed.

• The file is stored in the top folder

(root folder).

3. Connect the USB flash drive and try

updating the firmware again.

Flashing (red and green) indicators Indicators off

Cause Remedy

The USB flash

drive was

disconnected

from the unit

while firmware

was being

updated.

1. Terminate the update by touching z.

2. Connect the USB flash drive to the

unit correctly.

3. Try updating the firmware again.

The USB flash

drive is damaged.

1. Terminate the update by touching z.

2. Save the firmware data file to another

USB flash drive and try updating the

firmware again.

There is a

problem with the

firmware data file.

1. Terminate the update by touching z.

2. Download the firmware data file for

your unit from the Yamaha website

and save it to the USB flash drive.

3. Try updating the firmware again.

Flash (red) Flash (green)

Cause Remedy

The power cable

was unplugged

while firmware

was being

updated.

1. Plug the power cable into an AC wall

outlet.

2. Be sure that the USB flash drive is

correctly connected to the unit.

3. Touch z.

The firmware update will resume.

A power failure

occurred.

1. Be sure that the USB flash drive is

correctly connected to the unit.

2. Touch z.

The firmware update will resume.

Turned off
