Yamaha NX-E100 Manuel utilisateur

OWNER’S MANUAL

MODE D’EMPLOI

¤ˇ¥˛»¡'œﬁ

取扱説明書

NX-E100

Speaker System

Systeme D’enceintes

·›`n „‚¸‚m

スピーカシステム

Thank you for selecting this Yamaha NX-E100 speaker system.

PRECAUTIONS

Read these precautions carefully before using your

speaker.

• Any time you note distortion, reduce the volume

control on the receiver to a lower setting. Never allow

the receiver to be driven into “clipping”. Otherwise the

speaker may be damaged.

• When using a receiver with a rated output power

higher than the nominal input power of the speaker,

care should be taken never to exceed the speaker’s

maximum input.

• Do not attempt to clean the speaker with chemical

solvents as this might damage the finish. To clean,

wipe with a dry, soft cloth.

• To prevent the enclosure from warping or discoloring,

do not place the speaker where it will be exposed to

direct sunlight or excessive humidity.

• Do not place the speaker where it is liable to be

knocked over or struck by falling objects. Stable

placement will also ensure better sound performance.

• Placing the speaker on the same shelf or rack as the

turntable can result in feedback.

• This speaker system is designed for home use only.

Never use this speaker system inside a car.

• Secure placement or installation is the owner’s

responsibility.

YAMAHA shall not be liable for any accident caused

by improper placement or installation of the speaker.

CONNECTION TO YOUR RX-E100 RECEIVER

BEFORE MAKING CONNECTIONS, MAKE SURE

THAT THE RX-E100 RECEIVER IS SWITCHED

OFF.

• When this unit is connected to the RX-E100 receiver,

refer also to the owner’s manual supplied with the

receiver.

■CONNECTIONS

• Connect the screw-type input terminals at the rear of

the speakers to the speaker output terminals of the

receiver with the provided speaker cords.

• One side of the speaker cord is red and the other side is

black. Connect the (+) terminals on the receiver and

speakers using the red side. Connect the (–) terminals

on both components using the black side of the cord.

• Connect one speaker to the left (marked L) terminals

of the receiver, and the other to the right (marked R)

terminals. Make sure not to reverse the polarity (+, –).

If a speaker is connected with reversed polarity, the

sound will be unnatural and lack bass.

Procedures:

➀Loosen the terminal knob.

➁Insert the bare wire end properly into the terminal

hole. [Remove approx. 10 mm (3/8”) insulation from

the speaker cord.]

➂Tighten the knob.

➃Test the security of the connection by pulling the cord

gently at the terminal.

Note

Do not let the bare speaker wires touch each

other as this could damage the speaker and/or

the receiver.

RX-E100

Tighten

Loosen

Red (+)

Black (–)

Red line

Speaker (L)Speaker (R)

Black line

Red line

Speaker output terminals

of the receiver

• Place the speakers on a sturdy, vibration-free surface.

You may not be able to obtain good bass quality when

the speakers are placed directly on the floor. Put a

block, etc. under the speakers.

• Better stereo images will be obtained when the

speakers are slightly angled in towards the listening

position.

The front cover is fastened to the enclosure at four points,

and can be removed if desired. To remove the cover, hold

on to both sides of the cover and slowly pull straight

away from the speaker.

To reattach, line up the four pegs on the inside surface of

the cover with the four corresponding holes on the

speaker and push gently.

REMOVING THE FRONT COVER

Type ............................ 2-way bass-reflex speaker system

(Magnetically-shielded type)

Driver................................................. 13 cm cone woofer

2.5 cm dome tweeter

Impedance............................................................. 6 ohms

Frequency response .................. 55 Hz - 28 kHz (–10 dB)

Nominal Input Power ............................................... 60W

Maximum Input Power........................................... 110W

Sound pressure level............................... 87 dB/2.83 V.m

Crossover Frequency .............................3 kHz 12 dB/oct.

Dimensions (W x H x D)................. 186 x 300 x 222 mm

(7-5/16” x 11-13/16” x 8-3/4”)

Weight .......................................... 4 kg (8 lbs. 13 oz.) x 2

Accessory ................................... Speaker cable (4 m) x 2

* Specifications subject to change without notice due to

product improvements.

* Care should be taken not to exceed the input power

values noted above.

SPECIFICATIONS

Note

When the cover is removed, take care not to

touch the speaker units with your hands or to

exert excessive force with tools.

PLACING THE SPEAKERS
