Yamaha NS-E103 Manuel utilisateur

NS-E103

Thank you for selecting this Yamaha NS-E103 speaker system.

PRECAUTIONS

Read these precautions carefully before using your speaker.

●Any time you note distortion, reduce the volume control on

your amplifier to a lower setting. Never allow your amplifier to

be driven into “clipping”. Otherwise the speaker may be

damaged.

●When using an amplifier with a rated output power higher than

the nominal input power of the speaker, care should be taken

never to exceed the speaker’s maximum input.

●Do not attempt to clean the speaker with chemical solvents as

this might damage the finish. To clean, wipe with a dry, soft

cloth.

●To prevent the enclosure from warping or discoloring, do not

place the speaker where it is exposed to direct sunlight or

excessive humidity.

●Do not place the speaker where it is liable to be knocked over

or struck by falling objects. Stable placement will also ensure

better sound performance.

●Placing the speaker on the same shelf or rack as the turntable

can result in feedback.

●As some speaker contain strong magnets, avoid placing

watches, magnetic tapes, etc. near them. Also, placing

speaker near a TV set may impair picture color. If this

happens, move the speakers away from the TV set .

●Secure placement or installation is the owner’s

responsibility. YAMAHA shall not be liable for any

accident caused by improper placement or installation of

the speaker.

BEFORE MAKING CONNECTIONS, MAKE SURE THAT THE

AMPLIFIER IS SWITCHED OFF.

■CONNECTIONS

●Connect the push-type input terminals at the rear of the

speakers to the speaker output terminals of your amplifier with

the provided speaker cables.

●One side of the speaker cable is marked with a gray line.

Connect the (+) terminals on both the amplifier and the

speakers using this gray-marked side. Connect the (–)

terminals on both components using the unmarked side of the

cable.

●Connect one speaker to the left (marked L) terminals of your

amplifier, and another speaker to the right (marked R)

terminals, being sure not to reverse the polarity (+, –). If one

speaker is connected with reversed polarity, the sound will be

unnatural and lack bass.

Procedures:

➀Press the tab on the terminal down, as shown in the figure.

➁Insert the bare wire end properly into the terminal hole.

[Remove approx. 10 mm (3/8”) insulation from the speaker

cable.

➂Remove your finger from the tab to allow it to lock snugly on

the cable’s wire end.

➃Check the connection by lightly pulling the cable at the

terminal.

Note

Do not let the bare speaker wires touch each other as this

could damage the speaker and/or the amplifier.

CONNECTION TO YOUR AMPLIFIER

Natural Sound Bass-Reflex Effect Speaker System

Red Press

tab

Black

Speaker (R)

Gray line Gray line

Speaker output

terminals of

the amplifier

Speaker (L)

Gray line

Amplifier

■Mounting the speakers on a wall

The speaker can be mounted on a wall by using the holes

provided on the speakers’ back panel.

The hole(s) on the speaker’s back panel is arranged so that the

speaker can be mounted in either of the two configurations

shown by the following figures.

Fasten wood screws onto a firm wall or wall support as shown in

the figure, and set the mounting holes onto the protruding

screws.

SETTING UP THE SPEAKERS

Printed in China V 228210

Make sure that the screw is caught securely at a narrow part of

the hole .

For upright

mounting

For side-long

mounting

Diam. 4–5 mm

Min.

12 mm

Wood screw

(Available at a

hardware store)

Wall or

wall support

Upright mounting Side-long mounting

60mm

WARNING:

* Each speaker weighs 1.4 kg (3 lbs. 1 oz.). Do not mount them

on thin plywood or soft wall surface material, as the screws

may come out of the flimsy surface, causing the speakers to

fall down and be damaged, or result in personal injury.

* Do not fasten the speakers to walls with nails, adhesives, or

other unsound hardware. Long-term use and vibrations may

cause them to fall down.

* To avoid accidents resulting from tripping over loose speaker

cables, fix them to the wall.

For the upright mounting, only one hole is provided.

As for the side-long mounting, two holes are provided. Be sure

to use these two holes as a set.

For side-long

mounting

SPECIFICATIONS

Type..................................Full-range bass-reflex speaker system

Magnetic shielding type

Speaker Unit ...............................................10 cm cone full-range

Nominal Impedance...........................................................6 ohms

Frequency Response............................................70 Hz – 20 kHz

Nominal Input Power..............................................................25W

Maximum Input Power ...........................................................80W

Sensitivity.....................................................................90 dB/W·m

Dimensions (WxHxD)....................................180 x 220 x 101 mm

(7-1/16” x 8-11/16” x 4”)

Weight.............................................................1.4 kg (3 lbs. 1 oz.)

Accessories............................................Speaker cable (10m) x 2

* Specifications subject to change without notice due to product

improvements.

* Care should be taken not to exceed the input power values

noted above.

4–5 mm
